Parts for Lg LSHD3089BD: Main Parts

This interior lamp is the replacement light assembly that restores interior lighting so you can see food and controls clearly. It fits as the OEM-design lamp used in compatible LG appliances. What it does:

• Provides interior illumination for ovens/microwaves or appliance compartments
• Helps you check cooking progress and read controls without opening doors
• Replaces dim, flickering, or burned-out lights
• Matches OEM fit and connection style for straightforward replacement

• Disconnect power before replacing the lamp to avoid shock risk
• Allow the old lamp to cool before handling; use gloves if needed
• Remove/replace per appliance service instructions; secure all connectors and housing fasteners

This is a replacement microwave turntable glass plate that supports food containers and helps ensure even heating. It restores a stable, rotating surface when the original plate is cracked or missing. What it does:

• Provides the flat, heat-resistant surface that rotates during microwave use
• Centers on the coupler to enable smooth, even turning of dishes
• Replaces cracked, chipped, or missing glass to prevent uneven cooking or messes
• Fits and functions as the OEM-designed glass plate for compatible microwave ovens

• One glass turntable plate

• Handle the glass carefully to avoid chips or cuts; wear gloves if needed
• Clean with mild detergent before first use; do not use if damaged
• Ensure the rotation coupler and support ring are properly positioned before installing the plate
• If the plate does not seat or rotate correctly, inspect the coupler and motor drive for wear

Metal mounting bracket secures internal panels or components. Replace if original is cracked, broken, bent, or missing to restore proper alignment.

This main control board power PCB assembly manages core electrical control and power distribution for the appliance, restoring control functions when the original board has failed. Designed as a direct replacement to return proper electronic control. What it does:

• Regulates power to motors, sensors and user controls so cycles run correctly
• Processes input from buttons, sensors and the user interface to control cycles
• Can stop erratic behavior caused by failed or burnt components on the board
• Commonly replaced when the appliance has no power, intermittent operation, or control errors

• Disconnect power to the appliance before starting work to avoid shock or injury.
• Handle the PCB by the edges and avoid static discharge; use an anti-static strap if available.
• Inspect connectors and wiring harness for damage and reconnect firmly; do not force mismatched plugs.

The Module Display PCB Assembly is an OEM component specifically designed for LG dishwashers. Housed within the electronic control panel, this printed circuit board routes signals between control buttons and the dishwasher module. Integrated circuits process commands to start cycles and display settings through LED indicators.

Causes of a bad module display PCB can include water damage into circuit paths, voltage fluctuations over time, or loose connections. Without a functioning interface, users are unable to select wash cycles or check cycle status.

Symptoms of a bad module display PCB include:

• Blank or unresponsive control panel
• Inoperable buttons and dials
• Erratic lights and buzzers during cycles
• Diagnostic error codes shown

This LG OEM replacement restores dependable controls. Compatible also with Kenmore Elite dishwasher models, it provides a direct fit and easy restoration of washing functions. Proper installation protects future operations while maintaining convenience.
