Parts for Whirlpool MT1195SGQ0: 05 - Oven Interior, Literature Parts

This propeller is the small impeller that mounts to the dishwasher circulation pump to move wash water through the spray arms for effective cleaning. Replacing a worn or damaged propeller restores proper water flow and wash performance. What it does:

• Spins on the pump shaft to circulate wash water through the spray arms
• Restores normal water flow when a cracked or stripped propeller reduces circulation
• Helps resolve symptoms such as poor cleaning, weak spray, or inconsistent water movement
• Works with the pump motor; does not include the motor or pump housing

• Disconnect power and water supply before beginning any repair
• Access the pump assembly from the dishwasher base or cabinet front per your model service instructions
• Inspect the pump shaft and seal for wear; replace damaged components to prevent repeat failure
• Reassemble carefully and test operation

This electrical safety fuse opens the circuit when a short or overcurrent occurs. Replacing a blown fuse can help restore power after the root cause is corrected, protecting controls and wiring from further damage.

• Protects the appliance by interrupting power during overcurrent or short-circuit events
• When open/blown, the appliance may be completely unresponsive
• Helps prevent damage to control boards and wiring during faults
• Often fails after a component shorts or a power surge occurs

• Disconnect power to the appliance before servicing
• Use a multimeter to test the fuse for continuity; replace only if open
• Install a fuse with the exact same rating and form factor as the original
• If the new fuse blows again, stop and diagnose the underlying fault; consider service for high-voltage systems

Fastener screw
