Lg 4986ER0004E Door Boot Gasket (Bellow) OEM Part

Product Details

Genuine Lg part. See all items in Washer Gasket & Seal.

Cross Reference Information

Part Number 4986ER0004E replaces AP4439110, 1395154, AH3524976, EA3524976, PS3524976.

Description

This door boot gasket seals the gap between the washer tub and front opening to keep wash water contained. Replace a torn, cracked, or deformed boot to stop front leaks and restore a reliable door seal.

• Creates a flexible, watertight seal between the outer tub and door opening
• Helps prevent water leakage from the front of the washer during cycles
• Common failure signs: visible tears or cracks, water on the floor near the door, door not sealing properly
• Wear, sharp objects, or overloading can damage the gasket over time

What's included: 1 door boot gasket Install notes:

• Disconnect power and turn off water before servicing; wear gloves to protect hands from sharp cabinet edges
• Remove the outer spring clamp and peel the old boot from the front panel
• Access the inner clamp from inside the cabinet (front/top panel removal may be required); align index marks on the new boot and reconnect any small hoses/vents if present
• Seat the gasket evenly, reinstall both clamps, and run a short test to check for leaks
