Lg 4838JA2003E Water Tank (Refrigerator Reservoir) OEM Part

Product Details

Genuine Lg part.

Cross Reference Information

Part Number 4838JA2003E replaces AP5591924, 2649553, AH3635650, EA3635650, PS3635650.

Description

This refrigerator water tank holds a reserve of water inside the fresh food section so the dispenser delivers a steady, chilled flow. Replace the reservoir if it's cracked, leaking, or internally restricted.

• Stores and chills dispenser water inside the refrigerator
• Helps maintain consistent dispenser flow and pressure
• Damage can cause leaks under drawers or inside the fresh food compartment
• Kinks or blockages can reduce flow or stop water dispensing

What's included: One refrigerator water tank (reservoir). Install notes:

• Unplug the refrigerator and shut off the household water supply; dispense water to relieve line pressure.
• Access the tank behind the crisper/deli area; note tubing routing and connection points before removal.
• For push-to-connect fittings, depress the collar to release lines; cut tubing square and fully seat when reconnecting, then perform a gentle tug test.
• Restore water and power, check all connections for leaks, and purge air by dispensing water.
