Parts for Ge ZDP48N6RH2SS: 03 - Racks & Glides Parts

These burner base screws secure the burner base to the cooktop or range chassis, keeping burners stable for safe, even cooking. They replace worn or missing fasteners and restore proper burner alignment and support. What it does:

• Fastens the burner base to the appliance chassis to keep the burner assembly stable.
• Prevents burner wobble and uneven heating caused by loose or missing screws.
• Helps maintain correct burner-to-surface clearance for safe ignition and operation.
• Works with standard cooktop/range burner bases that use machine screws for attachment.

• Turn off power and gas to the appliance and allow all surfaces to cool before servicing.
• Use the correct screwdriver or nut driver to avoid stripping the screw head.
• Tighten screws securely but avoid over-torquing; replace any damaged screw holes or mounting hardware.

The Broiler Pan Kit is an OEM part for GE ranges. It serves as a secure platform for positioning meats, vegetables, and various foods directly beneath the broiler element, ensuring safe and efficient cooking. The pan is about 17 inches wide by 13 inches deep.

Over time, wear and tear can affect broiler pans, causing issues such as flaking or stripping of the non-stick coating and the development of small ridges or holes that permit grease to drip down.

Symptoms of bad broiler pans include:

• Grease fires caused by dripping grease contacting the heating element
• A burnt or smoky flavor transferring to foods
• Difficulty removing baked-on grease and food deposits
• Pans that are misshapen or developing small cracks

This OEM GE replacement part is also compatible with select Hotpoint, RCA, and some Kenmore ranges

This 27" oven broiler pan provides a durable tray for broiling and catching drips, helping keep the oven interior cleaner and supporting even heat under foods. Fits ovens requiring a full-width broiler pan. What it does:

• Catches grease and drippings while broiling to reduce flare-ups and simplify cleanup
• Supports food close to the broiler element for even browning and searing
• Restores proper fit and function when the original broiler pan is damaged, warped, or missing
• Works with standard 27" oven broiler systems designed for full-width pans

• One 27" oven broiler pan (single pan only)

• Slide into the broiler/grate position; no special tools required for most installations
• Ensure the oven is cool and disconnected from power before handling or cleaning
• Inspect for proper fit and stable seating before use; do not use if warped or cracked
• Clean according to oven manufacturer guidelines; avoid abrasive cleaners that could damage finish

Restore clear visibility inside your oven with this halogen lamp assembly. It replaces a failed light unit so you can monitor cooking progress through the door without opening the oven or losing heat.

• Provides bright interior lighting when the oven light is switched on or the door is opened
• Replaces a burned-out or heat-damaged lamp/socket assembly
• Helps you check doneness without interrupting cooking
• Common symptoms include: light not turning on, intermittent flicker, or visible damage/discoloration to the assembly

• Disconnect power at the circuit breaker and allow the oven to cool completely before servicing
• Handle the halogen capsule with clean gloves; avoid touching the glass
• Seat the assembly securely and route wiring as originally installed
• Test light operation before reassembling any covers or panels
