Parts for Thermador T24IR70FSS-01: Refrigerator Section Parts

This active carbon filter refreshes the air when your range hood is set to recirculate. Replace a saturated filter to restore effective odor reduction and maintain a more comfortable cooking space. What it does:

• Adsorbs cooking odors in recirculating operation
• Helps maintain fresher indoor air when venting back into the room
• Restores odor-removal performance when the old filter is saturated
• Typical signs it's time to replace: persistent cooking smells or diminished odor reduction

• One activated carbon filter

• Disconnect power to the hood before servicing
• Remove the metal grease filter(s) to access the charcoal filter
• Release the old filter from its clips/bayonet mount and install the new filter in the same orientation until it locks
• Charcoal filters are not washable; replace when saturated

• For hoods configured for recirculation; not used when vented to the outdoors

The Defrost Heater is an OEM part for Bosch refrigerators. Strategically placed at the rear of the freezer compartment, it quickly removes frost and ice during automatic defrost cycles. The defrost heater utilizes precisely regulated currents to raise temperatures temporarily and expel moisture.

Causes of a bad defrost heater may involve failures due to regular heating and cooling over countless cycles. Mineral or ice deposits can restrict filaments or warp sensitive components within.

Symptoms of a bad defrost heater include:

• Frost buildup despite automatic defrost mode being set
• High energy bills indicating excess run-time to fully defrost
• Warm areas detected behind removable freezer panels
• Risk of frost and condensation dripping onto stored items

Replacing your malfunctioning heater ensures even temperatures throughout. This genuine Bosch part restores frost-free convenience and maintains cooling efficiency. It is compatible with some Thermador, Gaggenau, and Kenmore models.

This operating module is the control panel interface that accepts user input and communicates commands to the appliance's main control. Replacing a faulty module restores button/selector responsiveness and proper cycle selection. What it does:

• Receives button and knob inputs from the user and forwards commands to the main control
• Powers and drives the display/indicator lights so cycle status is visible
• Enables selection and start of wash/dry cycles; failure can cause unresponsive controls or no cycle start
• Helps resolve intermittent or permanent control-panel faults, erroneous error codes tied to the panel interface

• Disconnect power to the appliance before beginning work to avoid shock or injury
• Handle the module and ribbon/connector gently to avoid damage to fragile contacts
• Reuse existing mounting hardware unless damaged; confirm connectors are fully seated before testing

This fan motor restores airflow by replacing a worn or failed blower motor in compatible Bosch appliances. Install to address noisy operation, weak air movement, intermittent spinning, or loss of ventilation so the unit can cool and ventilate properly. What it does:

• Drives the appliance fan/blower to circulate air for cooling, venting, or evaporator circulation.
• Common symptoms it can fix: loud grinding or squealing, little or no airflow, fan not spinning, or intermittent fan operation.
• Operates with the appliance's existing wiring harness and mounting locations when used as the correct OEM replacement.
• Replacing the motor often resolves overheating, frost buildup, or poor performance caused by reduced airflow.

• Disconnect all power to the appliance before starting any repair.
• Follow for panel removal and motor replacement; keep track of screws and mounting hardware.
• Note the wiring harness orientation and connector positions before disconnecting; reconnect exactly as removed.
• Handle the fan blades and motor shaft carefully to avoid damage; test the appliance after reassembly to confirm proper operation.

This is an electrical on/off switch used to control power to an appliance circuit. It replaces a failed switch so controls respond normally and the appliance can be powered on and off safely. What it does

• Opens and closes an electrical circuit to enable or disable appliance power or a specific control function
• Commonly replaces a worn, stuck, or unresponsive switch that prevents controls or lights from operating
• Can resolve symptoms like no power to a control, intermittent operation, or a button that won't actuate
• Designed to mate with the appliance's existing wiring and mounting points

• One electrical on/off switch

• Disconnect power to the appliance at the breaker or unplug before working on wiring
• Verify proper wire locations and secure all terminal connections; replace only with the exact part specified by the manufacturer
• Handle the part carefully to avoid bending terminals or damaging the switch actuator

This insulating part provides thermal and electrical isolation for internal appliance components to help prevent heat transfer and protect wiring and nearby parts from electrical contact. It replaces a worn or damaged insulator to restore safe separation. What it does:

• Shields wiring and terminals from direct contact with metal components to reduce risk of shorting or arcing
• Limits heat transfer between adjacent parts to help components run within intended temperature ranges
• Helps secure and position small components or harnesses inside the appliance
• Common symptom: visible melted, cracked, or missing insulation near wiring or control areas
• Common symptom: intermittent electrical faults, arcing sounds, or burn marks around terminals

• Disconnect power (unplug appliance or switch off breaker) before inspecting or replacing parts
• Replace only with the correct insulating part and orient it the same way as the original
• Handle carefully to avoid damaging the insulator or nearby wiring; use basic hand tools as needed

