Parts for Ge JE520WC001: 01 - Microwave Parts

This HVC bracket is a small mounting support that secures the HVC assembly and related components in place, restoring stable alignment and preventing vibration or misrouting of ducting and wiring. It's a direct-fit replacement designed to match the original mounting points. What it does:

• Supports and secures the HVC assembly to the appliance frame
• Keeps ducts, wires, or vents properly aligned to prevent rubbing or pinching
• Reduces rattling and vibration from loose or shifted components
• Helps restore correct airflow routing and component positioning

• One HVC bracket

• Disconnect power to the appliance before beginning any repair
• Access may require removing exterior panels or the control housing; keep fasteners organized
• Use common hand tools (screwdriver, nut driver) and avoid overtightening mounting fasteners
• Watch for sharp sheet-metal edges and work with gloves as needed

This is a replacement power cord assembly for electric ranges and ovens. It provides a direct electrical connection from the house supply to the appliance so your range receives safe, reliable power. What it does:

• Replaces a damaged or worn range/oven power cord to restore power delivery
• Prevents intermittent power loss caused by frayed wires or loose connections
• Eliminates burning smells, arcing, or visible wire damage from a failed cord
• Ensures a secure connection at the appliance terminal block

• Always disconnect household power at the breaker before inspecting or replacing the cord
• Inspect the terminal block and mounting bracket; replace any damaged hardware before installing

This high-voltage rectifier diode is used in the microwave's high-voltage circuit. It converts AC to DC so the magnetron can produce heat. A failed diode can cause no heat, loud humming, or a blown fuse when starting. What it does:

• Rectifies high-voltage AC to DC to power the magnetron
• Blocks reverse voltage in the HV circuit
• Common failure symptoms can include: runs but doesn't heat; loud hum then shutdown; line fuse blows at startup

• 1 high-voltage diode

• Unplug the microwave and properly discharge the high-voltage capacitor before servicing—dangerous voltage can remain even when unplugged
• Match diode orientation/polarity to the original and ensure a solid chassis ground connection where used
• Route leads and reinstall any clamps/insulators exactly as found; keep wiring clear of sharp edges and hot components
• If the original diode failed, inspect the HV capacitor and transformer for related issues before reassembly

The Monitor Switch is an OEM replacement part for GE microwave ovens. Located internally on the turntable control circuit board, this switch monitors rotation of the turntable during cooking cycles.

Causes of failure involve degradation of the electrical contacts from continuous arcing loads over years of use combined with vibration stresses.

Symptoms of a faulty monitor switch include:

• The turntable no longer rotates or spinning intermittently
• Cooking cycles aborting prematurely with error messages
• Screeching or grinding noises emanating from beneath cavity
• Visible burnt spots on turntable drive assembly

This genuine GE switch is also compatible with select Hotpoint and RCA models.

The Microwave Door Switch is an OEM part for GE microwaves, designed to prevent the microwave from operating when the door is open by interrupting the power whenever the door is not securely closed. The door switch is an essential safety feature.

Symptoms of a failing Microwave Door Switch include:

• The microwave not starting or heating
• Running when the door is opened
• Unusual noises when the door is closed

Causes of a bad Microwave Door Switch can result from repeated opening and closing of the door or slamming that can cause the switch to degrade or become misaligned, leading to intermittent or failure.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

Round glass microwave tray, 10 7/8 inches in diameter.

The Fuse is an OEM part for GE microwaves. It serves as a safety device designed to protect the microwave from excessive current that can cause overheating and potential fire hazards. When the current flowing through the microwave circuit exceeds a certain level, the fuse blows or breaks, cutting off the power to prevent damage or fire.

Common causes for a fuse to blow include power surges, faulty wiring within the appliance, or the use of microwave inappropriate containers that cause sparks. It is essential to address these issues not only to replace the fuse but also to correct the underlying problems to prevent future failures.

Symptoms of a bad fuse include:

• The microwave suddenly stops working.
• No signs of power or response even when the microwave door is closed and the start button is pressed.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This door film is the outer overlay used to restore the finished surface of the appliance door and improve appearance after scratches, peeling, or wear. It provides a clean, uniform look without replacing the whole door. What it does:

• Covers worn, scratched, or peeling door finish to restore a uniform appearance
• Acts as the replaceable outer surface for cosmetic repairs
• Helps prevent further cosmetic deterioration of the door exterior
• Matches the original part's fit and shape for a flush finish when installed correctly

• One outer door film

• Clean and dry the door surface thoroughly before installation to ensure proper adhesion and fit
• Align the film carefully before final placement; repositioning can damage the adhesive or film
• Use only manufacturer-recommended tools and methods
