Parts for Dacor DRT304SLPH: Manifold Parts

A single aluminum low-pressure service valve that provides a sealed access point for refrigerant charging, evacuation and pressure checks. Designed to restore proper serviceability for refrigeration and sealed-system maintenance. What it does:

• Provides a dedicated, sealed port for connecting gauges and service equipment to the low-pressure side of the refrigeration system.
• Allows safe charging, evacuation and pressure testing during diagnostics and repairs.
• Helps isolate and reseal the system after service to prevent refrigerant leaks.
• Commonly used when a refrigerator or freezer needs refrigerant service or pressure verification.

• Intended for experienced technicians; refrigerant work should follow all local regulations and EPA/other certification requirements.
• Depressurize and recover refrigerant before removing or replacing the valve.
• Inspect and replace any sealing O-rings, fittings or gaskets as needed; torque to OEM specifications.
• Test for leaks and proper operation before returning the appliance to service.

This manifold service assembly routes water from the refrigerator supply to the dispenser and ice-making components, restoring proper water flow and reducing leaks when the original manifold is damaged or clogged. It fits the factory plumbing layout and connects to the existing lines. What it does

• Distributes incoming water to the dispenser and ice maker so they can fill and dispense properly
• Replaces cracked, leaking, or clogged manifold components that cause water leaks or weak/no water flow
• Helps stop intermittent filling issues that affect ice production or dispenser performance
• Restores factory water routing and seal points for reliable operation

• One manifold service assembly

• Shut off water supply and unplug the appliance before beginning work
• Turn off the ice maker and relieve line pressure before disconnecting plumbing
• Inspect O-rings, tubing and fittings; replace any damaged seals to prevent leaks
