Need Help?
Call or text
Show parts
Usually ships within 4 - 14 days
A flange nut's unique wide flange design distributes the nut's pressure over the part it is securing. In return, it creates an even fastening surface, which reduces part damage and nut loosening. This one-piece all-metal fastener has a lock nut version that features a protruding circular flange. This drastically increases bearing surface, compatibility either for irregular or oversized holes, and surface tension reduction. Flange lock nuts are the preferred type of fastener for many lawnmower models because it can provide better fastening than regular screws, which are known to loosen under extreme vibration. However, it’s important to know that flange lock nuts are susceptible to wear and tear due to constant vibration exposure. It is essential to replace the broken flange lock nut immediately to prevent serious damage to the lawnmower. The MTD 712-04063 Flange Lock Nut OEM replacement can be used with Craftsman, White Outdoor, Yard Machines, MTD, or Columbia lawnmowers. It is a genuine or OEM MTD replacement part that measures 5/16-18. It is threaded and requires the use of a wrench. This replacement flange lock nut is sold individually. An MTD bolt carriage may also be needed and is sold separately.
This is a versatile screw designed with flanged hex head and double-lead threads. It is a high-low self-tapping screw with one thread that is high and the other low for easier penetration. The twin threads also reduce the amount of material displaced when the screw is driven into the material. This type of screw also creates a firmer grip. This screw can also be used to secure a newly installed front cover or grill. This part is available as an individual replacement part. It is a genuine OEM part for use with specific models of snow throwers, lawn tractors, electric mowers, chippers, and log splitters from Bolens, Cub Cadet, Craftsman, Poulan, Ryobi, Toro, MTD, Troy-Bilt, Yard Machines, and Yard-Man.
A carriage bolt is a type of fastener. It features a smooth rounded head and a square domed top. It has threading, which leads to up to the square shoulder. The purpose of its square is to prevent the bolt from spinning. Once the carriage bolt is inserted through the hole, using a nut and washer can provide additional security. Carriage bolts can corrode and loosen over time. Since it doesn't have a slotted head, a socket wrench is needed when replacing. This bolt carriage replacement is compatible with wood chippers, tillers, string trimmers, lawnmowers, and edgers. It is a genuine MTD product that measures 5/16x.075. It has a smooth rounded head and square shoulder underneath it. This carriage bolt is sold individually.
This is a quality chute handle that is used on snowblowers. The purpose is to offer an easy place to hold on to so the operator can use the snowblower. This chute handle is made of durable plastic but wear and tear, regular use, or impact can cause it to become damaged or broken. If this happens, the handle will need to be replaced.No special tools are needed to replace the chute handle on the snowblower. A pair of work gloves can be used. Take the snowblower and place it on a sturdy surface before disconnecting the spark plug wire. The original chute handle can be pulled off of the machine to install the new one. The part will pop into place and the snowblower can again be used.The chute handle is made for use on snowblowers created by Craftsman, Huskee, MTD, Troy-Bilt, Yard Machines, and Yard-Man. This is an authentic OEM replacement part that is directly sourced from the manufacturer. This product is sold individually.
This component is a bail used with many types of snowblowers. This part is a safety feature, ensuring the snowblower turns on and off. If the bail becomes damaged or broken, it will need to be replaced to ensure the snowblower is safe to operate.If the bail is broken, bent, or otherwise damaged, the part will need to be replaced. A pair of pliers will be useful for this task. Be sure to wear work gloves, as well. Take the bail out of the handle holes. The new replacement part will fit into the handle spaces so the snowblower can be used again. This bail is a genuine OEM replacement part that is sourced directly from the manufacturer. It is sold as an individual part. The bail is made to fit a variety of snowblowers manufactured by Craftsman, Bolens, Ryobi, Yard Machines, Huskee, and Yard-Man.
This is a seven-inch cable tie that is used with different types of lawn and garden equipment. It is most commonly used to secure the cable onto the handle of the lawnmower or tiller so it is secure. The cable tie is made of durable plastic but can be damaged or break. When this happens, the tie will need to be replaced to ensure the cable stays on the handle.If the cable tie needs to be replaced, no tools are needed. In the situation where other parts need to be replaced at the same time, a basic set of tools and a pair of work gloves may be required. Turn off the yard equipment and place it on a stable surface before replacing the broken cable tie. The old tie can be removed so the new one can be installed before further use.This cable tie is an authentic OEM replacement part that is directly sourced from the manufacturer. This product is sold individually. The component is designed to be compatible with lawnmowers, lawn tractors, tillers, and snowblowers manufactured by MTD, Troy-Bilt, Yard-Man, and Yard Machines.
