Parts for Craftsman 247.203703 / 2015: .Quick Reference Parts

This blade is used for lawn tractors. It is attached at the base of the mower deck, and it serves as the part of the machine that cuts the grass. When it is engaged, it spins to cut through the grass.The blade could become damaged in any number of ways. The user could have come too close to a stump or a rock, which could have bent or cracked the blade. The blade could even be broken. Blades that have been used for several seasons could also be damaged from normal wear and tear or corrosion. Corrosion can often be a problem if the blades are not cleaned properly. Replacing the blade is relatively easy. A wrench is needed to replace the blade.The lawn tractor blade will work with several models of tractors from MTD and Yard Machines. It is a genuine OEM replacement blade sourced from the manufacturer and is sold individually.

This oil filter wrench is a genuine MTD part, sold individually. This oil filter wrench can be used as a replacement part in a lawn mower or a log splitter. The purpose of an oil filter wrench in a lawn mower or a log splitter is to access and remove an oil filter that is deeply recessed and cannot be removed by hand without a supplemental component.The oil filter wrench might have to be ordered as a new component or as a replacement part in an oil filter wrench that has suffered damage to the point of reduced or no efficacy. If the oil filter wrench has been chipped, cracked, dented, warped, or eroded to the point that it cannot access the oil filter or if the operator does not own an oil filter wrench, this oil filter wrench should be ordered as a genuine OEM part.This is a genuine OEM replacement part sourced directly from the manufacturer. It is sold individually. This oil filter wrench is compatible with the following outdoor appliance brands: MTD, Craftsman, Cub Cadet, Murray, Yard Machines, Huskee, Bolens, Yard Man, and MasterCut.

This replacement part is a fuel cap and is intended for use in different types of lawn equipment. This is a genuine replacement part made by MTD. The fuel cap is one of the most important tools in many lawn devices. This part is connected with a wire to the body of the machine, and ensures that the fuel cap does not go missing. The fuel cap is able to attach to the device and seals the fuel tank shut. This is so that no fuel leaks during use.A new fuel cap might be needed if the current one is damaged, broken, or missing from the wire that connects it to the machine. Be aware that while replacing the fuel cap the device can leak fuel. To ensure a swift clean-up, have a towel handy or perform the repair outside. This replacement part is a genuine OEM part and is sourced directly from the manufacturer.

This actuator spring is a genuine MTD part, sold individually. This actuator spring can be used as a replacement part in a lawn mower. The purpose of the actuator spring, also known as a seat spring switch, in a lawn mower is to provide a plate upon which the seat switch can conduct its electrical current while being held stably in place.If the actuator spring slides out of place and cannot be reinstalled or if it is bent, broken, dented, or worn beyond repair, it should be removed and replaced by this genuine OEM replacement part.Sourced directly from the manufacturer, this component is a genuine replacement part that is sold individually. This actuator spring is compatible with the following outdoor appliance brands: MTD, Craftsman, Toro, Cub Cadet, Ryobi, Troy-Bilt, Yard Machines, Huskee, Montgomery Wards, Bolens, Yard Man, Turf King, and MasterCut.

This is a spring switch that is used in many types of lawn and garden equipment, such as log splitters, lawnmowers, and tillers. The spring switch is made out of durable metal and is typically located near the switch button. With ordinary use, the spring switch can experience wear or other types of damage and stop working correctly. When this occurs, it will need to be replaced.If the spring switch is broken or bent, a screwdriver will be needed to replace it. The lawn equipment should be powered off and placed on a stable surface during the replacement. Disassemble the unit and locate the contacts to access the spring switch and other small parts. The original switch can be removed using a screwdriver so the new component can be installed. Reassemble and power the tool on before use.This spring switch is a genuine OEM replacement part that is sourced directly from the manufacturer. The component is sold on an individual basis. The part is made to be compatible with lawnmowers, snowblowers, tillers, log splitters, and wood chippers manufactured by Craftsman, Toro, Cub Cadet, Ryobi, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Montgomery Wards, Bolens, Yard-Man, MasterCut, and Turf King.

This replacement part is a hand-held oil pump, and it is intended for use in different types of lawn equipment. This is a genuine replacement part made by MTD. This oil pump is small and portable and is able to assist the user during oil changes in their lawn mowers. Oil changes are a normal part of maintenance for many lawn mower models and this oil pump will facilitate that.A user might require a new oil pump if the old one is damaged. This part with the lawn mower at purchase, so it may need to be purchased after the fact. It makes changing the oil inside of the engine very easy.This hand-held oil pump is sold individually and is a genuine OEM replacement part sourced directly from the manufacturer. This device can come in handy for those looking to change the oil in their lawn mowers.

