Parts for Bosch B24IR70NSP/07: Lighting Assembly Parts

This active carbon filter refreshes the air when your range hood is set to recirculate. Replace a saturated filter to restore effective odor reduction and maintain a more comfortable cooking space. What it does:

• Adsorbs cooking odors in recirculating operation
• Helps maintain fresher indoor air when venting back into the room
• Restores odor-removal performance when the old filter is saturated
• Typical signs it's time to replace: persistent cooking smells or diminished odor reduction

• One activated carbon filter

• Disconnect power to the hood before servicing
• Remove the metal grease filter(s) to access the charcoal filter
• Release the old filter from its clips/bayonet mount and install the new filter in the same orientation until it locks
• Charcoal filters are not washable; replace when saturated

• For hoods configured for recirculation; not used when vented to the outdoors

This halogen oven light bulb replaces the interior lamp so you can clearly see inside your oven for cooking and cleaning. It restores oven illumination when the light is burnt out or dim. What it does

• Provides interior oven illumination for checking food and oven cavity condition
• Replaces a burned-out or flickering oven lamp
• Restores consistent brightness for safer monitoring of cooking progress
• Fits in compatible oven lamp sockets designed for halogen bulbs

• One halogen oven light bulb

• Turn power to the appliance off and allow the oven and old bulb to cool completely before replacing
• Use a cloth or gloves when handling the bulb to avoid skin oils on the glass, which can shorten bulb life
• Push or twist the bulb into the socket as required by your oven's lamp holder; do not force

This small replacement clip secures appliance components to restore proper fit and stop loose parts from shifting during use. It's a direct-fit replacement designed to hold trim, panels, or assemblies where the original clip failed. What it does:

• Holds small panels, trim pieces, or assemblies in place to prevent rattling and misalignment
• Restores the original mounting point so doors, drawers, or covers sit flush
• Helps keep wiring, hoses, or small parts secured and routed correctly
• Stops intermittent contact that can cause noise or wear on adjacent components

• One replacement clip

• Disconnect power and water before servicing
• Verify clip location and orientation against the existing fastener before removal
• Remove broken clip and press new clip into the same mounting slot; some clips may snap or slide into place

This support is a replacement mount bracket used to secure internal components and maintain proper alignment in the appliance. It restores stable support where a worn or broken bracket causes misalignment or movement. What it does:

• Provides structural support for internal assemblies to prevent sagging or shifting
• Helps keep racks, rails, or panels aligned for smooth operation
• Reduces noise caused by loose or damaged mounting points
• Restores correct part positioning that can affect performance or wear

• One support bracket

• Disconnect power and water to the appliance before starting any repair
• Use appropriate hand tools and handle sharp edges carefully
