Parts for Ge AZ95E09DACK2: Sealed System Parts

Not cooling properly? The indoor evaporator coil absorbs heat from room air. This repair requires refrigerant recovery and moderate skill.

This bracket secures the oven/range base pan and helps keep the bottom panel aligned for stable operation and proper clearance. It replaces a damaged or missing base pan bracket to reduce rattling and sagging. What it does:

• Fastens the base pan to the appliance cabinet to maintain proper alignment
• Prevents the bottom panel from sagging or vibrating during use
• Restores secure support for components mounted to the base pan
• Can stop noises or movement caused by a loose or broken bracket

• One base pan bracket

• Disconnect power (and gas if applicable) before beginning work
• Removal of the oven bottom or lower access panel may be required for access
• Use basic hand tools; retain fasteners unless new ones are explicitly included
• Follow OEM instructions and safety guidelines

This plug base pan is the metal mounting pan that secures the appliance's power plug/terminal assembly and helps protect wiring from heat and debris. It restores a stable mounting surface for the power connection. What it does:

• Provides a secure mounting surface for the power plug/terminal assembly
• Helps protect wiring and connections from heat, grease, and debris
• Prevents the power plug from shifting or rubbing against other components
• Worn or damaged pans can expose wiring or cause poor electrical seating

• One plug base pan

• Disconnect all power at the breaker or unplug the appliance before beginning work
• Access typically requires removing the appliance back panel or console; keep track of fasteners
• Inspect wiring and terminal hardware while replacing the pan; replace any damaged connectors