This is a small engine spark plug positioned in the engine cylinder head. It supplies the spark that will ignite the air-fuel mixture to enable an engine to produce power. This particular spark plug is designed with superior corrosion resistance and dependable performance. Small but mighty, this component allows for increased conductivity and heat control. If the spark plug is damaged or in poor condition, many problems may arise in equipment, including sudden stop while running, overheating, and excessive gas consumption. Replace the spark plug by disconnecting the spark plug wire first, then use a socket driver or wrench to remove the spark plug. Install the new spark plug by turning it by hand initially to avoid cross-threading. If it doesn't twist anymore, use a deep socket wrench or socket driver to tighten the plug until snug. The spark plug can also be used to tune up outdoor power equipment or improve a small engine. This part is recommended to be replaced once per season. This part works with lawn mowers, snowblowers, tillers, leaf blowers, log splitters, wood chippers, and others with small engines. It is compatible with brands such as Craftsman, Cub Cadet, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Bolens, Yard-Man, and MasterCut. This is a genuine OEM part directly from the manufacturer and is sold individually.

This is a two in one blade that can be used as a lift blade to bag clippings, as well as a side discharge for clippings. It is time to consider replacing this blade when there are uneven or even missed areas of cutting or bagging when using the mower. It may be that the blade has been dulled by prolonged use or bent or damaged by striking rocks and dense roots. Either way, replacing the blade is a relatively easy repair to make and should be considered a part of routine maintenance. The repair requires the use of the proper tools, including wrenches and sockets. An appropriate flange bolt may need to be purchased as well if the original has been damaged or worn. "This OEM replacement cutting blade works with more than 150 types of tractors and mowers made by Craftsman, Yard Machines, Yard-Man, MTD, and Troy Bilt. This ships singly and is a high-quality blade made of durable materials.

This part is a spindle pulley assembly that is used on lawn tractors. The spindle pulley assembly includes the mandrel, the shaft, and the pulley. The spindle is the post to which the blade attaches to and spins when the lawn tractor is being used.A new spindle pulley assembly may be needed if the original is missing from a new lawn tractor. If any component of the spindle pulley assembly is cracked, damaged, or broken, the entire spindle pulley assembly will need to be replaced. Remember to wear gloves when operating or performing care and maintenance on any outdoor power equipment. Never perform care and maintenance on outdoor power equipment that is powered on.This spindle pulley assembly is a genuine MTD part. It is sold individually. This particular spindle pulley assembly is compatible with lawn tractors that are manufactured by MTD, Troy-Bilt, Yard Machines, Husky, and Murray.

A V-belt is used on riding lawn mowers and yard tractors to turn the blades and the accessories of these power tools. The engine pulley, which supplies power, is connected to the cutting deck pulley, which turns the mower blades, with a V-belt. Over time the V-belt, which is made of rubber, may stretch, calling for the tension on the belt to be adjusted. Eventually the belt will wear to the point that it no longer turns the cutting deck pulley fast enough for the blades to cut grass. Sometimes the belt will crack with dry rot and break. In any of these instances, the solution is to replace the V-belt. In order to replace the V-belt, the cutting deck must be lowered completely. A worn belt will likely slip off the cutting pulley with little resistance. In case the belt is missing, the user will find a diagram with the proper V-belt routing on top of the cutting deck. When replacing the V-belt, make sure to use a genuine OEM replacement part such as this one, which is manufactured to be an exact replacement for the original. This V-belt is compatible with riding mowers from MTD, Murray, Huskee, Troy-Bilt, Yard Machines, and Yard Man.

This authentic OEM replacement ball joint assembly is a part of the front suspension of a lawn tractor or riding mower. Suspensions are complex systems that include joints, bushings, and bearings that must all work together to turn and maintain contact with the ground. This ball joint assembly helps to connect all of these components. It works similarly to a human hip in that it has a joint and a ball that allows for pivot motions. The most common reason for a ball joint assembly to go bad is if it loses lubrication or becomes gritty. In order to work smoothly, these joints must stay well oiled or else they will grind and break. If the ball assembly breaks, use a wrench to disengage the wheel and change out the part. This is a fairly straightforward repair and should not take more than a few minutes. This replacement assembly is a high-quality part for Cub Cadet, Huskee, MTD, Yard Machines, Murray, Troy-Bilt, Bolens, Ryobi, and Yard Man machines. This part is sourced from the original parts manufacturer and ships individually.

This part is a replacement starter solenoid. This is a genuine OEM part made by MTD and has been sourced directly from the manufacturer. This part can be used to replace a defective or damaged solenoid in a variety of lawn tractor models.When the engine's ignition is turned on, the starter solenoid routes the electricity generated by the battery to the engine starter. This part will eventually need replacing if damaged or with regular equipment use. A wrench and screwdriver will be required to replace this part. It is always recommended that the appropriate safety precautions are adhered to when attempting to fix any power tools or machinery. When working on or near to an engine, ensure the equipment is powered off and completely cooled down before starting any repairs. For more accurate information on how and where to install this starter solenoid, the appropriate owner's manual and included diagrams should be referenced.As an authentic replacement part, this solenoid is suitable for use on several different models of lawn tractors manufactured by MTD, Troy-Bilt, Yard Machines, Cub Cadet, and Husky. This is a genuine part made of high-quality, durable materials and is sold individually.

