Parts for Ge AJES12DCBM1: 03 - Sealed System & Components Parts

This evaporator assembly circulates refrigerant inside the freezer compartment to remove heat and help maintain cold temperatures. Replacing a damaged evaporator restores proper cooling and reduces frost buildup. What it does:

• Houses the evaporator coil where refrigerant absorbs heat from inside the appliance
• Enables airflow over cold surfaces for consistent freezer/cabinet temperatures
• Commonly replaced when you see excessive frost, poor cooling, or frequent defrost cycling
• Works with the appliance's sealed refrigeration and defrost systems to maintain performance

• One evaporator assembly

• Recover the refrigerant safely and follow all EPA and local regulations before opening the system
• Handle the coil carefully to avoid kinks or damage; ensure all fittings and seals are replaced per OEM instructions
• Verify proper vacuum, charge and leak-free connections before returning the appliance to service

This condenser panel replaces the outer cover that protects the refrigerator condenser and helps direct airflow for efficient cooling. It restores proper airflow path and keeps condenser components shielded from debris. What it does:

• Covers and protects the condenser coil and nearby components from dust and physical damage
• Helps channel airflow over the condenser to support efficient heat rejection
• Can reduce vibration noise caused by loose or damaged panels
• Symptoms a failing panel can cause: visible damage, rattling or increased noise near the condenser area, or decreased cooling performance if airflow is obstructed

• One condenser panel (outer cover)

• Disconnect power to the appliance before beginning any work
• Remove access panels and mounting screws to replace the old condenser panel; retain hardware
• Handle edges carefully; panels may have sharp metal edges

A rubber compressor cushion that isolates the compressor from the refrigerator chassis to reduce vibration and prevent metal-on-metal contact. Replaces worn or missing cushions to help minimize noise and vibration transfer. What it does:

• Cushions the compressor to dampen vibration and reduce rattling or buzzing noises.
• Keeps the compressor from directly contacting the cabinet, preventing wear and chafing.
• Helps maintain proper compressor positioning and reduces stress on mounting components.
• Common symptom: increased compressor noise or vibration, or visible worn/deteriorated cushion.

• One compressor cushion (rubber mount).

• Disconnect power to the appliance before starting any repair.
• Support the compressor or secure the unit when removing/replacing mounts to avoid strain.
• Remove the old cushion and press the new cushion into place; no refrigerant handling required.
• Use basic hand tools and wear gloves.
