Parts for Frigidaire CPMC3085KF2: 05 - Microwave Parts

This capacitor kit replaces the start/run capacitor assembly for refrigerator compressors, helping the compressor start reliably so the appliance can cool properly. Use it to restore normal compressor operation when the capacitor has failed. What it does

• Provides the electrical boost the compressor motor needs to start and run
• Commonly used when the compressor hums but won't start or the fridge won't reach temperature
• Helps prevent repeated hard starts that can damage the compressor
• Works with the compressor's relay and overload to enable proper motor function

• One capacitor kit

• Disconnect power to the appliance before starting work to avoid shock
• Discharge capacitors before handling; capacitors can hold a charge after power is removed
• Access usually requires removing the refrigerator rear lower service panel; keep track of fasteners and wiring

Replace a failed light socket with this lamp assembly to restore reliable illumination inside your appliance. If your bulb is good but the light won't work or flickers, the socket assembly is a likely culprit.

• Holds the bulb and supplies power to illuminate the interior or work area
• Replaces cracked, heat-damaged, or loose sockets and terminals
• Helps resolve no light, intermittent flicker, or arcing at the socket
• Designed to fit the original mounting and wiring on compatible models

• Disconnect power before servicing to avoid electrical shock
• Allow the lamp and surrounding area to cool before handling
• Move wires to the new assembly one at a time to maintain correct connections
• Use the bulb type and wattage specified for your model; do not overtighten the bulb

This drive motor restores rotational power to the appliance's drum or agitator so loads spin and drain correctly. It's a direct-replacement motor designed to restore normal wash and spin cycles when the original motor fails. What it does:

• Provides the mechanical drive force for the washer drum/agitator so clothes tumble and spin
• Re-establishes proper agitation and spin speed control when a worn or failed motor causes no-spin or no-agitate symptoms
• Operates with the appliance's existing pulley, belt, or coupling
• Works as the core rotating component tied to load movement and draining functions

• One motor

• Disconnect power and water before beginning any repair; follow the appliance service manual for safe access
• Replacement typically requires removing cabinet panels, drive belt or coupling, and electrical connector—avoid forcing parts
• Inspect associated belts, couplings, and mounting hardware; replace worn items to prevent repeated failures

The Door Switch is an OEM replacement part for Frigidaire wall ovens. It is a component located on the oven door that detects when the door is opened and closed. The door switch works alongside the control board to regulate oven operations based on door position.

Symptoms of a bad door switch can include:

• Oven failing to automatically go into bake or warm modes after door closure
• Interior lights not turning on when the door is opened
• Control buttons/display remaining constantly lit instead of dimming
• Oven not heating or functioning properly in different modes

Causes relate to normal wear over extended use as the door switch mechanism cycles with frequent door openings and closings. Moisture exposure or impacts could also degrade switch performance.

This OEM Frigidaire switch is compatible with Amana, Jenn-Air, KitchenAid, and some Electrolux wall oven models as well.

This thermal fuse stops excessive heat by opening the circuit when temperatures get too high, protecting the appliance and its components. Replace a blown fuse to restore normal heating or safety shutdown functions. What it does:

• Acts as an over-temperature safety device to interrupt power when internal temps exceed safe limits
• Commonly linked to symptoms such as no heat, intermittent heating, or an appliance that won't start
• Prevents further damage by cutting power when a serious overheating condition occurs
• Functions as a single-use safety cutout—if it's open, it must be replaced

• One thermal fuse

• Disconnect power before testing or replacing; verify no voltage present
• Test continuity with a multimeter to confirm the fuse is open before replacing
• Replace with the same part number and rating; do not bypass or substitute with wire
• If the fuse failed, inspect the appliance for underlying issues before returning to service

The Magnatron is an OEM part for Frigidaire microwaves. It is the principal electronic component responsible for converting electrical energy into microwave radiation, allowing for fast and efficient cooking or heating of food.

Causes can be related to normal component fatigue over extended use. High voltage magnetron coils are also susceptible to power fluctuations or surges over time.

Symptoms of a faulty magnatron include:

• Inability of the microwave to transmit energy and heat foods
• Slow or ineffective cooking times
• Oven light working but no microwave output
• Overheating, arcing or burning smells from the unit

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This replacement motor restores the rotation your appliance relies on to move air or drive a mechanism, bringing normal operation and performance back when the original motor has failed or become noisy. What it does:

• Converts electrical power into controlled shaft rotation to drive the associated component
• A failing motor may cause no movement, intermittent operation, or unusual humming/grinding noises
• Can contribute to reduced performance if the driven part doesn't run as intended
• May present with overheating smell or visible signs of wear on the old unit

• One motor

• Disconnect the appliance from power before servicing
• Note wire locations and connector orientation; transfer any brackets, grommets, or hardware from the old motor
• Handle sheet-metal edges carefully; wear cut-resistant gloves
• After installation, confirm the shaft spins freely by hand before restoring power and testing

Control transformer that supplies the low-voltage power needed for the appliance's electronic control/console, restoring reliable operation when the original transformer fails or the display and controls lose power. What it does:

• Converts incoming line voltage to the low-voltage supply used by the control board and console.
• Keeps the display, touchpad/keys and control electronics powered and stable.
• Common symptoms of a failing transformer: unlit or blank display, unresponsive controls, intermittent operation, or control board power loss.
• Replace a visibly burned, cracked, or shorted transformer to prevent further electrical damage.

