Parts for Yard-Man 12A-B29Q701 / 2013: .Quick Reference Parts

A fuel filter is designed to ensure that the fuel flowing into an engine is as clean as possible. When combined with an effective air filter, this dramatically improves engine durability. In general, a fuel filter should be replaced during a small engine’s annual maintenance cycle. This is true whether the filter is inside a lawnmower, snowblower, or another small engine. Symptoms of a failed fuel filter include stalling, particularly when the throttle is fully open. A clogged fuel filter can also be checked visually. If it’s cloudy or there are particles are inside, it needs to be replaced. If there is visible rust during this process, check the fuel can and gas tank for any rust on the inside. Discard any bad gas and replace it with fresh gasoline. Initially, this fuel filter was used for MTD snowblowers. Since then, it’s been used by several other manufacturers, including Briggs & Stratton, Cub Cadet, Yard Machines, and Honda. This is an OEM filter sourced directly from MTD, and it is sold individually.

A fuel tank cap assembly prevents contaminants and particles from entering the gas tank and causing problems with the carburetor or engine. The cord between the insert and the fuel cap is meant to prevent the loss of the fuel cap. However, over time the cord can wear out and break. The threads on the cap can also become worn down or swell from heat. When this occurs, consider replacing the fuel tank cap assembly. The replacement job is easy and should not need any tools, except maybe some vice grips to remove the old fuel tank cap assembly. This fuel tank cap assembly will work in conjunction with many different types of lawn and garden maintenance equipment. Most have a small engine, like lawnmowers, tillers, and log splitters. Some of this equipment is produced by the brands Craftsman, Cub Cadet, Honda, Huskee, Lawn-Boy, Mastercut, MTD, Murray, Troy-Bilt, and Yard Machines. It is a genuine OEM part.

This cover is a genuine MTD part, sold individually. This cover can be used as a replacement part in a lawn mower. This cover helps to protect the mower from exposure to dust and the elements.If the cover is punctured, ripped, torn, or otherwise leaves the lawn mower exposed, the cover should be replaced by this genuine OEM replacement part. Remember to always wear gloves when handling, repairing, and operating outdoor equipment. Always unplug the appliance before performing any kind of repair or replacement.Sourced directly from the manufacturer, this component is a genuine replacement part that is sold individually. This cover is compatible with the following outdoor appliance brands: MTD, Craftsman, Cub Cadet, Murray, Yard Machines, Huskee, Bolens, Yard Man, and MasterCut.

This replacement part is a hand-held oil pump, and it is intended for use in different types of lawn equipment. This is a genuine replacement part made by MTD. This oil pump is small and portable and is able to assist the user during oil changes in their lawn mowers. Oil changes are a normal part of maintenance for many lawn mower models and this oil pump will facilitate that.A user might require a new oil pump if the old one is damaged. This part with the lawn mower at purchase, so it may need to be purchased after the fact. It makes changing the oil inside of the engine very easy.This hand-held oil pump is sold individually and is a genuine OEM replacement part sourced directly from the manufacturer. This device can come in handy for those looking to change the oil in their lawn mowers.

This 21-inch extreme blade is an OEM replacement part for select lawn mowers. Routine blade maintenance is an important part of owning a lawnmower. With regular sharpening and care, this durable blade made of high-quality metal should last for a long time. However, the blade can still become dull with regular use or damaged by hitting concrete or other objects. If the cutting as it should, replace it immediately for safety and effective operation. This OEM blade offers a greater cutting surface and extreme cutting power for compatible machines. Installing the blade is simple and only requires a wrench. Disconnect the spark plug for safety before accessing the mower deck. Always wear gloves when working on blades or engine components. This extreme blade replacement is designed for use with various MTD lawnmowers, as well as models from Troy-Bilt, Yard Machines, Yard-Man, and Craftsman. This blade is sold individually.

This MTD 17211-ZL8-023 Air Cleaner is used in lawnmowers to help prevent dirt, dust, and other debris from contaminating the carburetor and damaging the engine. A lawnmower's air filter is typically housed in a plastic or metal case and usually mounted on top of the engine. It comes in paper, foam, or a combination of the two. The foam filter can be cleaned with water and detergent, while the paper filter requires replacement at least once a year. If the air filter is clogged or dirty, the engine may not start or may run rough. In this case, the filter needs to be replaced to breathe new life into the engine. Regular maintenance is essential and installing a new air filter can help keep the engine running in top condition. Aside from lawnmowers, this MTD air cleaner can be used in log splitters, pressure washers, generators, and tillers. It is also compatible with other brands like Briggs & Stratton, Craftsman, Cub Cadet, Honda, Huskee, Lawn-Boy, MasterCut, Toro, Troy-Bilt, Murray, Yard Machines, and Yard-Man. It is an OEM part sourced directly from the manufacturer and is sold individually.

This grass catcher frame holds the grass-catching bag, which captures grass clippings for compost or simply to remove yard waste. Bagging rather than mulching allows grass to get higher and thicker without putting added stress on the mower. The internal grass catchers frame can become bent and not suitable for further use, making it impossible to bag clippings until it is replaced. This OEM replacement handle is the answer for mowers made by these manufacturers: Bolens, Murray, Mastercut, Troy-Bilt, Yard Machines, Craftsman, Yard-Man, and Cub Cadet. This OEM part is sold individually.

