Parts for Ge AZ25E09D2PM1: 01 - Grille, Heater & Base Parts

This replacement front panel restores the appliance's appearance and protects internal components by covering the front cabinet and providing mounting for the console and door trim. Ideal when the existing panel is cracked, dented, or cosmetically worn. What it does:

• Covers the front of the appliance to protect internal parts from impact and debris
• Provides mounting points and alignment for the console, door trim, or lower access area
• Restores a flush, finished appearance to the appliance cabinet
• Commonly replaced for visible cracks, dents, peeling finish, or loose/misaligned trim

• Disconnect power (and water if applicable) before starting any repair
• Remove surrounding trim, screws, or door as required to access panel fasteners
• Handle panel carefully to avoid scratching the finish; align tabs before seating screws
• Reuse original hardware unless new fasteners are explicitly required by the OEM

This control panel cover is used on many General Electric Zoneline air conditioners. Color: cream. It measures about 7-1/2 inches wide by 5-1/2 inches high.

Color: beige. It measures about 15 inches wide by 10 inches high.

General Electric Zoneline air conditioner filter. Color: beige. It measures about 17 inches wide by 10 inches high.

This base pan assembly serves as the lower cabinet support for the appliance, providing a stable platform for internal components and helping contain minor leaks or debris. It restores proper fit and alignment at the unit's base. What it does:

• Replaces a damaged or corroded base pan to restore structural support under the appliance
• Helps keep internal components mounted securely and aligned
• Contains small drips or debris that collect at the appliance floor area
• Reduces vibration transfer from the cabinet to the floor when properly installed

• High-level replacement only; follow OEM service manual for step-by-step removal and reassembly
• Disconnect power (and water, if applicable) before beginning work
• Inspect surrounding seals, fasteners, and mounting hardware; replace any worn parts
• Use appropriate tools and work on a stable surface

This thermal overload protector safeguards the motor/compressor circuit by opening when temperature or current rises too high. Replacing a failed protector helps prevent damage and restore reliable operation when the unit won't stay running.

• Opens the circuit on over-temperature/over-current to protect windings
• Helps address symptoms like: hums then clicks off, won't start, or shuts down shortly after starting
• Often resets when cool; repeated tripping indicates a failing protector or a related issue
• Mounts against the component for accurate thermal sensing

• Disconnect power at the breaker before servicing; capacitors can retain a charge
• Note wire locations and transfer one at a time; terminals should fit snugly
• Seat/clip the protector firmly as designed for proper heat transfer
• If the old protector shows heat damage, also inspect the start relay/capacitor, wiring, and the motor/compressor

This protector heater is a small heating element used with the overload/thermal protector in the motor or compressor circuit. It provides calibrated warmth so the protector trips correctly under heavy load, helping prevent overheating and protecting the unit. What it does:

• Works with the overload/thermal protector to ensure proper trip timing
• Helps prevent overheating and potential damage to the motor/compressor
• Common signs include repeated clicking near the compressor area or frequent overload trips

• 1 protector heater

• Disconnect power and safely discharge the run capacitor before servicing
• Photograph or label wiring and component orientation for accurate reassembly
• Install in the same position/orientation as the original with secure, insulated connections and proper wire routing
• Inspect the overload, start device, and terminals; replace any burnt or loose connectors to prevent repeat failures
