Parts for Magic Chef CGR1110ADQ: 06 - Supplemental Information Parts

This switch spark harness routes the spark signal from the range/oven control to the burner igniters so burners spark reliably when attempting to light. It restores proper spark routing and helps resolve ignition-related issues. What it does:

• Carries ignition switch signals to the spark modules/igniters so burners spark during lighting cycles
• Commonly replaced when burners fail to spark or sparks are intermittent
• Helps stop clicking or sparking at the wrong burner if wiring is damaged or shorted
• Maintains correct connection and routing between the control switch and ignition components

• Disconnect power and turn off gas supply before inspecting or replacing harness
• Replace only if wiring, connectors, or insulation are damaged; handle connectors by the body, not the wires
• Confirm connector orientation and secure all connections; route wiring clear of heat sources and moving parts