This is a replacement lawn mower wheel that can be used with select walk-behind lawn mowers. The lawn mower wheel helps keep the deck off of the ground and provide an easy way to maneuver the machine. Wheels are made of durable plastic, but they can wear or become dented or otherwise damaged from impacts with rocks and stumps, or even just with regular use. A broken, crooked, or otherwise damaged wheel is going to affect the ability to maneuver the mower. In some cases, it may prevent operation completely. Replacing the wheel with a genuine part like this will resolve the issue. This OEM lawn mower wheel is manufactured by MTD. It can be used with lawn mowers from MTD, Craftsman, Huskee, Yard Machines, and Yard Man. The wheel is made of durable plastic and attaches to the axle on the lawn mower. This unit is just the wheel and the hardware required to secure it will be sold separately. Those who need multiple wheels will have to purchase additional quantities. Always be sure to disconnect the spark plug before working on the deck of the lawn mower and wear gloves for hand safety.

The blade support is found between the blade and the bolt. As its name suggests, it is designed to provide support for the blade to ensure it is secured to the base of the mower deck. It is made of metal and it will need a replacement if it becomes worn or damaged. To replace a blade support or blade spacer, first, the engine needs to be cool. Remove the wire and boot from the spark plug. Tip the mower back on its handle assembly and use a piece of wood or sturdy object to hold the cutting blade in place. Remove the old blade support and blade. When installing the new one, ensure that the blade's sharp edge faces away from the mower deck. Re-thread and torque the bolt between 40 and 50 ft-lbs. This is an original OEM replacement part for lawnmower blade support made by Craftsman, Cub Cadet, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Bolens, Yard-Man, MasterCut. It is sold individually.

This part is a replacement drive cable. This is a genuine OEM part made by MTD and has been sourced directly from the manufacturer. It can be used to replace a broken or malfunctioning drive cable in a variety of different lawnmower models.The drive cable is important for proper equipment control, as it stops the engine when the operator presence handle is released. Over time, drive cables can become stretched, worn, broken, or detached, which can be dangerous and thus they should be immediately replaced. When working on or near an engine, ensure the equipment is powered off and completely cooled down before starting any repairs. For more accurate information on how and where to install this drive cable, the appropriate owner's manual and equipment diagrams should be referenced. As an authentic replacement part, this drive cable is suitable for use on several different models of lawnmowers manufactured by MTD, Yard Man, Yard Machines, Troy-Bilt, and Husky. Please note that this is a genuine part made of high-quality, durable materials and is sold individually.

Designed for comfortable mowing, this trail shield attaches to walk-behind lawnmowers. It secures to the back of the deck on the lawnmower and prevents grass and other debris from reaching the person using the mower. This trail shield is made of durable plastic but can become damaged use. If it is broken, it will not be able to keep grass from collecting behind the mower deck, so it will need to be replaced.To replace the part with a new shield, put the lawnmower on a stable surface and ensure it is powered off. On the original trail shield, find the metal clasps that hold it secure. Unclasp each of these and remove the trail shield from the lawnmower. The new replacement part can be attached and the lawnmower will operate correctly.This trail shield is an authentic OEM replacement part that is directly sourced from the manufacturer. It is an individual component and does not come with hardware. The part is compatible with lawnmowers by MasterCut, Craftsman, Yard-Man, Cub Cadet, Bolens, Troy-Bilt, Huskee, Murray, MTC, and Yard Machines.

This replacement part is a hex bolt. It is a genuine replacement part made by MTD. Hex bolts are named because they are shaped like a hexagon and are different from the regular circle-shaped bolts. These parts are able to hold other parts secure and in place so that everything can operate as needed. A new hex bolt might be needed if the current ones are damaged in any way. It is possible that these bolts become stripped or lodged in place over time due to normal wear and tear and should be replaced. The repair should be fairly easy, only requiring a screwdriver or pliers if the previous part is stuck. Be sure the engine is completely powered down before beginning this repair. This bolt is sold individually. Be sure to purchase the correct amount as many appliances require more than one. This is a genuine OEM replacement part sourced directly from the manufacturer.

A side discharge chute is engineered to move the debris away from the machine's underside. This is because grass that is not only long and thick but also moist can get trapped and clog the deck and the blades. When this happens, you will have to stop to clear the accumulated clippings periodically. To mitigate clogging and maximize cutting, using a side discharge chute is ideal. When a side discharge chute is installed, but clogging still occurs, there might be a problem with the chute itself. It can be torn or already loose. Luckily, installing a brand-new side discharge chute is easy and will take less than 5 minutes. Start the installation by removing the spark plug. The engine should be cool to the touch. Then, lift and hold the mulch cover up. Take the brand-new side discharge chute and hook the tabs on to the hinge pins. Then, release the mulch cover. MTD manufactures this brand-new side discharge chute. It is an original replacement with Craftsman, MTD, Murray, Yard-Man, Yard Machines, Bolens, Huskee, and Mastercut lawnmowers. It comes in solid plastic material with a black finish. This side chute is sold individually.

A mulching blade has a unique curved or angled design that allows discharging, bagging, and mulching. If its edges are already dull, it can lead to longer mowing time and frayed and torn grass blades. Mulching blade installation is easy. First, unplug the spark plug wire. Then, position the lawnmower on its side. Get a woodblock, preferably 6 x 2 in size, and put it between the old blade and housing deck. Make sure that the wood will prevent the old blade from moving. Take a socket wrench and remove the blade’s nut and washer. Remove the old blade and put the new mulching blade in. Put the nut and washer back and tighten until it is secured. You can use the woodblock to prevent the replacement blade from moving when it is tightened. This mulching blade replacement s an original MTD product. This OEM mulching blade can be used for MTD, Craftsman, Cub Cadet, Murray, Yard-Man, and Bolens lawnmower models. This brand-new mulching blade is sold individually. The support blade and screw hex are sold separately.
