Parts for Briggs & Stratton 135200-135299 (7003): Piston Assembly Parts

This precision-drilled burner orifice is sized for Type 4 butane applications. It meters gas to the burner so flames ignite reliably and burn cleanly when the appliance is configured for butane per the manufacturer's specifications. What it does:

• Regulates gas flow to the burner head for proper flame size and shape
• Type 4 drilling intended for butane gas configurations specified by the manufacturer
• Replaces a missing or stripped orifice during service or gas-type conversion

• 1 burner orifice (Type 4, butane)

• Shut off gas supply and power; allow the appliance to cool before service
• Access the orifice at the burner base/manifold; remove the original with the correct wrench or socket
• Start threads by hand; tighten snugly—avoid overtightening or cross-threading
• After reassembly, leak-check with soapy water and verify flame; gas conversions should be performed following OEM instructions and local codes

A pack of ten 10-32 x 5/8 inch pan head Phillips machine screws with zinc finish, used to fasten appliance panels, brackets, and components. Durable, service-grade screws for routine appliance repairs and reassembly. What it does:

• Secures panels, trim, brackets and internal components where 10-32 machine screws are specified.
• Replaces missing or stripped screws that cause loose panels or rattling.
• Restores proper fit and alignment after service or component replacement.
• Zinc plating helps resist corrosion in normal household conditions.

• Ten 10-32 x 5/8 in pan head Phillips machine screws with zinc finish.

• Use the correct size Phillips driver to avoid cam-out and head damage.
• Start screws by hand to ensure proper thread engagement; do not cross-thread.
• Tighten snugly but avoid overtightening to prevent stripping threads or damaging parts.
• Disconnect power and follow appliance safety procedures before servicing.
