Mtd 946-0916 Clutch Cable OEM Part

Product Details

Genuine Mtd part. See all items in Tiller Control Cable.

Cross Reference Information

Part Number 946-0916 replaces AP6149997, 1843186, 746-0916, PS9168115.

Description

This is a durable rubber clutch cable that is used on lawn and garden tillers. It is used to connect the drive system to the clutch control arm in the equipment. It is an important component that controls the clutch to engage the machine. Over time, the clutch cable can break or become damaged and will need to be replaced. If a visual inspection shows that the clutch cable is broken, the first step is to remove the clutch handle. Take out the bolt on the cover plate for the arm. Take the old cable off of the handle and remove the cover plate. Loosen the screws so the old clutch cable can be removed. Remove the screws on the cover over the clutch and belt. Take off the old cable and attach the new one to the clutch. Tighten the screws and reassemble the parts and make adjustments before using the new cable.This clutch cable is a genuine OEM replacement component sourced directly from the manufacturer. It is sold as an individual part. This cable is compatible with tillers manufactured by MTD, Huskee, MasterCut, and Yard Machines.
