Thomas M Osterville , MA July 14, 2015 Appliance: Model 107RF47D The front burner supports were disengaged from the element this is what prompted to replace the burner Removed the defective burner labeled the leads as to their location and coil connections. Replaced the connections to the corresponding locations, 1 to 1, 2 to 2 and the bridged terminal as it was. I noticed that the coils in the replacement burner were not wound in the same direction as the original burner and made note of this. I did not think much of this at the time, but on turning the power back on and lighting up the burners I noticed up they were not lighting up the corresponding elements. On Hi all the elements lit up, on medium hi the front burner did not correspond as the others did so I reversed leads 1 and 2 and now all the elements are corresponding as the others, the exception the rear (6") burner is dim on med-hi but the replacement burner is lighting up as all the others except the rear burner which is dimmed on med-hi as I said previously. The front burner is lighting up as the two larger burners do on all the other settings. My Range has two small elements, front and rear and two larger elements left and right. The stove was installed back in 1963 and is almost in the same condition as the day it was installed in the house I built. My now deceased wife of 64 years took excellent care of it and is a tribute to her. I hope this is in detail as well as I could put it to be understood by others. Thank you for your rescue of the replacement burner .The replacement took me about 1 hour to replace since I do not go up and down stairs as fast as I once was able at 87 years of age and I did this in my spare moments. Read More... 16 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Adjustable Wrench, Nut Drivers, Pliers, Screwdrivers
Kevin N Oakland , CA August 09, 2019 Dead 1970s GE stove heating elements Ordering the right part is the key. This is the element with 3 wire connectors NOT the usual kind with 2 prongs that slide in. Thank goodness this company carries these elements for old GE built-in stoves. I'm not super handy but replaced two in about 40 min. Make sure you save the old ceramic clamps. The three prongs of the element with connected wires need to fit completely in the ceramic grooves so the two sides can be clamped together. The new element comes with everything you need but the new ceramic pieces don't fit as well so I ended up reusing the old ones. Read More... 28 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Pliers, Screwdrivers
Ruth T New Orleans , LA April 23, 2020 Old range from the 1940's & the burners were not working I bought your replacements & reinstalled "new" vintage 4 prong burner elements. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
William G Pawcatuck , RI March 12, 2016 The element was worn and shorting out It took me a total of 10 minutes to remove the old, put side by side and transfer wires, and put the new one in! Very simple fix for a 40+ year old GE range. Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Screwdrivers
Roderick S Bradenton , FL October 02, 2023 Surface burner cracked. Ordered and replaced one 6" surface unit. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Socket Set
