Parts for Ge PFCS1RKZHSS: Ice Maker & Dispenser Parts

The water filter is an OEM part for GE refrigerators. This filter removes or reduces various contaminants.

Features and Benefits:

• Easy DIY replacement, typically mounted inside the refrigerator at the back of the compartment.
• Removes or reduces various contaminants in your water and ice, including lead, cysts, asbestos, atrazine, , taste and odor, chlorine, sediment, turbidity, and more
• NSF/ANSI 42 and 53 standards
• 6 Month lifespan filter
• Carbon Block media
• Micron rating: 0.5-1 micron (Class I)

When to replace your filter:

• Bad taste or odor in water and ice
• Cloudy or discolored ice
• Reduced water flow or pressure
• Refrigerator replace filter indicator light is on

Note: If replacing the Culligan metal canister design filter for the first time, a special adapter, part number AP2615702 is needed, which is not included with this part. The compatible bypass cap is part number AP6891551.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


8-18 CA HX 1/2 S

This stationary blade holder secures the stationary blade within the ice maker/dispenser assembly so the blade stays aligned for proper ice cutting and dispensing. It helps restore blade position and stable operation after damage or wear. What it does:

• Secures and locates the stationary blade inside the ice maker/dispenser assembly
• Keeps the blade aligned so ice is split or dispensed cleanly
• Replaces a cracked, worn or broken holder that allows blade wobble or misalignment
• Helps prevent binding or contact that can stop the blade from operating

• One stationary blade holder

• Installation requires removing the ice maker or dispenser trim per your model's service instructions
• Use basic hand tools; keep power to the appliance off and water disconnected when working on dispenser/ice components
• Inspect adjacent components (blade, mounting screws, clips) and replace any damaged parts for reliable operation

This spacer is a small mounting support used to maintain proper clearance and alignment between refrigerator panels, doors, or components. It helps reduce rubbing, vibration, and noise by restoring correct spacing and fit. What it does:

• Keeps panels, trim, or components spaced correctly to prevent metal-on-metal contact and wear
• Helps align doors and panels for a flush fit and smoother operation
• Reduces vibration and rattling caused by misaligned parts
• Used wherever a fixed clearance or gap is required during reassembly

• Disconnect power to the appliance before beginning any service that requires panel or component removal
• Inspect mating surfaces for damage or debris before installing the spacer; replace any damaged fasteners
• Install in the same orientation and location as the original spacer; do not overtighten mounting hardware

This moving blade crusher replaces the rotating/crushing blade in a refrigerator ice crusher and dispenser so the unit can break ice into smaller pieces for dispensing. Fits the crusher rotor where the blade spins against the fixed cutter. What it does:

• Cuts and crushes ice fed from the ice bin into smaller pieces for the dispenser
• Restores proper crushing when blades are worn, chipped, cracked or missing
• Helps reduce jams and large ice chunks that block the dispenser chute
• Works with the crusher rotor; does not include stationary cutter

• One (1) moving blade crusher

• Disconnect power to the appliance before servicing to avoid injury
• Remove the ice bucket/door panels per your model instructions to access the crusher assembly
• Inspect the stationary cutter and rotor for wear; replace both parts if damaged to ensure proper crushing
• Use care handling the blade—edges may be sharp

This washer drive coupling connects the motor to the transmission to transfer torque for agitation and spinning. Replacing a worn coupling restores drivetrain engagement so the washer can agitate and spin normally. What it does

• Transfers motor rotation to the transmission and agitator/drum.
• Failsafe shear design helps protect the transmission from overloads when worn or damaged.
• Commonly linked to symptoms like no agitation, no spin, slipping during cycles, or loud grinding/knocking from the drive area.
• Replacing a damaged coupling prevents further wear to motor and transmission components.

• One washer drive coupling

• Disconnect power before starting and drain/remove remaining water from the tub if present.
• Access requires removing the agitator and/or cabinet depending on model; retain fasteners and note orientation.
• Inspect motor and transmission splines for wear; replace damaged mating parts if present.
• Test the washer through a short cycle after installation to ensure proper engagement and quiet operation.

This DC auger motor drives the ice-dispensing auger in the freezer door, restoring proper ice delivery from the dispenser. It replaces a worn or failed motor to get the auger turning again for reliable dispensing. What it does:

• Turns the ice auger so cubes or crushed ice move from the bin to the dispenser
• Stops common symptoms like no ice dispensed, intermittent auger movement, or a stuck auger when motor failure is the cause
• Operates as the motorized drive for the dispenser auger assembly
• Works with the existing auger shaft and housing when the motor is the failed component

• One DC auger motor

• Disconnect power to the appliance before starting any repair
• Access may require removing the freezer door liner or dispenser housing; keep fasteners organized
• Observe wiring connections and routing; transfer connectors exactly or document before disconnecting

This is a standard 8-32 x 1/2 inch hex-head machine screw used to fasten appliance panels, brackets, and components. It replaces missing or damaged mounting screws to restore secure assembly and proper fit. What it does:

• Secures panels, brackets, and internal parts where an 8-32 x 1/2 in. screw is specified
• Stops rattling or loose parts caused by stripped or missing screws
• Restores proper alignment and mounting for components that rely on this fastener
• Works where a standard hex-head 8-32 machine screw is required

• Use the correct 8-32 screw and length to avoid damaging threads or components
• Tighten snugly but avoid over-torquing, which can strip threads or crack plastic
• Disconnect power before servicing
• Replace all like-for-like for even load and fit

This refrigerator ice maker assembly freezes water and automatically ejects cubes into the bin. Replacing a failed unit restores steady, hands-free ice production and helps resolve common ice maker cycling and cube-ejection issues.

• Freezes water in its mold, then harvests and drops finished cubes into the ice bin
• Controls fill and harvest timing for consistent cube production
• Typical failure symptoms: no ice production, unit stuck mid-cycle, cubes not ejecting, or loud clicking/grinding from the drive
• Works with the refrigerator's controls to pause ice making when the bin is full

• Disconnect power and shut off the water supply before servicing
• Remove the ice bin and any covers; unmount the old ice maker and disconnect its wiring harness
• Transfer any brackets, covers, or guides from the old unit if needed
• Mount the new assembly, reconnect wiring, restore power/water, and allow up to 24 hours for full ice production
