Parts for Craftsman 13188273: Replacement Parts

This motor timer controls the drive and cycle sequencing on compatible commercial washers, restoring timed switching between motor, clutch and timer-driven functions to keep cycles advancing reliably. What it does

• Controls timed motor operation and cycle advancement so the washer shifts through wash, rinse and spin stages.
• Re-establishes electrical switching that starts/stops the motor during cycle transitions.
• Use when the machine won't advance through cycles, won't start or stop the motor as expected, or cycles stall or repeat.
• Matches OEM function for replacing a failed or intermittent timer assembly.

• One motor timer (115V 60Hz) assembly.

• Disconnect power before inspecting or replacing electrical components.
• Note and label wiring connections or take a photo before removal to ensure correct reassembly.
• Tighten fasteners and verify secure wiring; test a single cycle after installation.

This blade fan is used on lawn tractors and sits next to the transmission in the body of the tractor. The blade fan is the main component that offers extra cooling to the transmission while a riding lawn tractor is being used. While it is made of premium parts, the blade fan can be damaged or break. When this occurs, it may cause overheating. The lawn tractor may also refuse to start so the part should be replaced.Turn off the lawn tractor and take the key out of the ignition. Lift the set and use wrenches to remove the nuts and disconnect the battery cables. Disconnect the negative side first. Take the battery out and then use a socket to remove the mounting nut for the blade fan. Press on the brake to loosen the drive belt and take out the original blade fan. Install the new part on the transmission shaft and reassemble the lawn tractor.This Hydro-Gear blade fan is a component on many lawn tractors with transaxle transmissions. It's an authentic OEM replacement part that is directly obtained from the manufacturer. This part is sold on an individual basis.