The shave plate, also called the scraper bar, is an important but often overlooked part of a snowblower. This thin metal strip sits at the bottom of the auger housing against the ground and gathers the snow the auger will expel through the chute. Made of hard plastic, the shave plate is the only part of the snowblower that actually touches the snow-covered ground without rolling. As durable as the shave plate is manufactured to be, it constantly comes into contact with unseen objects that pound, slice, and pit it. Eventually, the shave blade has to be replaced. To replace the blade, simply invert the blower, unscrew the old blade, attach the new blade, and put the blower right side up again. As long as the user is replacing the shave plate and has the machine upside down, this is an ideal time to check for damage to the wheels, the auger blades, driveshaft, and the condition of the shear pin. If this replacement is taking place in preparation for the coming winter, it might be a good time to replace the oil and oil filter as well. Be sure to use genuine OEM replacement parts that perfectly match the factory originals. This blade is compatible with snowblowers made by Yard-Man, Bolens, Yard Machines, Troy-Bilt, Craftsman, Ryobi, Cub Cadet, Huskee, Montgomery Wards, and Ryobi.
This carriage screw is a replacement part for Craftsman, Yard-Man, MTD, and Yard Machines lawnmowers and snowblowers. Carriage screws are made from durable metal and have a flat tip with a round head and threading on a portion of the shank. These screws may also be called coach screws or plow screws and are corrosion resistant, strong, and resistant to scratches. If a carriage screw breaks or beings to become weak, replacement may be required. In many cases, it’s possible to inspect the screw to determine whether it is still doing its job. The screw might be rusted or appear beaten up, which means it should be replaced. In most cases, it can be removed using a wrench unless the rusting is extreme. The new screw can be placed into the original hole and tightened to keep your snowblower running correctly. This is a genuine OEM replacement component for use with lawn tractors and snowblowers. It’s made of metal and can be found in various locations depending on the tool model. The screw comes as an individual item and will require the use of a wrench to install.
A flange lock nut, also known as a flange lock or a lock nut, is created to be used in various types of lawn and garden equipment. This flange lock nut holds other parts in place and, when properly threaded, will resist loosening. Over time, a flange lock nut may begin to weaken and may become loose or break. If it appears to be broken or weak, a replacement is required. Flange locks can be adjusted and uninstalled after use. When replacement is required, you may need a socket set, screwdriver, hacksaw, and butane torch. The socket wrench will loosen the bolt it is connected to, while the torch is used to heat the lock nut. A socket wrench may remove the nut, but sometimes cutting it with a hacksaw is required. This flange lock nut is a genuine OEM component directly from the manufacturer and comes in an individual unit. It is made of metal, a gold color, and can be found in various areas of lawn equipment. It works with lawnmowers, trimmers, snowblowers, cultivators, tillers, and leaf blowers by Poulan, MTD, Toro, Cub Cadet, Murray, Troy-Bilt, Bolens, Yard Machines, Craftsman, and Yard-Man.
This is a hex screw used on a variety of types of lawn and garden equipment. On large machinery, it is often used to mount the gas tank. On smaller items, it tends to be used to clamp the housing together. It can secure items like plastic, metal, brick, and wood together. It measures 5/16-18 x .75 inches and is made of durable metal. In some cases, the screw can become damaged, broken, or stripped, which means it needs to be replaced.A visual inspection will indicate whether the screw is damaged. If it needs to be replaced, a hex wrench can be used to remove it from the equipment. Afterward, the replacement hex screw can be installed with the wrench before being tightened to ensure materials hold together well.This hex screw is a genuine OEM part that is sold individually. It is sourced directly from the manufacturer. The hex screw is compatible with lawnmowers, wood chippers, log splitters, snowblowers, chainsaws, edgers, tillers, leaf blowers, and string trimmers by Craftsman, Cub Cadet, Ryobi, Troy-Bilt, Husky, Broan, Yard Machines, MTD, Huskee, Montgomery Wards, Bolens, Turf King, Yard-Man, and MasterCut.
