Parts for Mtd Gold 12AVB2J1704 / 2012: .Quick Reference 12Axb2x Parts

This control cable is a mower part that works with the control handle or lever bar that engages the wheels. It is also known as choke cable, brake cable, choke control, and control assembly cable. The inner wire total length is 53 inches, and the cable casing or conduit length is 40 inches. The control cable can stretch over time and it will result in a mower that moves forward slower than usual. A cable that's too corroded won't be capable of moving the drive lever. A broken or cut cable won't make the mower move. Here is a manufacturer-approved replacement control cable that's easy to install. A genuine OEM replacement part, this control cable is made to fit specific models of walk-behind mowers from Bolens, Ryobi, MTD, Troy-Bilt, and Yard-Man. It is sold individually.

This is a small engine spark plug positioned in the engine cylinder head. It supplies the spark that will ignite the air-fuel mixture to enable an engine to produce power. This particular spark plug is designed with superior corrosion resistance and dependable performance. Small but mighty, this component allows for increased conductivity and heat control. If the spark plug is damaged or in poor condition, many problems may arise in equipment, including sudden stop while running, overheating, and excessive gas consumption. Replace the spark plug by disconnecting the spark plug wire first, then use a socket driver or wrench to remove the spark plug. Install the new spark plug by turning it by hand initially to avoid cross-threading. If it doesn't twist anymore, use a deep socket wrench or socket driver to tighten the plug until snug. The spark plug can also be used to tune up outdoor power equipment or improve a small engine. This part is recommended to be replaced once per season. This part works with lawn mowers, snowblowers, tillers, leaf blowers, log splitters, wood chippers, and others with small engines. It is compatible with brands such as Craftsman, Cub Cadet, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Bolens, Yard-Man, and MasterCut. This is a genuine OEM part directly from the manufacturer and is sold individually.

This is a complete wheel assembly for walk-behind and push lawnmowers. It is a single replacement wheel for the front wheels on a mower. Wheels may be damaged by impact with hard objects or from exposure to the elements over time. When the wheel is visibly damaged or otherwise does not roll as well as it should, it should be replaced.If the user is having difficulty pushing the walk-behind lawn mower, a visual inspection of the wheels will determine if a new part is required. Replacing a wheel on a lawn mower is simple. Tools including a socket set, pliers, and a screwdriver may be necessary to perform the repair.This wheel is a genuine OEM replacement part. It is compatible with MTD, Troy-Bilt, and Yard-Man machines. It is sold as an individual unit. The wheel is made of durable plastic.

This is a simple set of lawnmower ignition keys. They’re also used for an array of riding mowers, lawn tractors, and even snowblowers. To simplify repair and replacement procedures, most manufacturers use standardized keys for all their machines in a given class. As a result, a single key can be used for dozens of machines. The keys are manufactured from stainless steel, with an INDAK logo stamped into the center. Regardless of whether the machine is a walk-behind mower or a full-sized lawn tractor, a keyed ignition is easier to operate than a recoil cord. Similarly, replacing a key is generally straightforward. The exception is if the old key has snapped off in the ignition. In this case, a set of needle-nosed pliers can sometimes be used to extract the key. A powerful magnet can also be helpful if the broken key is being stubborn. In the worst-case scenario, the ignition may need to be replaced. This is an OEM part sourced directly from MTD, and it is sold as a set of two.

A fuel cap assembly is a component often seen on lawnmowers and other lawn and garden equipment. It is made of durable black plastic and is used to ensure that fuel doesn’t spill out of the fuel tank. Over time, fuel cap assemblies can begin to wear out and cause problems. Sometimes this results in a cap that doesn’t tighten all the way or there may be a fuel smell when using a lawnmower or snowblower. If fuel is leaking, the cap doesn’t fit right, or the cap seems damaged, it’s best to replace it with a new component. This is a simple process that involves removing the original fuel cap assembly and fitting the new assembly to the lawn machine. This fuel cap assembly is a genuine OEM component that comes directly from the manufacturer. It is an individual part that is compatible with MTD, Murray, Cub Cadet, Bolens, Yard-Man, and Yard Machines lawnmowers, snowblowers, chipper shredders, and tillers. No tools are required to replace this component.

