Parts for Ge AZ22E15E4CM1: 03 - Section3 Parts

Rubber cushion that mounts between the air conditioner motor and housing to reduce vibration and noise. Replace if cracked, compressed, or missing.

This base pan assembly is the lower support pan that helps protect the appliance cabinet and catch minor leaks or debris. It restores the unit's stable mounting and helps keep internal components protected from spills. What it does:

• Provides the lower structural support for the appliance cabinet and components
• Channels and contains incidental water or debris away from electronics and controls
• Helps maintain proper alignment and stability of the appliance on the floor
• Reduces vibration transfer and helps prevent direct contact between components and the floor

• One base pan assembly as shown

• Disconnect power and water before beginning
• Check for secure mounting points and replace any worn fasteners or grommets during reassembly
• Inspect surrounding seals, hoses, and mounts for damage while the appliance is open
• Use manufacturer-recommended hardware and follow OEM disassembly/reassembly steps

Special mounting screw for air conditioner assembly. Secures internal components and panels. Replace if stripped, missing, or damaged during maintenance.

Rubber washer for air conditioner unit assembly. Installs between components to create seal and reduce vibration. Replace if cracked, worn, or missing.

This wire fixing band is a small retainer clamp that secures wiring harnesses and individual wires to appliance chassis to prevent rubbing, pinching, or accidental disconnection. It helps protect wiring from damage and reduces electrical faults. What it does:

• Holds wiring harnesses and loose wires in place to prevent contact with hot or moving parts
• Reduces wear from vibration and movement that can cause frayed insulation or shorts
• Helps maintain safe routing of wires to avoid pinch points and strain on connectors
• Commonly used where a simple clipped band or strap is needed to fasten wires to sheet metal

• Inspect surrounding wiring and connectors before installation; replace damaged wires or insulation
• Secure the band to the designated chassis hole or stud without over-tightening to avoid crushing wires
• Disconnect power before accessing wiring and follow all appliance safety procedures

Special mounting screw for air conditioner assembly. Replace if screw is stripped, missing, or damaged during maintenance or installation work.

Replacement mounting screw for air conditioner units. Secures cabinet panels and internal components. Order if your original screw is missing or stripped.
