Parts for Dacor ER48DSCHNG: Igniter Assembly Parts

This service assembly secures the injector in the appliance's dispenser area so detergent or liquid additives are directed properly during the cycle. Replacing a damaged holder restores correct injector positioning and helps prevent dispenser issues. What it does

• Holds and aligns the liquid/detergent injector in the dispenser assembly
• Ensures proper flow path so additives are delivered into the wash
• Helps stop injector movement that can cause leaking or misdirected detergent
• Commonly replaced when the dispenser area is cracked, loose, or not dispensing correctly

• One injector holder service assembly

• Disconnect power and turn off water supply before starting any repair
• Remove the dispenser or access panel to reach the injector area
• Inspect nearby seals and clips; replace if damaged to ensure a watertight fit

This dual burner base assembly replaces the damaged or worn support that holds two cooktop burners in place, restoring proper alignment and stable burner seating for safer, more consistent heating. What it does

• Secures and centers two burner elements so they sit flat and stable
• Prevents burner wobble and misalignment that can cause uneven heating
• Provides the structural support for burners and related mounting hardware
• Works with original cooktop components to maintain proper burner positioning

• Disconnect power (and gas if applicable) to the appliance before starting work.
• Remove the cooktop or control panel per the manufacturer's service instructions to access the burner base.
• Inspect nearby components (burner caps, elements, clips) and replace any damaged parts for best results.

Seals the dual burner assembly to the cooktop surface, preventing spills and ensuring proper support. Replace when worn to restore a snug fit and reliable burner operation. Verify fit with your model number.

Rubber O-ring that seals the surface burner assembly to prevent gas and air leaks. Replace if you notice gas odor, poor ignition, or uneven flames. Confirm fit with your model number.

Nylon support bracket that secures the PCB control board in your dishwasher. Replace if cracked, broken, or missing to properly mount the circuit board.

Controls and protects LED lighting and display circuitry. Replace if LEDs flicker, dim, or fail completely. Verify fit with your model number.

This service shield LED isolator is a small module that controls and protects LED indicators on the appliance's control panel, making diagnostics and LED replacement easier for service techs. What it does

• Routes and isolates LED power and signals so indicator lights operate correctly
• Prevents backfeed and protects the main control board from LED-related faults
• Commonly replaced when LEDs are unlit, flickering, or display/indicator behavior is erratic
• Used during panel repairs and service diagnostics to restore proper LED function

• One service shield LED isolator module (single unit)

• Always disconnect power at the breaker or unplug the appliance before servicing
• Handle the module by edges and avoid touching contacts; observe basic ESD precautions
• Verify connector orientation and seating; do not force connectors onto pins
