Parts for Dacor EG486SCHNG: Manifold Parts

This LED socket assembly restores the high-intensity indicator lighting used on select cooktops to show an active cooking zone. Replace a failed module to bring back clear, consistent illumination. What it does:

• Provides bright LED illumination for a cooking zone indicator
• Restores visual feedback that a burner/zone is in use
• Replaces a failed or damaged LED socket/module
• Common symptoms: no light, dim or flickering light, intermittent operation, or physical damage

• One LED socket assembly

• Disconnect power at the breaker before servicing
• Allow the appliance to cool and protect the glass surface while working
• Access the module from beneath the cooktop; match connector orientation and mounting position
• Test illumination before final reassembly

This retaining ring secures the LED assembly in place, keeping indicator lights and display components stable for reliable operation. It's a small but important part that helps prevent loose or misaligned LED modules. What it does:

• Holds the LED assembly securely to the control/display area
• Prevents movement or rattling of indicator lights during operation
• Helps maintain proper alignment so LEDs remain visible and functional
• Can address symptoms like loose display trim, vibrating noises, or intermittently obscured LEDs

• Disconnect power before starting any repair to avoid shock or damage
• Handle the LED assembly and connectors gently to avoid breaking LEDs or wiring
• Use basic hand tools; avoid forcing the ring—align and snap into place per OEM guidance

This blue LED holder secures a blue indicator/lighting LED in place behind the control or panel, restoring stable illumination and correct LED positioning for visible status lights. What it does

• Holds and aligns a blue LED so the light displays correctly through the control or panel lens.
• Replaces broken, cracked, or melted holders that cause misaligned or non-visible LEDs.
• Helps stop LED wobble, intermittent contact, or shifting that can make lights dim or flicker.
• Fits into the OEM mounting location to maintain factory fit and light direction.

• Disconnect power before accessing controls or removing panels to prevent shock.
• Handle the LED and holder gently to avoid damaging the LED lens or leads.
• May require removal of the control panel or bezel; keep screws and small parts organized.
