Parts for Ge JE740BK02: 05 - Interior Parts

This under-cabinet mounting kit provides the hardware needed to secure an appliance to the underside of a kitchen cabinet for a stable, finished installation. It's a replacement/optional kit for installations that require a dedicated mounting bracket set. What it does:

• Provides mounting brackets and hardware to fasten the appliance to the underside of a cabinet for added stability.
• Helps stop shifting, sagging, or vibration that can occur when an appliance isn't secured properly.
• Useful when original mounting hardware is missing, damaged, or when installing a new appliance in an existing cabinet opening.
• Designed as an optional accessory to match OEM mounting locations and attachment points.

• Disconnect power to the appliance before starting work and follow all safety instructions in the appliance manual.
• Fasten to solid cabinet framing or use appropriate anchors; use correct-length screws to avoid cabinet or appliance damage.

This suction guide is a molded guide/holder that positions the suction tube or hose in the appliance to help maintain correct routing and reliable flow. It reduces the chance of kinks and misalignment that can affect performance. What it does:

• Holds and positions the suction tube/hose so it stays properly routed
• Helps maintain consistent suction flow for ice/water systems
• Reduces risk of kinks or tube rubbing that can interrupt operation
• Can help address symptoms like reduced ice production, inconsistent water flow, or tube displacement
• Fits into the appliance where the original guide was mounted to secure tubing

• Disconnect power and water supply before starting any repair
• Remove any covers or panels necessary to access the suction tube; keep track of fasteners
• Slide the tube into the guide and secure per the original hardware; do not force or over-bend tubing

This replacement duct directs airflow inside the appliance to help channel heat, smoke and cooking odors out of the cavity for more consistent operation and safer use. Fits where the original duct is damaged or missing. What it does:

• Channels exhaust and airflow from the appliance cavity to the vent path
• Helps reduce heat buildup that can affect cooking performance
• Prevents smoke and odors from lingering inside the unit
• Restores proper airflow when the original duct is cracked, bent or deteriorated

• Disconnect power (and gas if applicable) before starting work to avoid shock or injury
• Basic hand tools typically required; keep screws and brackets for reassembly
• Handle sharp edges carefully and wear gloves
• Follow model-specific service instructions for access and mounting
