Parts for Kitchenaid KFIS29BBMS02: 06 - Shelf Parts

This front pan is the front half of the outer tub assembly in a washing machine. It forms the watertight front section of the tub that houses and supports the spin basket and seals against the rear tub half.

• Forms the front portion of the outer tub to contain wash water
• Provides mounting and sealing surface for the door boot/bellow
• Supports the spin basket shaft and helps maintain proper alignment
• Wear or damage may cause leaks, rubbing noises, or vibration

• Disconnect power and water before service; use protective gloves
• Removal generally requires taking off the top, front panel, and door boot
• Transfer any seals, clamps, screws, and hardware from the original part
• Inspect and replace the tub gasket/door bellow if worn or damaged

The Heater is an OEM part for Whirlpool refrigerators. It is an essential temperature control component located inside the refrigerator compartment. The heater works to maintain consistent cool temperatures by heating evaporator coils and circulating airflow inside the fridge.

Causes of a bad heater include failures in the heating element over time, moisture damage to electrical components, or loose connections to the power supply.

Symptoms of a bad heater are:

• Fluctuating and unstable interior temperatures
• Frost or ice buildup inside the refrigerator
• The refrigerator failing to consistently cool food properly

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This refrigerator crisper pan replaces a damaged or missing produce drawer. It restores smooth sliding access and dedicated storage for fruits and vegetables, keeping spills contained and fresh items organized in the fresh-food compartment.

• Provides a dedicated bin for fruits and vegetables
• Helps contain drips and debris to protect shelves and liners
• Slides on existing rails for easy access to contents
• Common symptoms: cracked or broken bin, warped drawer, broken front lip/tab, won't slide or stay on track, or missing drawer

• Disconnect power and clear the crisper area before handling parts
• Remove the old drawer; clean and inspect the tracks/rails
• Transfer any reusable trim or inserts from the old drawer if applicable
• Align the new pan with the tracks and slide it fully into place

This glass shelf replaces a damaged or missing refrigerator shelf to restore usable storage space and an even load surface. It provides a flat, easy-to-clean surface for food storage and organization. What it does:

• Replaces a broken, cracked or missing refrigerator shelf so you can safely store items.
• Provides a stable, level surface for food containers, deli items and produce.
• Helps maintain organized shelving and prevents items from shifting or tipping.
• Easy-to-clean glass surface resists stains and odors compared with porous shelving.

• Remove all items from the refrigerator compartment and support adjacent shelves before removing the old shelf.
• Slide the shelf out carefully to avoid chipping; lift straight up when reinstalling to seat into shelf supports.
• Handle the glass with care and wear cut-resistant gloves if broken glass is present.
• No electrical disconnection is typically required, but follow your appliance owner's manual for any model-specific instructions.

This pan front is the removable front panel for a refrigerator storage drawer. Replacing a cracked or missing front restores containment and gives a solid handhold so the drawer opens and closes smoothly.

• Forms the drawer's front wall and integrated pull
• Helps keep food from sliding out of the bin
• Common fix for cracked, broken, or missing drawer fronts
• Improve drawer alignment and closing after damage

• Safety first: Disconnect power before working inside the refrigerator
• Remove the drawer and place it on a flat surface
• Release retaining tabs or screws to remove the old front
• Align and snap/secure the new front; verify smooth operation before reinstalling

The Storage Drawer is an OEM replacement part for Whirlpool refrigerators. It provides customizable organization for items like snack foods, beverages, and condiments inside the refrigerator cabinet. The drawer measures approximately 27"x 20"x 6".

Causes of a bad storage drawer can include broken mounting slides, making it difficult to open or close securely. Overpacking may also cause cracks in the plastic construction over time.

Symptoms of a bad storage drawer include:

• Will not stay fully closed when loaded
• Mounting brackets crack or break off from vibration
• Contents spill out easily due to loose fit

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This glass crisper shelf provides a sturdy, flat surface for the refrigerator crisper area so fruits and vegetables are stored safely and organized. Replaces a cracked, chipped, or missing crisper shelf to restore usable storage space. What it does:

• Replaces the glass shelf that sits over the crisper drawer, supporting produce and other items
• Restores a smooth, even surface when the original shelf is cracked, chipped, or broken
• Helps prevent food from falling into the crisper compartment due to damaged glass
• Allows drawers and storage above the crisper to slide and sit properly when shelf is intact

