Ge WB21X20252 Gas Surface Burner Control Valve OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB21X20252 replaces AP5790795, 3025894, PS8754413.

Description

This gas control valve regulates the flow of gas to a surface burner on your cooktop or range. Replacing a worn valve restores smooth, accurate flame adjustment, reliable ignition, and positive shutoff for safe, consistent burner performance.

• Regulates gas to one surface burner for ON/OFF and flame size control as you turn the knob
• Enables proper ignition when opened; supports steady, even flame once lit
• Common failure symptoms: hard-to-turn or wobbly knob, uneven flame or poor adjustment
• May help if the burner won't light despite sparking, or if there's a gas odor at the valve stem

What's included: 1 gas surface burner control valve assembly Install notes:

• Shut off the gas supply and disconnect power before servicing
• Remove the knob and access the valve from the control panel/cooktop area
• Transfer the igniter switch and any mounting hardware from the old valve to the new one if applicable
• After reassembly, check all connections with a leak-detection solution before use
