Parts for Electrolux FFLF3047LSF: 05 - Top / Drawer Parts

This drain pan collects and channels condensation away from the evaporator to prevent water buildup and leaks. It restores proper drainage and helps maintain refrigerator hygiene and consistent operation. What it does:

• Catches defrost and condensation water from the evaporator coil to prevent pooling inside the cabinet
• Directs water toward the drain tube or pump for proper removal
• Helps reduce unwanted odors and potential mold by containing moisture
• Supports the evaporator assembly and aligns with mounting points for a secure fit

• One drain/evaporator drip pan as shown

• Inspect surrounding seals and the drain tube for clogs before reinstalling the pan
• Use basic hand tools; keep electrical power disconnected when accessing internal compartments
• Handle carefully to avoid bending mounting tabs or damaging nearby components
• Replace any damaged fasteners or gaskets removed during service

This insert is a small trim piece designed to restore fit and finish on your appliance where factory trim has worn or been damaged. It improves appearance and helps protect edges from wear. What it does:

• Replaces a damaged or missing trim insert to restore original appearance
• Covers gaps and provides a finished edge on the appliance component
• Helps prevent dirt and moisture from reaching underlying parts
• Supports proper alignment of the surrounding trim or panel

• One insert trim piece as pictured

• High-level replacement; may require removal of surrounding trim or fasteners
• Use appropriate hand tools and keep small parts organized during reassembly
• Disconnect power to the appliance before starting work if removal involves electrical components

This surface burner grate supports cookware on your gas cooktop, keeping pots and pans stable above the flame. Replace a cracked or warped grate to restore safe pan support and consistent burner performance.

• Holds cookware at the proper height above the burner flame
• Provides a stable, level surface for pots and pans
• Replace if cracked, warped, or missing to prevent wobbling or tipping
• Common symptoms include unstable cookware, uneven heating, or visible damage to the grate

• Turn all burners off and allow the cooktop to cool completely before handling
• Lift off the old grate and clean the area if needed
• Position the new grate so its feet sit flat and openings align with burner caps
• Test with a pan to confirm it sits level and stable

The Surface Burner Cap is an essential OEM component for Frigidaire gas cooktop ranges. It regulates flame spread and directs heat precisely to pots and pans placed above each burner coil.

Causes of burner cap failure include warping or discoloration from continuous exposure to open flames and high cooking temperatures over time. Accidental impacts could also crack or fray burner cap edges.

Symptoms of a faulty burner cap include:

• Irregular or uneven flame patterns beneath cooking vessels
• Visible yellow or blue flames indicating poor combustion
• Signs of cracked porcelain or scorched burner bases
• Reduced burner efficiency and poor heat distribution

This authentic OEM replacement is compatible with Electrolux, Gibson, Kelvinator and select Kenmore models.

The Burner Cap is an OEM part for Frigidaire cooktops and ranges. It is designed to cover the burner head, ensuring an even distribution of the flame for efficient cooking. The burner cap also protects the burner head from spills and debris, which can affect performance.

You should replace the burner cap if it becomes damaged or worn out. Causes of a bad burner cap can include exposure to high heat, buildup of food residue, or accidental impacts. A compromised burner cap can lead to uneven flames, inefficient cooking, or difficulty in lighting the burner.

Symptoms of a bad burner cap include:

• Uneven or yellow flames
• Difficulty in igniting the burner
• The burner cap being cracked, chipped, or discolored
• Poor cooking performance or hotspots on cookware

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Surface Burner Cap is an OEM part for Frigidaire gas ranges. It sits atop the surface burner and helps to distribute the gas flame evenly for consistent cooking performance. The cap also protects the burner head from spills and debris.

You should replace this surface burner cap if it becomes damaged or worn out. Signs of damage include chipping, cracking, or discoloration due to prolonged exposure to high temperatures or cleaning agents.

Symptoms of a bad surface burner cap include:

• Uneven or unstable flame
• Difficulty in igniting the burner
• Visible cracks or chips on the cap
• Food cooking unevenly

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This is the stainless steel oven door handle. It lets you safely open and close the oven door and restores a secure, finished look when the original handle is broken, loose, or missing.

• Provides a sturdy grip to operate the oven door
• Helps ensure the door opens/closes smoothly
• Common failure signs: loose handle, broken end caps/mounts, missing or damaged handle
• Cosmetic refresh for a worn or scratched handle

• Disconnect power and allow the oven to cool completely before servicing
• Remove interior door screws to access the handle mounts
• Support the door glass to prevent stress while removing/installing hardware
• Reuse existing screws and trim/end caps or replace them if worn or damaged

This factory screw secures components in your appliance, restoring a tight, rattle-free fit. Replace missing or damaged hardware to keep panels, brackets, and trim properly fastened and aligned for safe, reliable operation.

• Secures panels, brackets, trim, or internal components to the chassis
• Replaces lost, rusty, stripped, or cross-threaded screws
• Helps eliminate looseness, gaps, and vibration/rattling
• Common signs: loose/misaligned panels or trim, rattling noises, missing or rounded screw heads

• Disconnect power (and shut off gas if applicable); allow the unit to cool completely
• Match to the original location and replace one at a time to maintain alignment
• Hand-start to prevent cross-threading; tighten snugly—do not overtighten
• Use light torque when threading into plastic or thin sheet metal

This is a replacement mounting screw used to secure panels and components in compatible Frigidaire appliances. It restores proper fit and helps prevent rattles, loose panels, and parts that shift during operation. What it does:

• Fastens trim, panels, brackets, or controls to the appliance frame
• Restores secure attachment to reduce vibration, noise, and movement
• Replaces stripped, missing, or corroded screws that prevent proper assembly
• Works wherever the OEM screw with this part number is specified

• Disconnect power to the appliance before beginning any repair
• Use the correct screwdriver or bit to avoid stripping the head
• Tighten until snug—do not overtighten to avoid stripping threads or damaging parts
• Keep removed hardware organized and compare parts to the old screw for correct fit

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