Fuel filters are created to strain out gas before it reaches the carburetor in lawnmowers and other gardening tools. Located in the fuel line or the fuel tank, it prevents unwanted debris from reaching the carburetor, which can cause engine damage. If the fuel filter is damaged or becomes clogged with material, it no longer offers the same protection to the carburetor. This can lead to difficulty starting the lawnmower and decreased performance. Correcting this issue early can prevent damage that might require a new lawnmower. Maintenance of the lawnmower by adding fuel stabilizer, changing the oil, and replacing the air filter will increase the life of lawn care equioment. Even if no issues are present, the fuel filter should be replaced after about 200 hours of use. Disconnecting the spark plug should be done prior to installing a new fuel filter. This fuel filter is a genuine OEM component directly from the manufacturer and comes as an individual part. It can be used with various Craftsman, Cub Cadet, Murray, Yard Machines, MTD, Huskee, Bolens, Yard-Man, and Mastercut lawnmowers, tillers, blowers, and wood chippers.

This replacement part is an adapter assembly. This is a genuine replacement part made by MTD. This adapter assembly piece is able to connect different parts so that the entire machine is able to work together and run smoothly and efficiently. A new adapter assembly might be needed if the current one is damaged in any way including being bent, dented, cracked, or chipped. It is also possible that this part can become stripped due to normal wear and tear. Be sure the engine is completely shut down before attempting to replace the adapter assembly. Work gloves are also recommended to protect the hands during any repair or replacement.This adapter assembly is sold individually and is sourced directly from the manufacturer to ensure proper fit. This part is a genuine OEM replacement part for long-lasting use.

This is a Briggs & Stratton Original Equipment 491588S Air Filter Cartridge. The purpose of this filter is to prevent dirt, dust, and debris from contaminating the carburetor and damaging the engine. This flat panel style, pleated paper air filter provides the first line of defense against the destructive effects of dirt ingestion. It is designed for 3.5 through 6.75 HP quantum engines and 625-1575 series engines. Over time, the air filter can get clogged or damaged, and this can lead to reduced engine performance. Locate the air filter cover, unscrew it, and remove the old filter. Make sure to clear out any debris that has found its way into the air filter assembly before inserting the new cartridge. Reattach the air filter cover and secure it with the screws. This replacement part works with generators, lawnmowers, pressure washers, wood chippers, and tillers. Aside from Briggs & Stratton, it is also compatible with specific products from Craftsman, Husqvarna, Lawn-Boy, Toro, Troy-Bilt, Simplicity, Snapper, and Wheel Horse. It is a genuine OEM replacement part and is sold individually.

This is a replacement belt for self-propelled lawn and garden equipment. The belt is responsible for turning the axle that rotates the wheels when the self-propelled action is engaged. Over time, the belt can become worn with regular use. it should be replaced every season for optimal operation. There may also be instances where the belt breaks or becomes damaged and needs immediate replacement to avoid further damage. Without a working belt, the self-propelled function will not work. This genuine OEM v-belt is designed for use with a variety of 21-inch walk-behind lawn mowers and snow throwers. This belt is made of durable composite rubber material and reinforced for longer life with premium compression materials. Be careful when replacing belts and other tension parts as pinching and crushing injuries are common. Always allow the engine to cool and disengage the spark plug for safety.

The blade support is found between the blade and the bolt. As its name suggests, it is designed to provide support for the blade to ensure it is secured to the base of the mower deck. It is made of metal and it will need a replacement if it becomes worn or damaged. To replace a blade support or blade spacer, first, the engine needs to be cool. Remove the wire and boot from the spark plug. Tip the mower back on its handle assembly and use a piece of wood or sturdy object to hold the cutting blade in place. Remove the old blade support and blade. When installing the new one, ensure that the blade's sharp edge faces away from the mower deck. Re-thread and torque the bolt between 40 and 50 ft-lbs. This is an original OEM replacement part for lawnmower blade support made by Craftsman, Cub Cadet, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Bolens, Yard-Man, MasterCut. It is sold individually.

Installing a brand-new air filter keeps the engine in top running condition. When the machine is in operation, the vacuumed air goes through the air filter. Any dirt or dust is left in the filter media. Over time, the filter will become dirty and can no longer provide the same filtering efficiency as before. If left ignored, the tiny particles could clog the engine and the carburetor. You may experience misfires and no engine start-up. An air filter replacement is cheap and easy to do. Simply remove the air cleaner cover and take out the dirty filter. Insert the new filter into the housing. This replacement will take less than 5 minutes. A screwdriver will be needed. The MTD 951-10298 Air Cleaner Kit is a genuine air filter from MTD. Each kit comes with one paper filter and one foam filter. The foam filter can be cleaned with water and detergent. The paper filter, however, needs replacement at least once a year. This air filter kit is compatible with Cub Cadet, PowerMore, and Troy-Bilt. It can also work with other garden equipment like wheel string trimmers, chipper-shredder vacuums, and log splitters.

