Parts for Electrolux EW36IC60IB1: 03 - Induction Unit Parts

This ground wire connects an appliance's metal chassis to a designated grounding point to maintain a safe electrical path and help prevent shock hazards. It replaces a damaged or corroded grounding lead. What it does:

• Provides a secure electrical path from the appliance frame to the home ground
• Restores proper grounding if the original wire is broken, frayed, or has a loose terminal
• Helps stop intermittent shocks, arcing, or chassis voltage caused by a failed ground
• Prevents corrosion-related connection problems by replacing worn terminals

• Disconnect power at the breaker and unplug the appliance before starting any work
• Attach ring terminal to the appliance ground screw or chassis grounding point; tighten securely
• Route wire to avoid heat sources, moving parts, and sharp edges; secure with existing clips or fasteners

This small plastic clip secures the dishwasher drain hose to the pump assembly or discharge fitting, keeping the hose in place and helping prevent leaks or disconnection during operation. What it does:

• Holds the drain hose firmly to the pump or outlet fitting to maintain a watertight connection
• Prevents the hose from slipping free during drain cycles
• Helps stop water leaks and washing chamber flooding caused by a loose hose
• Useful when replacing a cracked or broken retaining clip

• One drain hose retaining clip

• Disconnect power and water supply before accessing the dishwasher lower access area
• Remove the access panel or kickplate to reach the drain hose and pump connection
• Use pliers or a flat tool to remove the old clip and snap the new clip over the hose/fitting until fully seated
• After installation, run a short drain cycle and inspect for leaks; re-secure if necessary

This main electronic control board manages the appliance's functions and user interface, restoring normal cycle selection and timed operations when the original board fails. Replaces a failed control to return reliable electronic control of the unit. What it does:

• Receives user commands and runs the appliance's operating cycles
• Controls timers, relays and display indicators for proper operation
• Common symptom: appliance won't start or respond to controls
• Common symptom: no or erratic display, or cycles stop unexpectedly
• Helps resolve issues caused by burned or shorted control circuitry

• Disconnect power before attempting any service to avoid shock or damage
• Handle the board by its edges and avoid static discharge; use anti-static precautions
• Verify the appliance model and part number before ordering and swapping parts

Specs: 10-32 X 0.375