• Handle with care; glass can break—wear gloves and eye protection during removal/installation
• Remove food and any loose components from the area before replacing the shelf
• Support the shelf while sliding it into position to avoid dropping or chipping
• Align it evenly and test drawer movement before restocking

This rear crisper drawer support secures and aligns the refrigerator crisper, keeping the drawer stable and allowing smooth sliding. Replace a worn or broken rear support to restore proper drawer fit and prevent sagging or misalignment. What it does:

• Holds the rear of the crisper drawer on its track so the drawer stays level during use
• Guides and stabilizes drawer movement to prevent sticking or uneven travel
• Prevents the crisper from tilting, falling, or binding when opening and closing
• Works with the existing front support and drawer components to maintain fit

• One rear crisper drawer support (quantity: 1)

• Remove food and the crisper drawer before replacing the support
• Most repairs are simple and require only basic hand tools; handle plastic parts gently to avoid damage
• Disconnect power to the appliance before servicing if you need to move or access electrical components

This replacement plate (burner drip bowl) sits under a cooktop burner to catch spills and protect the cooktop. It restores a clean appearance and helps prevent food and liquids from contacting the heating element. What it does:

• Catches drips and boiled-over food to keep the cooktop surface cleaner
• Shields the heating element or burner area from debris that can cause smoking or uneven heating
• Helps the burner sit flush and stable in the cooktop opening
• Visible cracks, warping, heavy corrosion, or large dents can cause poor fit or increased spills

• One replacement plate (burner drip bowl)

• Disconnect power (or shut off gas) to the appliance before beginning any work
• Allow the cooktop and burner to cool fully; use gloves to avoid sharp edges
• Remove the old plate by lifting or releasing any retaining clips; install the new plate in the same orientation so the burner seats properly

This is a replacement mounting plate that secures and supports internal components for proper alignment and stable operation. Restores structural support and helps maintain correct positioning of nearby parts. What it does:

• Provides a stable mounting surface for adjacent components to prevent movement or vibration
• Keeps parts aligned so mechanisms operate smoothly and reliably
• Replaces a damaged, bent, or corroded plate that can cause rattling or misalignment
• Helps maintain proper spacing to protect wiring and connectors from contact or wear

• Disconnect power before beginning any repair to avoid shock or injury
• Installation typically requires basic hand tools; handle edges carefully
• Inspect nearby fasteners, clips, and gaskets and replace if damaged

The Drawer Slide Rail is an OEM part for Whirlpool refrigerators. It is designed to allow freezer or refrigerator drawers to glide smoothly in and out.

Causes of a bad refrigerator slide rail can be wear and tear over long-term use. Accidental damage from overloading a drawer or rough handling can also prematurely wear out slide rails.

Symptoms of a bad slide rail include:

• A drawer that is stiff, sticks, or binds during operation
• Visible damage or bent parts along the slide rail
• A drawer that no longer fully extends from the refrigerator

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This slide is the replacement drawer rail that supports and guides a range/oven storage drawer for smooth opening and closing. Restores proper alignment so the drawer rides evenly and stays securely in place. What it does:

• Provides a guided track for the appliance's storage/drawer assembly to slide in and out
• Replaces worn, bent, or broken rails that cause sticking, grinding, or misaligned drawers
• Helps prevent the drawer from slipping off its track or falling when opened
• Restores stable, consistent drawer movement and proper closure

• One replacement slide

• Disconnect power to the appliance before beginning any repair to avoid shock or injury
• Remove the drawer and any obstructions; install the slide in the same orientation as the original
• Basic hand tools are typically required; keep fasteners and mounting positions consistent

This is the right-side crisper plate — the shelf panel that supports the crisper drawer and its contents, helping keep produce organized and stable inside the refrigerator. What it does:

• Provides a stable shelf surface for the right crisper/drawer area
• Supports the crisper drawer and helps keep items from falling into lower cavities
• Replaces cracked, chipped, warped or missing right crisper shelf panels
• Restores proper seating and alignment for the crisper drawer on the right side

• Handle carefully during install to avoid chipping or cracking; use gloves if needed
• Slide the crisper drawer out and set aside before positioning the replacement plate

The DRAWER GLIDE is an OEM component specifically designed for bottom-mount Whirlpool refrigerators. It facilitates smooth extension and retraction of refrigerator shelves and drawers.

These heavy-duty glides are engineered to silently and reliably operate over extended use. Proper functionality of the glides is necessary for accessible storage of items placed on shelves and in drawers.

