Parts for Dacor ER30GISCHLP: Manifold Parts

A single aluminum low-pressure service valve that provides a sealed access point for refrigerant charging, evacuation and pressure checks. Designed to restore proper serviceability for refrigeration and sealed-system maintenance. What it does:

• Provides a dedicated, sealed port for connecting gauges and service equipment to the low-pressure side of the refrigeration system.
• Allows safe charging, evacuation and pressure testing during diagnostics and repairs.
• Helps isolate and reseal the system after service to prevent refrigerant leaks.
• Commonly used when a refrigerator or freezer needs refrigerant service or pressure verification.

• Intended for experienced technicians; refrigerant work should follow all local regulations and EPA/other certification requirements.
• Depressurize and recover refrigerant before removing or replacing the valve.
• Inspect and replace any sealing O-rings, fittings or gaskets as needed; torque to OEM specifications.
• Test for leaks and proper operation before returning the appliance to service.

This LED socket assembly restores the high-intensity indicator lighting used on select cooktops to show an active cooking zone. Replace a failed module to bring back clear, consistent illumination. What it does:

• Provides bright LED illumination for a cooking zone indicator
• Restores visual feedback that a burner/zone is in use
• Replaces a failed or damaged LED socket/module
• Common symptoms: no light, dim or flickering light, intermittent operation, or physical damage

• One LED socket assembly

• Disconnect power at the breaker before servicing
• Allow the appliance to cool and protect the glass surface while working
• Access the module from beneath the cooktop; match connector orientation and mounting position
• Test illumination before final reassembly

This retaining ring secures the LED assembly in place, keeping indicator lights and display components stable for reliable operation. It's a small but important part that helps prevent loose or misaligned LED modules. What it does:

• Holds the LED assembly securely to the control/display area
• Prevents movement or rattling of indicator lights during operation
• Helps maintain proper alignment so LEDs remain visible and functional
• Can address symptoms like loose display trim, vibrating noises, or intermittently obscured LEDs

• Disconnect power before starting any repair to avoid shock or damage
• Handle the LED assembly and connectors gently to avoid breaking LEDs or wiring
• Use basic hand tools; avoid forcing the ring—align and snap into place per OEM guidance

This thermal cut-off switch is a high-temperature safety device that interrupts power if the appliance overheats. Replacing a failed cutout restores proper overheat protection and can help address no-heat or shutdown issues caused by an open safety circuit.

• Monitors temperature at its mounting location and opens the circuit if temperatures exceed a safe limit
• A failed/open cutout can cause no heat, intermittent heating, or the unit shutting off during use
• Helps protect components from damage due to overheating
• Location varies by model; typically mounted to a bracket or surface near a heat source

• Disconnect power at the breaker or unplug the appliance before servicing
• Note wire orientation and transfer leads one at a time to the new switch
• Mount in the original position with firm, flush contact for accurate temperature sensing
• After replacement, inspect airflow/venting and nearby fans/filters to address any underlying overheating causes
