Parts for Electrolux FFGF3049LSJ: 05 - Top / Drawer Parts

This drain pan collects and channels condensation away from the evaporator to prevent water buildup and leaks. It restores proper drainage and helps maintain refrigerator hygiene and consistent operation. What it does:

• Catches defrost and condensation water from the evaporator coil to prevent pooling inside the cabinet
• Directs water toward the drain tube or pump for proper removal
• Helps reduce unwanted odors and potential mold by containing moisture
• Supports the evaporator assembly and aligns with mounting points for a secure fit

• One drain/evaporator drip pan as shown

• Inspect surrounding seals and the drain tube for clogs before reinstalling the pan
• Use basic hand tools; keep electrical power disconnected when accessing internal compartments
• Handle carefully to avoid bending mounting tabs or damaging nearby components
• Replace any damaged fasteners or gaskets removed during service

This insert is a small trim piece designed to restore fit and finish on your appliance where factory trim has worn or been damaged. It improves appearance and helps protect edges from wear. What it does:

• Replaces a damaged or missing trim insert to restore original appearance
• Covers gaps and provides a finished edge on the appliance component
• Helps prevent dirt and moisture from reaching underlying parts
• Supports proper alignment of the surrounding trim or panel

• One insert trim piece as pictured

• High-level replacement; may require removal of surrounding trim or fasteners
• Use appropriate hand tools and keep small parts organized during reassembly
• Disconnect power to the appliance before starting work if removal involves electrical components

This cooktop grate provides a stable, elevated surface for pots and pans over the burner, restoring safe and even cookware support for gas ranges. Durable cast construction resists heat and helps keep burners accessible and level. What it does:

• Supports cookware above the burner for stable cooking and even heat exposure
• Keeps flames and burner caps accessible while protecting the cooktop surface
• Replaces cracked, warped, or missing grates that cause wobbling or uneven heating
• Helps maintain proper airflow around burners for consistent flame performance

• Allow the cooktop to cool completely before removing or installing the grate
• Lift the grate straight up to remove; seat it firmly on the cooktop supports when installing
• Clean with warm, soapy water; avoid harsh abrasives that can damage the finish
• Inspect grate for cracks or warping and replace if damaged to prevent instability

The oven grates are installed on top of the burner elements to hold various types of cookware and protect the burners from damage. Sometimes the grates on top of an oven's burners can become damaged or corroded, and repairing or cleaning won't be enough to fix them. Working grates should always be installed on top of the burners to protect pots and pans from direct heat. These grates also keep the burners from getting damaged. Make sure the old grates aren't hot before you remove them. Wear gloves if possible. Lift up on the old grates to remove them from the burners. Discard them and place the new ones in their old place. Make sure they are locked in place securely and don't sit unevenly.This Frigidaire grate kit is sourced directly from Frigidaire as a genuine OEM replacement part. The component is sold individually. This part is compatible with Frigidaire brand appliances.

Restore steady, even flames with this surface burner cap. It sits atop the burner head to shape the flame and shield the burner from spills and debris, helping keep lighting quick and cooking performance consistent.

• Shapes and centers the flame for efficient, even heating
• Protects the burner head from spills and food debris
• Helps proper ignition by maintaining the correct gap and alignment
• Typical symptoms: uneven or yellow flames, delayed ignition or constant clicking, visible chips/warping, or a missing cap

• Turn all controls off and allow the cooktop to cool completely
• Lift off the old cap; clean the burner head and igniter area
• Center the new cap on the burner head so it sits level and fully seated
• If ignition is delayed or the flame is uneven, re-seat and realign the cap

The Range Cap is an OEM part for Frigidaire ranges. It seals the upper combustion chamber to contain heat from the oven burners. A tight-fitting cap is critical for efficient, safe oven performance.  This cap measures 3 inches in diameter.

Causes of a bad cap can include cracks, warping, or collapsed seals from prolonged exposure to high oven temperatures. Accidental damage during past maintenance is also possible.

Symptoms of a bad cap include:

• Escaping heat from the oven chamber, reducing efficiency
• Flames or sparks visible around the cap during baking
• Loose, wobbly, or missing cap allowing grease and debris in the combustion area

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

The Burner Cap is an OEM part for Frigidaire cooktops and ranges. It is designed to cover the burner head, ensuring an even distribution of the flame for efficient cooking. The burner cap also protects the burner head from spills and debris, which can affect performance.

You should replace the burner cap if it becomes damaged or worn out. Causes of a bad burner cap can include exposure to high heat, buildup of food residue, or accidental impacts. A compromised burner cap can lead to uneven flames, inefficient cooking, or difficulty in lighting the burner.

Symptoms of a bad burner cap include:

• Uneven or yellow flames
• Difficulty in igniting the burner
• The burner cap being cracked, chipped, or discolored
• Poor cooking performance or hotspots on cookware

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Surface Burner Cap is an OEM part for Frigidaire gas ranges. It sits atop the surface burner and helps to distribute the gas flame evenly for consistent cooking performance. The cap also protects the burner head from spills and debris.

You should replace this surface burner cap if it becomes damaged or worn out. Signs of damage include chipping, cracking, or discoloration due to prolonged exposure to high temperatures or cleaning agents.

Symptoms of a bad surface burner cap include:

• Uneven or unstable flame
• Difficulty in igniting the burner
• Visible cracks or chips on the cap
• Food cooking unevenly

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This is the stainless steel oven door handle. It lets you safely open and close the oven door and restores a secure, finished look when the original handle is broken, loose, or missing.

• Provides a sturdy grip to operate the oven door
• Helps ensure the door opens/closes smoothly
• Common failure signs: loose handle, broken end caps/mounts, missing or damaged handle
• Cosmetic refresh for a worn or scratched handle

• Disconnect power and allow the oven to cool completely before servicing
• Remove interior door screws to access the handle mounts
• Support the door glass to prevent stress while removing/installing hardware
• Reuse existing screws and trim/end caps or replace them if worn or damaged

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
