Parts for Whirlpool WED8600YW2: 01 - Top And Console Parts

This electronic control board powers the oven's user interface and manages touch controls, display, and command signals so the range responds correctly to button presses and timer/settings changes. Replaces a failed console control to restore normal panel operation. What it does:

• Receives input from the touchpad/buttons and sends commands to the oven's main control
• Drives the control panel display and status indicators for temperature and timer
• Helps enable oven functions like broil, bake, timers and clock when functioning properly
• Resolve symptoms such as unresponsive touchpad, blank or erratic display, or inability to select functions

• Disconnect power at the breaker before accessing the control panel to avoid shock
• Handle the board by the edges and avoid touching components or connector pins
• Verify connectors are fully seated and wiring is undamaged before reassembly

This control knob assembly replaces a worn or broken selector knob so you can set and change appliance functions with a secure fit and clear detents. It restores reliable manual control for common user settings. What it does:

• Fits onto the control shaft to select cycles, temperatures, or settings depending on your model
• Provides tactile detents and a firm grip for accurate selection
• Resolves symptoms like a loose, cracked, or spinning knob that won't engage settings
• Prevents slipping or intermittent control inputs caused by a damaged knob

• Disconnect power (unplug or shut off breaker) before handling control parts
• Often installs by aligning onto the control shaft and pushing on until seated; some models may use a retaining clip or screw
• Handle gently to avoid damaging the control shaft or surrounding panel

This electronic control board manages the washer's cycle selection, timing and user interface to help restore normal operation. It replaces a failed control board that causes unresponsive controls, incorrect cycles or display problems. What it does:

• Manages wash cycles, spin timing, and control logic for the appliance
• Processes user inputs and drives the display and indicators
• Common symptom: washer won't start or cycles won't advance
• Common symptom: unresponsive buttons, error codes or erratic behavior

• Disconnect power before servicing to avoid shock; verify power is off at the breaker
• Handle the board by the edges and avoid static discharge; use an anti-static wrist strap if available
• Some installations require removing the control panel or console and disconnecting wiring harnesses; refer to the service manual or wiring diagram

Screw for control panel.

This self-drilling screw secures appliance panels and components where a fastener must cut its own pilot hole. It provides a quick, reliable hold for repair or reassembly of trim, brackets, and internal fixtures. What it does:

• Fastens panels, brackets, and small components without pre-drilling
• Helps stop loose or rattling trim and parts caused by missing or worn screws
• Restores proper alignment and secure mounting after repairs
• Works where sheet metal or thin substrates require self-tapping engagement

• One self-drilling screw

• Disconnect power and follow appliance safety procedures before starting repairs
• Use the correct size driver and steady pressure to avoid stripping the head
• Start straight and apply firm, even torque; avoid overtightening which can damage mounting surfaces
• Wear eye protection and handle small fasteners carefully to avoid loss or ingestion hazards