This fuel filter is a genuine MTD part, sold individually. This fuel filter can be used as a replacement part for lawn mowers, snowblowers, pressure washers, generators, tillers, log splitters, lawn tractors, and wood chippers. The purpose of the fuel filter is to prevent the accumulation of external materials such as dirt, debris, and pebbles from entering the fuel line.If the fuel filter is punctured, torn, scraped, or eroded to the point that external materials can pass through it and enter the fuel line and the fuel tank, the component must be removed and replaced with this genuine OEM replacement part. Remember to always wear gloves when handling, repairing, and operating outdoor equipment. This is an OEM part sourced directly from the manufacturer. It is sold individually. This fuel filter is compatible with the following outdoor appliance brands: MTD, Briggs & Stratton, Toro, Cub Cadet, Murray, Wheel Horse, Lawn Boy, Snapper, and Simplicity.

Designed for comfortable mowing, this trail shield attaches to walk-behind lawnmowers. It secures to the back of the deck on the lawnmower and prevents grass and other debris from reaching the person using the mower. This trail shield is made of durable plastic but can become damaged use. If it is broken, it will not be able to keep grass from collecting behind the mower deck, so it will need to be replaced.To replace the part with a new shield, put the lawnmower on a stable surface and ensure it is powered off. On the original trail shield, find the metal clasps that hold it secure. Unclasp each of these and remove the trail shield from the lawnmower. The new replacement part can be attached and the lawnmower will operate correctly.This trail shield is an authentic OEM replacement part that is directly sourced from the manufacturer. It is an individual component and does not come with hardware. The part is compatible with lawnmowers by MasterCut, Craftsman, Yard-Man, Cub Cadet, Bolens, Troy-Bilt, Huskee, Murray, MTC, and Yard Machines.

This replacement part is a hex bolt. It is a genuine replacement part made by MTD. Hex bolts are named because they are shaped like a hexagon and are different from the regular circle-shaped bolts. These parts are able to hold other parts secure and in place so that everything can operate as needed. A new hex bolt might be needed if the current ones are damaged in any way. It is possible that these bolts become stripped or lodged in place over time due to normal wear and tear and should be replaced. The repair should be fairly easy, only requiring a screwdriver or pliers if the previous part is stuck. Be sure the engine is completely powered down before beginning this repair. This bolt is sold individually. Be sure to purchase the correct amount as many appliances require more than one. This is a genuine OEM replacement part sourced directly from the manufacturer.

A side discharge chute is engineered to move the debris away from the machine's underside. This is because grass that is not only long and thick but also moist can get trapped and clog the deck and the blades. When this happens, you will have to stop to clear the accumulated clippings periodically. To mitigate clogging and maximize cutting, using a side discharge chute is ideal. When a side discharge chute is installed, but clogging still occurs, there might be a problem with the chute itself. It can be torn or already loose. Luckily, installing a brand-new side discharge chute is easy and will take less than 5 minutes. Start the installation by removing the spark plug. The engine should be cool to the touch. Then, lift and hold the mulch cover up. Take the brand-new side discharge chute and hook the tabs on to the hinge pins. Then, release the mulch cover. MTD manufactures this brand-new side discharge chute. It is an original replacement with Craftsman, MTD, Murray, Yard-Man, Yard Machines, Bolens, Huskee, and Mastercut lawnmowers. It comes in solid plastic material with a black finish. This side chute is sold individually.

A mulching blade has a unique curved or angled design that allows discharging, bagging, and mulching. If its edges are already dull, it can lead to longer mowing time and frayed and torn grass blades. Mulching blade installation is easy. First, unplug the spark plug wire. Then, position the lawnmower on its side. Get a woodblock, preferably 6 x 2 in size, and put it between the old blade and housing deck. Make sure that the wood will prevent the old blade from moving. Take a socket wrench and remove the blade’s nut and washer. Remove the old blade and put the new mulching blade in. Put the nut and washer back and tighten until it is secured. You can use the woodblock to prevent the replacement blade from moving when it is tightened. This mulching blade replacement s an original MTD product. This OEM mulching blade can be used for MTD, Craftsman, Cub Cadet, Murray, Yard-Man, and Bolens lawnmower models. This brand-new mulching blade is sold individually. The support blade and screw hex are sold separately.