This halogen light bulb restores bright, reliable illumination in your appliance so you can clearly see the cooking area or interior. Replace a burned-out or flickering bulb to maintain visibility and safe operation. What it does:

• Provides illumination inside the appliance or over the cooking surface
• Replaces a failed halogen lamp to restore proper lighting
• Typical symptoms: light won't turn on, is dim or flickers, or works intermittently
• Helps you monitor food and check progress without guesswork

• 1 halogen lamp

• Disconnect power/unplug and allow the bulb and surrounding area to cool completely before service
• Access the lamp per your model's instructions; remove any lens or cover carefully
• Handle the new halogen bulb with gloves or a clean cloth; avoid touching the glass capsule
• Match the bulb type and rating specified for your model; do not exceed the rated wattage

This replacement control panel push button restores a missing, worn, or broken button on compatible Bosch appliance control panels. It gives a clean, user-friendly surface for reliably activating the associated function. What it does

• Replaces a damaged or missing control panel push button so the corresponding command can be selected.
• Restores a crisp tactile feel for a more reliable button press.
• Helps resolve symptoms like a loose, cracked, jammed, or visually missing button.
• Matches the original form for proper fit and operation when installed correctly.

• One replacement control panel push button.

• Disconnect power to the appliance before starting any work.
• Typically snap-fits or slides into the front control panel; use a non-marring pry tool if needed.
• Remove gently to avoid damaging the control panel or surrounding buttons; note orientation for reinstallation.

This push button is a direct-replacement control button used on compatible appliance control panels to restore a responsive, tactile control interface. Replaces worn, broken, or missing buttons so functions register correctly when pressed. What it does:

• Acts as the user interface actuator that completes the mechanical press action for a specific control.
• Restores proper tactile feedback and reliable engagement when selecting functions.
• Commonly replaced when a button is cracked, jammed, loose, or no longer registers presses.
• Helps eliminate intermittent or non-responsive button symptoms caused by damaged controls.

• Disconnect power to the appliance before beginning any work to avoid shock.
• Access may require removing the control panel or console.
• Remove the old button by gently levering or sliding it free; do not force or damage surrounding components.
• If necessary, retain any clips or springs from the original button and reuse with the replacement.

This replacement cover is a protective panel used on compatible Bosch appliances to shield internal components and maintain proper airflow and appearance. It restores the appliance's finished look and helps keep wiring and mechanisms protected. What it does:

• Protects internal components from dust, spills and incidental contact
• Helps maintain proper airflow and clearance around internal parts
• Restores a missing or damaged exterior/internal panel for a finished appearance
• Reduces risk of accidental contact with electrical or moving parts

• One replacement cover

• Installation may require removing access panels and/or disconnecting power—always unplug the appliance before servicing
• Use appropriate hand tools; avoid forcing tabs or fasteners to prevent breakage
• Keep screws and mounting hardware from the original part; replace only with identical fasteners if needed

This is a replacement micro switch used in select Bosch-built appliances. It opens and closes an electrical circuit when actuated by a lever or cam, enabling functions like starting/stopping a cycle or detecting a position.

• Controls power or signals by opening/closing a low-voltage circuit when pressed
• Commonly used for on/off, door/lid, or position-sensing functions
• Failure may cause the unit not to start, intermittent operation, or features that won't engage
• May also present as unresponsive buttons or functions that only work when pressed a certain way

• Disconnect power before servicing; verify no voltage is present
• Access location varies by model; remove panels as needed to reach the switch
• Note wire positions and terminal orientation before removal
• Test continuity with a meter after installation to ensure proper operation

This sensor monitors operating conditions inside the appliance and reports to the control so cycles run correctly and safely. When the sensor fails, the control may receive inaccurate feedback, leading to irregular performance. What it does:

• Detects key conditions inside the appliance and sends a signal to the control
• Helps the control regulate heat and cycle progress
• Failure symptoms can include erratic cycle times, poor heating performance, or sensor-related error messages
• Can prevent the appliance from starting or completing a cycle if readings are out of range

• 1 sensor

• Disconnect power before servicing; shut off water supply if applicable
• Access the sensor and note wire orientation before removal
• Ensure any sealing surface is clean and the sensor is seated properly; check for leaks after reassembly where applicable
• Run a diagnostic or test cycle after installation to clear errors and verify operation

This active carbon filter refreshes the air when your range hood is set to recirculate. Replace a saturated filter to restore effective odor reduction and maintain a more comfortable cooking space. What it does:

• Adsorbs cooking odors in recirculating operation
• Helps maintain fresher indoor air when venting back into the room
• Restores odor-removal performance when the old filter is saturated
• Typical signs it's time to replace: persistent cooking smells or diminished odor reduction

• One activated carbon filter

• Disconnect power to the hood before servicing
• Remove the metal grease filter(s) to access the charcoal filter
• Release the old filter from its clips/bayonet mount and install the new filter in the same orientation until it locks
• Charcoal filters are not washable; replace when saturated

• For hoods configured for recirculation; not used when vented to the outdoors
