Parts for Frigidaire AS10C4SVC: 04 - System Parts

This tube connector joins the refrigerator water line to internal tubing, restoring a secure, leak-resistant connection for the ice maker and dispenser. Use when a cracked or loose tube causes leaks or poor water flow. What it does:

• Connects and secures the refrigerator's water tubing to internal fittings.
• Prevents leaks and helps maintain proper water flow to the ice maker and dispenser.
• Commonly replaced for visible cracks, splits, or loose fittings that cause dripping.
• Works with rigid or flexible water tubing depending on the appliance plumbing layout.

• Turn off water supply and unplug the appliance before starting work.
• Verify tubing sizes and seating; push tubing fully into the connector until it locks (or secure per OEM fitting style).
• Inspect nearby tubing and fittings; replace any damaged sections to prevent repeat leaks.

This terminal-cover gasket seals and cushions the appliance's electrical terminal cover, helping protect wiring and connections from moisture, dust and abrasion. It restores a secure fit for the cover and helps maintain safe operation. What it does:

• Creates a sealed barrier around the terminal cover to reduce moisture and debris intrusion
• Cushions the terminal cover to prevent chafing or movement of wiring and connectors
• Helps reduce risk of arcing by keeping cover seated and terminals covered
• Useful when the existing gasket is cracked, warped, missing, or no longer forms a tight seal

• Disconnect power to the appliance before servicing electrical components
• Remove the terminal cover and clean mating surfaces of debris and old gasket material
• Press the new gasket into place, ensuring it seats evenly around the cover perimeter
• Reinstall the terminal cover and restore power; inspect for secure fit and any exposed wiring
