Lg ADP36665705 Fan Assembly (Freezer Evaporator), 1 Assembly OEM Part

Product Details

Genuine Lg part. See all items in Refrigerator Blower Wheel Or Fan Blade.

Cross Reference Information

Part Number ADP36665705 replaces AP5974951, 4116760, PS11708063.

Description

This is the evaporator fan assembly that circulates cold air throughout the freezer and refrigerator sections for even cooling. Replacing a failed assembly restores proper airflow and temperature consistency.

• Draws air across the evaporator coils and distributes it through the cabinet
• Helps maintain stable, uniform temperatures and prevents warm spots
• Common failure symptoms: buzzing or grinding from the freezer, weak/no airflow, warming in fresh food section, frost buildup around the evaporator cover
• Fits in the freezer compartment behind the rear interior panel

What's included: One complete evaporator fan assembly (motor with fan blade and housing) Install notes:

• Disconnect power before servicing; sharp edges may be present behind the panel
• Remove shelves and rear freezer panel to access the assembly
• Transfer any grommets/insulators in the same orientation if reused
• After installation, verify fan operation and ensure no wires contact the blade

This part fixes the following symptoms

• Noisy