This is a sponge filter that is used in several types of lawn and garden equipment. It helps remove dirt, dust, and other debris before it can reach the engine. If the sponge filter is dirty, damaged, or otherwise not working correctly, debris can end up clogging the carburetor, which will weaken performance or prevent it from starting completely. If the dust and dirt reach the engine, serious engine damage can occur.Inspecting the sponge filter on a regular basis is important to ensure it's working well. It also needs to be replaced at least annually, and possibly more often depending on wear and tear. Replacing the air filter is simple. Take off the lid on the filter and then remove it from the machine. Replace it with the new sponge filter and replace the lid.This is a genuine OEM replacement part that is directly sourced from the manufacturer. It is sold as an individual part. The sponge filter is compatible with lawnmowers, lawn tractors, and wood chippers manufactured by Craftsman, Huskee, Cub Cadet, MTD, and Yard Machines.

This fuel filter is a genuine MTD part, sold individually. This fuel filter can be used as a replacement part for lawn mowers, snowblowers, pressure washers, generators, tillers, log splitters, lawn tractors, and wood chippers. The purpose of the fuel filter is to prevent the accumulation of external materials such as dirt, debris, and pebbles from entering the fuel line.If the fuel filter is punctured, torn, scraped, or eroded to the point that external materials can pass through it and enter the fuel line and the fuel tank, the component must be removed and replaced with this genuine OEM replacement part. Remember to always wear gloves when handling, repairing, and operating outdoor equipment. This is an OEM part sourced directly from the manufacturer. It is sold individually. This fuel filter is compatible with the following outdoor appliance brands: MTD, Briggs & Stratton, Toro, Cub Cadet, Murray, Wheel Horse, Lawn Boy, Snapper, and Simplicity.

This air filter consists of an internal plastic frame with a foam mesh cover that captures dust and dirt. The outer, washable pad covers an accordion-style inner filter that removes even finer particles. An air filter keeps particles in the air from getting sucked into the motor, where friction will cause wear and tear to the engine. However, a filter has a limited life cycle. Eventually, it gets clogged up, which leads to limited airflow and decreased efficiency. If the engine is bogging down when it is revved up, a clogged air filter might be to blame. Simply install a new air filter and see if the motor performance improves. It is recommended to preemptively replace the air filter every spring so a clogged filter never puts a halt to a job in progress. This is an OEM part, sourced directly from MTD, and it is sold individually. In addition to MTD lawn equipment, it has also been used by other manufacturers, including Craftsman, Yard Machine, and Yard-Man.

When interlock switches are working properly, they will keep the engine from starting if there is no foot is not on the brake or if the parking brake is not set. When the switch breaks, it will not allow current to reach the starter even when the brake is on, which means the engine will not start. If the solenoid is not clicking when the ignition key on the tractor or mower is turned, the interlock switch is likely to blame. This is a genuine OEM replacement interlock switch that can help get a lawn tractor up and running again. Is is compatible with riding tractors and mowers from many different brands, including Craftsman, Bolens, Yard Machines, Yard-Man, MTD, and Troy-Built.

The nut-hex flange 5/8-18 features a hex nut with a wide flanged portion at one end. This flange will act as an integrated washer that does not spin. Since the flange acts as a washer, it ensures that the nut can fasten to the material's surface evenly. If any of these nuts are removed from a machine to do other work, it is recommended to replace them with a new nut-hex flange. Check the nuts that are currently on the machine at least once a year. Make sure they are properly tightened and that they are in good condition. Replace them as needed. This OEM part will work for many types of equipment, including lawnmowers, edgers, snowblowers, and lawn tractors. The part will work with many brands, including Ryobi, Poulan, Bolens, Yard-Man, MTD, Yard Machines, and Troy-Bilt.

This is an oil filter designed to fit a variety of small, gasoline-powered motors used primarily on lawn equipment. This genuine OEM replacement filter removes contaminants that otherwise would wear down the internal working parts of the engine. While the filter works very well, it should be replaced annually as a part of regular maintenance. Depending on use, the filter may need to be replaced more often. When replacing the oil filter, the crankcase oil must be drained and safely discarded as well. To remove oil from the gasoline engine, start the engine and let it run for a couple of minutes. This circulates the oil and heats the internal engine parts so oil is better able to drain. Next, remove the drain plug located on the bottom of the oil pan and collect the oil. Remember to dispose of the oil safely where it cannot contaminate streams or aquifers. Once the oil has been removed, remove the old filter and discard it properly. The new filter should only be hand-tightened in place as using a wrench may cause the filter gasket to seal to the engine block. This filter will fit Yard Machine mower engines and MTD equipment.