Causes of bad drawer glides can include worn roller bearings, broken plastic clips or guides, or accumulated debris that causes resistance.

Symptoms of a bad Drawer Glide include:

• "Sticking" or binding when pulling shelves out
• Noisy or grinding sounds emanating from glide areas
• Difficulty fully extending shelves or drawers

This part is also compatible with refrigerators from Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, and some Kenmore models.

This is a replacement plate that covers and protects internal components on select Whirlpool appliances, helping keep parts secure and preventing debris from entering service areas. It restores proper fit and appearance to the area it covers. What it does:

• Covers and shields internal components from dust, food debris and moisture
• Helps hold adjacent parts in place for correct appliance operation
• Reduces rattling or vibration caused by loose or missing metal trim
• Restores finished appearance to the appliance where the original plate was damaged or missing

• One replacement plate as shown

• Disconnect power (unplug or shut off circuit breaker) before starting any repair
• Verify plate orientation and fastener locations before fastening; use existing screws if still serviceable
• Wear gloves to protect hands from sharp metal edges during installation

This trim piece restores the finished appearance of your appliance where trim has become cracked, chipped, or missing. It provides a clean, factory look while protecting the exposed edge or opening. What it does:

• Covers and protects an exposed edge or seam for a finished appearance
• Replaces cracked, warped, or otherwise damaged trim that affects looks
• Helps maintain the appliance's original styling and visual fit
• Simple, non-electrical part — no wiring or moving components

• Remove power to the appliance and follow the manufacturer's service instructions before starting.
• Installation typically requires basic hand tools and careful removal of old trim to avoid damaging surrounding surfaces.
• Keep mounting screws or clips from the original trim if re-using; replace only with manufacturer-specified fasteners.

This slide is a direct-fit replacement guide that restores smooth, stable movement for a refrigerator drawer or shelf. It helps the drawer track correctly and prevents binding or uneven operation. What it does:

• Guides and supports a refrigerator drawer or shelf for smooth, controlled opening and closing
• Replaces worn, damaged or missing slide hardware that causes sticking or uneven movement
• Helps maintain correct alignment so the drawer loads and unloads without jamming
• Commonly used when a drawer drops, tilts, or does not track properly

• One replacement slide

• High-level installation: remove the drawer or shelf, unfasten the old slide, and install the new slide using existing mounting holes and hardware
• Inspect mating tracks and mounting points for damage; clean debris before installing
• Use proper tools and avoid overtightening fasteners to prevent cracking the slide or mounting bosses
• Disconnect power only if required by your appliance model; follow all manufacturer safety instructions

This replacement screw fastens trim, panels and small components to restore secure attachment and reduce rattling or movement. Use when a screw is missing, stripped, or damaged to keep parts aligned and operating quietly. What it does:

• Secures panels, brackets and trim to appliance assemblies
• Prevents vibration, rattling and misalignment caused by missing or damaged fasteners
• Replaces lost or stripped screws that can allow gaps or loose parts
• Helps maintain safe, stable operation by keeping components properly fastened

• Disconnect power (and water if applicable) before accessing interior panels
• Use the proper screwdriver or driver bit to avoid stripping the head
• Align parts before tightening and tighten until snug—do not overtighten
• Replace only with the correct OEM part to ensure proper fit and function

This front crisper drawer support secures the refrigerator's front crisper drawer for smooth sliding and correct alignment, reducing sagging and sticking so stored items stay accessible and the drawer operates reliably. What it does:

• Holds the front corner of the crisper drawer in place so the drawer slides and aligns properly.
• Prevents drawer sagging, catching, or uneven movement that can make the drawer hard to open or close.
• Helps maintain proper drawer positioning to protect stored produce and prevent rubbing on the cabinet.
• Works with the existing drawer track and rear support.

• Unplug the appliance or disconnect power before starting any service to reduce electrical risk.
• Empty and remove the crisper drawer before replacing the support; follow the refrigerator's parts diagram for correct orientation.
• Inspect the drawer track and rear support for wear; replace any damaged components to restore smooth operation.

