Parts for Bosch NITP666SUC/01: Pcb Assembly Parts

This operating module is the electronic control that manages dishwasher functions and the user interface, restoring proper cycle selection and responsive controls when the original module fails. What it does:

• Receives input from the control panel and starts, stops, or advances wash cycles
• Regulates cycle timing and communicates status to the display/LEDs
• Can cause unresponsive or erratic controls, failed cycle starts, or missing/displayed error codes when faulty
• Interfaces with other control components to coordinate wash functions

• Disconnect power to the appliance before beginning any work to avoid shock or damage
• Handle the module carefully; avoid static discharge and do not touch exposed circuitry
• Inspect connectors and harnesses for damage and ensure proper seating during reassembly
• Test appliance operation after installation.

This flexible exhaust air hose routes vented air from the appliance to the household vent, restoring proper airflow and preventing leaks. Use it when the original hose is cracked, collapsed, or not sealing correctly. What it does:

• Directs exhaust air from the appliance to the home vent to maintain proper ventilation
• Restores airflow when a damaged hose causes reduced venting or longer run times
• Helps stop air leaks that can cause heat buildup, moisture, or unwanted noise
• Keeps the vent path sealed when secured with proper clamps

• Disconnect power and gas before servicing the appliance.
• Remove the old hose, note routing, and slide the replacement into place without kinking.
• Secure both ends with appropriate clamps; confirm a snug, leak-free fit.

A small chassis knockout protector that shields wiring and components where factory knockout holes are removed. Helps prevent wire abrasion and keeps openings tidy for safe appliance operation. What it does:

• Fits into a chassis knockout to protect wiring from sharp sheet-metal edges
• Helps prevent cable chafing and short circuits by covering exposed openings
• Keeps out debris while allowing routed harnesses to pass through the cabinet
• Commonly used where service or modifications require a sealed knockout

• One chassis knockout protector

• Install by pressing the protector into the knockout until it seats securely
• Ensure wiring is routed through the protector and not pinched between metal edges
• Disconnect power before servicing appliance to avoid shock or injury
