Mtd 748-04069A Deck Lift Pivot Cup OEM Part

Product Details

Genuine Mtd part.

Cross Reference Information

Part Number 748-04069A replaces AP6530071, 4522167, 748-04069, PS12087457.

Description

This deck lift pivot cup is an authentic OEM replacement part sourced directly from the manufacturer for use on riding lawnmower decks. This pivot cup separates the hex lock nut and the lift arm so that the arm can move freely while being secured to the deck. If the pivot cup is damaged or broken, the lift arm would not be able to move, and the deck would not be adjustable up and down. Regular maintenance and inspection will reveal problems with parts like the pivot cup, which can then be repaired. If the deck is not moving freely, the pivot cup should be checked and replaced if necessary. Park the mower on a flat surface and take the spark plug out for safety. Remove the deck mower and remove the blades. Locate the lift arm and the hex nut. Remove the hex nut and set it aside. Remove the damaged pivot cup and then insert the new one. Replace the hex nut and tighten it. Reverse the process to reassemble the lawnmower. This deck lift pivot cup is a metal part that is sold as a single unit. It is designed for use on lawn mowers and lawn tractors manufactured by MTD, Murray, and Craftsman.