• Always disconnect power to the appliance before servicing to avoid electric shock.
• Take care with wiring: match original connector positions and secure all wire nuts/terminals.
• Inspect mounting hardware and insulation; replace any damaged fasteners or wires.

This replacement power cord restores mains power to compatible Frigidaire appliances, providing a safe, factory-style connection for reliable operation. Use it when the original cord is damaged or not supplying power. What it does:

• Replaces a worn, frayed, or damaged power cord to restore electrical connection
• Provides the appliance's main AC connection so controls, heating, and motors can operate
• Helps resolve symptoms such as intermittent power, no power to the appliance, visible cord damage, or exposed wiring
• Matches the OEM form and function for a direct-replacement fit when the part number is correct

• One replacement power cord

• Disconnect power at the breaker or unplug the appliance before installing
• Route and secure the cord per manufacturer instructions; tighten terminal connections to proper torque

This temperature sensor (thermistor probe) monitors internal refrigerator temperatures and sends readings to the control board so cooling cycles respond correctly. Replacing a faulty sensor helps restore accurate temperature control and more consistent cooling. What it does:

• Senses cabinet temperature and provides a variable resistance signal to the control board
• Allows the refrigerator to cycle the compressor and fans based on actual temps
• Commonly linked to symptoms like temperature fluctuations, overcooling or warming, long run times, or cooling-related error codes
• Works as the temperature feedback element for fresh food/freezer systems

• Disconnect power to the appliance before starting any repair
• Handle probe and connector wiring carefully—do not kink or overly bend the sensor element
• Route and secure wiring per service manual or parts diagram to avoid contact with moving parts or heat sources

This outer cabinet provides the refrigerator's main exterior housing, restoring structural support and the appliance's finished appearance. Replaces a damaged or dented outer shell to help maintain proper component alignment and fit. What it does:

• Forms the refrigerator's outer housing and supports internal components and panels
• Protects internal parts from damage, dust, and moisture
• Restores proper alignment and mounting for doors, trim, and internal assemblies
• Addresses symptoms like visible dents, loose or misaligned panels, rattling, or gaps around the cabinet

• Disconnect power and remove food before beginning any repair
• This heavy panel may require two people and basic hand tools to remove and install
• Keep mounting hardware and insulation in place or transfer from the old cabinet as instructed by the service manual

This latch hook engages the door catch/lock on your appliance to keep the door securely closed. Replacing a worn or broken hook restores proper latching so cycles can start and run reliably. What it does:

• Engages the mating latch/strike to hold the door shut
• Ensures the door switch/lock is satisfied so the appliance can operate
• Helps prevent the door from popping open during use
• Common symptoms: door won't stay closed, must push/slam to start, "door open" errors, intermittent stopping

• 1 latch hook

• Disconnect electrical power before servicing; allow any hot surfaces to cool
• Wear cut-resistant gloves; edges and panels can be sharp
• Transfer and reuse original screws/fasteners if not supplied
• After installation, verify door alignment and latch engagement; inspect the mating strike/lock if the issue persists

The Door Release Lever is an OEM part for Frigidaire microwaves. It facilitates the smooth opening of the microwave door by engaging the latch mechanism when the door release button is pressed, ensuring convenient access to the microwave cavity.

Causes of a bad door release lever can include regular wear and tear, exposure to heat, or physical damage from forceful operation.

Symptoms of a bad Microwave Door Release Lever include:

• Difficulty opening the microwave door
• The door not latching properly or remaining ajar
• The door release button not functioning correctly
• Unusual resistance or noises when opening the door

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This replacement cover restores a clean, secure fit over an opening on your appliance, helping shield internal components from dust, moisture, and debris. Replace a damaged or missing cover to maintain proper protection and appearance. What it does:

• Shields internal parts from grease, dust, and debris intrusion
• Helps maintain proper airflow and component protection as designed
• Reduces vibration or rattling from loose or broken panels
• Restores a finished, factory look when the original is cracked or missing

• 1 cover

• Disconnect power to the appliance before servicing
• Note fastener locations and orientation for correct reinstallation
• Reuse original screws/clips unless your unit specifies otherwise
• Use gloves and caution—panel edges and surrounding metal can be sharp

