Lg 4738ER2005A Washer Door Boot Gasket (Bellows) OEM Part

Product Details

Genuine Lg part. See all items in Washer Dryer Combo Hose Or Tube and Washer Hose Or Tube.

Cross Reference Information

Part Number 4738ER2005A replaces AP5078822, 1330511, AH3523353, EA3523353, PS3523353.

Description

This washer door boot gasket (bellows) seals the opening between the outer tub and the front panel on front-load machines, keeping wash water inside the drum. Replace when the seal is torn, cracked, or leaking around the door.

• Forms a flexible, watertight seal between the tub and door opening
• Helps prevent leaks during fill, wash, and spin cycles
• Typical failure signs: water on the floor at the front of the washer
• Visible rips, cracks, or warping of the boot
• Drips or seepage from the door area after a cycle

What's included: 1 door boot gasket (bellows) Install notes:

• Unplug the washer and shut off water supply before servicing
• Remove the outer and inner retaining clamps and front panel as required by your model to access the boot
• Note the boot's orientation and alignment marks; match the same orientation on the new gasket
• Ensure the gasket lip is fully seated in the grooves; reinstall clamps evenly and securely