A small mounting screw used to secure appliance panels and components. This genuine replacement restores proper fit and reduces vibration or loose parts when a missing or stripped fastener causes fit issues. What it does:

• Secures panels, trim, or internal components to the appliance frame
• Helps stop rattling or movement caused by a missing or loose screw
• Restores correct alignment where a fastener is lost or damaged
• Works as a direct-fit replacement when the original screw is worn or stripped

• The screw shown/listed

• Disconnect power (and gas if applicable) before any repair
• Use the matching screwdriver or driver bit to avoid stripping the head
• Thread carefully and avoid overtightening to prevent damage
• Keep small parts away from children and store removed hardware for reference

This sachet holder housing assembly secures single-use detergent or cleaning sachets inside the dispenser so they stay in place and release correctly during cycles. Replacing a cracked or broken holder restores reliable sachet positioning and dispensing. What it does:

• Holds detergent/cleaning sachets in the dispenser so they don't shift or drop into the tub.
• Ensures sachets stay aligned for proper release during the wash or cleaning cycle.
• Helps prevent sachets from rupturing or blocking the dispenser area.
• Common symptoms of a bad holder: sachets falling out, sachets not dispensing properly, or poor wash/cleaning results.

• Disconnect power (and water, if required) before servicing the dispenser area.
• Access the dispenser per the owner's manual; the holder typically snaps into place or secures with a small fastener.
• Handle plastic clips and tabs gently to avoid breakage; use a non-marring pry tool if needed.

This electronic control board is the appliance's main logic module that manages cycles, user controls and display feedback so the unit responds correctly to inputs and runs programmed functions. What it does:

• Receives user commands and sends signals to motors, valves, heaters and timers
• Controls cycle selection, start/stop functions and display indicators
• Can prevent the appliance from starting or cause unresponsive or erratic controls
• Common symptoms: blank or non-responsive control panel, cycles won't start, incorrect cycle behavior or intermittent operation

• Disconnect power before starting; verify the appliance is de-energized to avoid shock
• Take photos of wiring and connector locations before removal for correct reassembly
• Handle the board by edges and avoid static discharge; do not touch components
• Reconnect all harnesses securely and test functions before reassembling trim or panels

This replacement screw fastens appliance components securely in place. Use it to replace missing, stripped, or corroded hardware so panels, brackets, and covers stay aligned and rattle-free.

• Secures parts such as panels, brackets, covers, or internal assemblies
• Restores alignment and helps eliminate vibration or rattling from loose hardware
• Replaces lost, rusted, or damaged screws during service
• Maintains safe, stable operation by keeping components tight

• Disconnect power before service; if applicable, also shut off water and/or gas
• Start threads by hand to avoid cross-threading; tighten snugly without over-torquing
• Use the correct driver bit to prevent stripping the head

This replacement cover restores the appliance's exterior appearance and protects internal components from dirt and accidental contact. It fits where the original cover was removed or damaged, helping keep controls and wiring protected. What it does

• Replaces a damaged, cracked, or missing access panel to restore cabinet protection and appearance
• Shields internal components from dust, spills, and incidental contact
• Helps prevent accidental access to wiring and electrical parts
• Useful when the original cover is warped, broken, or no longer securing in place

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Remove any retaining screws or clips from the original cover; installation typically reverses removal
• Handle edges carefully to avoid cuts; use gloves if panels are sharp
• Inspect and replace fasteners or mounting tabs as needed for a secure fit

This decorative trim piece replaces a damaged or worn exterior trim to restore the appliance's finished appearance and fit. It provides a clean edge and helps cover mounting gaps around the control area. What it does:

• Covers and protects the appliance edge where trim is installed, improving appearance
• Hides gaps between panels and the control area for a finished look
• Replaces cracked, chipped, bent, or missing trim that affects aesthetics
• Prevents sharp or exposed edges that can catch clothing or skin

• Disconnect power (unplug appliance or shut off breaker) before starting any repair
• Typical installation requires removing adjacent screws or clips; have a screwdriver set handy
• Handle edges carefully; trim and surrounding metal can be sharp

This replacement support is a mounting bracket that helps secure and stabilize a major appliance assembly, restoring proper alignment and reducing vibration or movement. It fits into the OEM assembly to keep panels and components supported. What it does

• Holds and supports a panel or internal component to prevent sagging and misalignment
• Reduces rattling, vibration and contact-related noises caused by loose supports
• Restores proper alignment so doors, panels or assemblies sit and operate correctly
• Helps maintain safe, stable operation by keeping parts secured in their intended position

• Disconnect power and water (if applicable) before starting any repair
• Use basic hand tools; follow the OEM diagram for correct orientation and fastener locations
• Inspect adjoining parts (fasteners, clips, mounting points) and replace any that are worn