This bushing guides and supports a rotating shaft to reduce wear and keep moving parts aligned, restoring smooth, quiet operation. Fits specific Frigidaire appliances—use the OEM part number to fit for your model. What it does

• Supports a rotating shaft or drum to prevent metal-on-metal contact
• Reduces friction and wear that can cause squeaks, grinding, or rough rotation
• Helps maintain proper alignment for consistent appliance performance
• Commonly replaces worn or damaged bushings that allow excessive play

• Disconnect power before servicing and access the affected assembly per your model's service manual
• Remove the worn bushing and any debris; press or tap the new bushing into place squarely
• Inspect mating shaft/surface for scoring or wear; replace or repair if damaged
• Use only OEM-recommended lubricants if specified by the manufacturer; do not assume grease is required

This replacement electrical wire restores a damaged or faulty connection in compatible Frigidaire appliances, helping re-establish reliable power or signals to components. Use it when wiring is cracked, melted, or showing corrosion. What it does:

• Replaces a worn or damaged single conductor wire used in internal appliance circuits
• Restores continuity to fix intermittent power, component failure, or nonfunctional controls
• Prevents shorts caused by exposed or frayed insulation when installed correctly
• Matches OEM routing and connection points when used with the original harness and terminals

• Disconnect power before inspecting or replacing any internal wiring
• Verify wire routing and terminal fit with the original part; secure with appropriate connectors or clips
• Do not splice with incompatible gauge or insulation types; follow appliance wiring diagrams

This support assembly secures and stabilizes an appliance component to the cabinet or frame, restoring proper alignment and reducing vibration. Ideal when a broken or worn support causes movement or instability of the affected area. What it does:

• Provides structural mounting to keep panels, controls, or other components properly aligned.
• Reduces vibration, rattling, or visible sagging caused by a failed or loose support.
• Restores reliable attachment after damage, deformation, or worn mounting points.
• Matches OEM diagram locating for direct-replacement fit when replacing the faulty part.

• Disconnect power and unplug the appliance before starting any repair.
• Follow the OEM diagram for correct placement and fastener locations.
• Use appropriate hand tools and wear gloves to avoid sharp edges; inspect surrounding mounting hardware and replace if damaged.

The Turntable Tray is an OEM part for Frigidaire microwaves. It sits inside the microwave and rotates food to ensure even cooking and heating. Made of durable glass, this tray is designed to withstand high temperatures and the repetitive motion of the microwave's turntable motor.

Damage can occur due to accidental drops, placing heavy items on the tray, or thermal stress from repeated heating cycles.

Symptoms of a bad turntable tray include:

• Cracks or chips on the glass surface
• Unstable or wobbling movement during operation
• Inability to rotate smoothly
• Food not heating evenly

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This replacement appliance label provides the factory identification and safety information fastened to the appliance so you can read model/serial and safety/warning text clearly. It restores legible markings for servicing and ownership records. What it does

• Shows the appliance identification, model/serial or rating area and factory safety/warning text so technicians and owners can service data.
• Helps ensure required safety and operating instructions remain visible and readable.
• Replaces a torn, faded, or missing label that can make identification and troubleshooting harder.
• Supports accurate parts ordering and service by restoring the original markings.

• One replacement label

• Peel-and-stick replacement; clean and dry the surface thoroughly before applying.
• Align carefully and press from one edge to the other to avoid bubbles; firm pressure ensures adhesion.
• Do not stretch or trim the label unless explicitly specified by the equipment instructions.
• For safety, disconnect power or follow manufacturer safety precautions before working near electrical components.

This is a replacement screw used to secure appliance components and panels so assemblies stay stable and aligned. It provides a straightforward fix when a mounting fastener is missing, stripped, or damaged. What it does

• Secures panels, brackets, or trim to prevent movement and vibration
• Stops rattling or loose parts caused by missing or damaged screws
• Restores proper fit and alignment of the affected assembly
• Works wherever the OEM-designated screw of this size and thread is required

• Turn power off or unplug the appliance before working on electrical areas
• Use the proper-size driver to avoid stripping the head
• Start threads by hand, then tighten until snug — do not overtighten
• If the original screw is corroded or the hole is damaged, inspect mating parts for repair before installing

This #10-32 x 3/4-inch machine screw secures appliance components such as panels, brackets, and handles. Using the correct length and thread helps restore a snug, rattle-free hold wherever this screw is specified by the manufacturer.

• Fastens components with a #10-32 machine thread and 3/4-inch length
• Helps keep panels, trim, brackets, or handles secured and aligned
• Replaces missing, stripped, or corroded hardware
• Common signs include loose or wobbly parts, rattling, missing screws, or damaged screw heads/threads

• Disconnect power before servicing; if working near a water connection, shut off the water supply
• Use the correct driver/bit and start threads by hand to avoid cross-threading
• Tighten snugly; do not overtighten to prevent stripping plastic or threads
• Reuse any model-specific washers or spacers if present
