Joseph K Baden , PA November 01, 2014 Appliance: Samsung Microwave Oven SMH8165B/XAA Se or 5e error Searched and found it is a common problem. Wife boiled pasta and forgot to turn on exhaust fan. Microwave was soaking wet and problem began. Poor design on keypad allows moisture to enter. Could see moisture when old pad was removed. Probably could of took it apart and dried out. Any how, part solved the problem. Be careful to remove all icky glue left over from old pad. Be careful when lining new pad up. One shot deal, when it sticks, it sticks. Also looks like I forgot to remove protective clear cover on display. Can see it once I stuck membrane on. Aint taking it apart for that. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Matt S Rochester Hills , MI July 11, 2014 Se error code I took the keypad off the microwave. There were 4 screws that attached the mother board to the keypad housing. I had to use a screwdriver to peel off the old keypad membrane. I stuck the new one on and put it back together. It's been working perfect for about a week. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
David B Bryan , TX June 17, 2015 Appliance: Samsung Microwave Oven SMH8165B/XAA Se (shorted key) error code Removed top trim & screws, pushed control panel up then tilted out top. Removed wiring clips. Pulled out on locking clip on touchpad ribbon & removed ribbon. Placed control panel on protected surface to pry back plastic release tabs removing circuit board from panel. Pealed off old touch pad & spent some time removing glue left on panel. Stuck new touch pad on front & reattached wires. Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Pliers, Screwdrivers
John W Aurora , CO June 05, 2017 Unit start microwave by it self Replace the touch pad or some time called the switch MEMBRANE SMH8165B (DE34-00304K). Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
Richard Q Riverview , FL November 03, 2018 Se error code on display and microwave will not work. Replaced the keypad and it solved all my issues. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
