Parts for Kenmore 790.4252231A (7904252231A, 790 4252231A): Top / Drawer Parts

This replacement control panel restores the oven/stove console appearance and provides the front surface for the keypad and display, helping you use controls safely and clearly. It's a direct-fit exterior panel used where the factory front panel is cracked, scratched, or worn. What it does:

• Replaces the appliance's worn or damaged console front so buttons and display have a solid mounting surface
• Restores a clean, legible surface for touch or push-button operation
• Helps stop further cosmetic damage that can interfere with button visibility
• Addresses symptoms like cracked or chipped front surface, peeling finish, or a loose console face

• One control panel (console front) as shown

• Always disconnect power at the breaker or unplug the appliance before starting repairs
• Remove any trim pieces or screws holding the console in place; handle glass or painted surfaces carefully to avoid scratches
• Reattach all connectors and fasteners as removed; confirm proper alignment before tightening

The Coil Burner Element is an OEM replacement part for Frigidaire cooktops and ranges. The 6-inch coil burner element typically consists of a spiral-shaped metal resistance wire or rod that glows red-hot when electricity passes through it. This heat is then transferred to the cooktop surface, allowing it to reach the desired temperature for various cooking tasks, such as boiling, simmering, or sautéing.

Symptoms of a bad coil burner element:

• Burner not heating up properly or failing to reach the desired temperature
• Uneven heating or hot spots on the cooktop surface
• Visible damage or breaks in the coil wire
• Unusual smells or burning odors emanating from the burner area

Causes of a bad coil burner element can include mechanical failure, electrical malfunctions, or simply reaching the end of its lifespan due to repeated heating and cooling cycles.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore cooktops and ranges.

The Coil Surface Element is an OEM part for Frigidaire ranges and cooktops. It is a key component for cooking, providing the heat source directly under pots and pans. This 8 inch element is designed to heat quickly and maintain consistent temperature, which is essential for effective cooking and energy efficiency.

Symptoms of a bad Coil Surface Element include:

• The element not heating up when turned on
• Uneven heating or hot spots that can cause inconsistent cooking results
• The element not turning off or fluctuating in temperature

Causes of a bad coil surface element can include a breakdown of the coil itself due to general wear and tear, electrical connections becoming loose or corroded, or damage from spills or impacts during cooking.

This OEM part is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This drain pan collects normal defrost and condensation water under the refrigerator so moisture safely drains away from components and floors. It helps reduce leaks and supports proper defrost drainage. What it does:

• Catches and channels defrost and condensation water to the refrigerator drain system
• Prevents water from pooling under the cabinet and reduces risk of floor damage
• Sits in the appliance base and aligns with factory drain to ensure proper flow
• Commonly replaced when cracked, warped, or leaking and after long-term wear

• Disconnect power to the appliance before working underneath it
• Remove lower access panel or toe kick to access the pan; support the appliance if required
• Inspect surrounding drainage components and clean the drain path while replacing the pan
• If the pan mounts with fasteners or clips, reuse OEM hardware or replace with equivalent; do not overtighten

These chrome drip bowls sit beneath coil surface elements to catch spills and reflect heat. Sized for 8-inch and 6-inch burners, they refresh the cooktop's appearance and help elements seat correctly. What it does:

• Collects drips and splatters under coil elements and reflects heat back toward cookware
• Restores a clean look when originals are stained, pitted, or rusted
• Helps burners sit level and make solid contact with the cooktop
• Common signs to replace: heavy discoloration, rust, broken tabs, warping, lingering smoke or odor from burnt-on spills

• Two chrome drip bowls: one 8-inch and one 6-inch

• Disconnect power at the breaker and allow surface units to cool completely
• Pull the coil element straight out of its receptacle, then lift out the old bowl
• Align the new bowl's notches with the cooktop opening and seat it flat
• Reinsert the element fully and ensure it rests evenly in the bowl

The 6-inch Drip Pan is an OEM part for Frigidaire ranges. This drip pan sits beneath the heating element on the stovetop, catching spills, drips, and food debris that occur during cooking.

Causes of a bad drip pan can include corrosion from prolonged exposure to moisture, heat damage from the heating elements, or physical damage from heavy cookware.

Symptoms of a bad drip pan include:

• Rust or corrosion on the pan's surface
• Warping or bending of the pan
• Difficulty in cleaning due to burnt-on residue
• Visible holes or damage that allows spills to reach the underlying surface

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

The 8-Inch Drip Pan is an OEM replacement part for Frigidaire ranges. It is positioned below cooktop burners to catch drips and spills on the cooking surface.

Causes of a faulty drip pan include scorching or discoloration from prolonged high heat exposure. Mineral buildup over time can inhibit drainage.

Symptoms consist of:

• Excess moisture near surface elements or controls
• Grease residues left on cooktop after cleaning
• Premature corrosion underneath the range top
• Electrical issues tripped by liquid contact

This OEM Frigidaire replacement part is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This trim is a decorative finishing panel that restores the appliance's original appearance and covers exposed edges for a clean, factory look. It replaces damaged, cracked, or missing trim to improve cosmetic appearance. What it does

• Covers and protects exposed edges on the appliance surface for a finished look
• Hides gaps and fasteners for a clean, factory appearance
• Replaces cracked, chipped, or otherwise damaged trim that detracts from appearance
• Helps keep dirt and moisture out of exposed seams

• One trim piece as shown

• Disconnect power (and water, if applicable) before beginning any repair
• Remove any retaining screws or clips and carefully pry away old trim to avoid damaging adjacent surfaces
• Align new trim and secure with original screws or clips; do not overtighten fasteners
• Handle painted or chrome-finish trim with care to avoid scratching during installation

This decorative trim piece restores the finished appearance on the appliance door or control area and covers the mounting edges for a clean, factory look. Replaces a scratched, dented, or missing trim to improve appearance. What it does:

• Covers and protects the edge of the door or control opening to keep a finished appearance
• Hides fasteners and gaps for a smoother exterior surface
• Prevents dirt and moisture from collecting in the trim gap
• Restores original aesthetics after damage or during panel replacement

• One decorative trim piece

• Install with basic hand tools; align trim over mounting area before fastening
• Do not force or bend trim; inspect adjacent mounting tabs for damage
• Disconnect power to the appliance if installation requires removing electrical panels or access behind the trim
• Replace with OEM-specified fasteners for a secure fit

This is a replacement mounting screw used to secure the appliance power/control board, restoring a solid electrical board connection and preventing vibration or loose contacts. Ideal for repairs where the original screw is missing or damaged. What it does:

• Fastens the power/control board to the appliance chassis to keep connections stable
• Helps prevent board movement that can cause intermittent electrical issues or noise
• Restores proper mounting after service or component replacement

• Turn off and unplug the appliance before starting any repair
• Use appropriate screwdriver and avoid over-tightening to prevent board or thread damage
• Wear eye protection and keep small parts away from children and pets

This factory screw secures components in your appliance, restoring a tight, rattle-free fit. Replace missing or damaged hardware to keep panels, brackets, and trim properly fastened and aligned for safe, reliable operation.

• Secures panels, brackets, trim, or internal components to the chassis
• Replaces lost, rusty, stripped, or cross-threaded screws
• Helps eliminate looseness, gaps, and vibration/rattling
• Common signs: loose/misaligned panels or trim, rattling noises, missing or rounded screw heads

• Disconnect power (and shut off gas if applicable); allow the unit to cool completely
• Match to the original location and replace one at a time to maintain alignment
• Hand-start to prevent cross-threading; tighten snugly—do not overtighten
• Use light torque when threading into plastic or thin sheet metal

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
