Parts for Kenmore 790.94143313 (79094143313, 790 94143313): Top / Drawer Parts

This interior refrigerator liner replaces a damaged or worn cabinet surface to restore a clean, smooth interior and support shelves and drawers. It helps maintain a sanitary storage area and a proper fit for accessories. What it does:

• Provides a smooth, easy-to-clean interior surface for the fresh food compartment
• Restores mounting surfaces for shelves, bins and trim pieces
• Prevents drafts and moisture intrusion where cracks or gaps exist
• Addresses symptoms like visible cracks, gouges, or a warped/loose interior liner

• One refrigerator interior liner

• Disconnect power to the appliance before beginning any repair
• Removal typically requires taking out shelves, trim and fasteners to access the liner
• May require adhesive, clips or screws specific to the model—keep original fasteners and hardware

This glide restores smooth, aligned movement for a refrigerator or freezer drawer so the drawer opens and closes without sticking. Use it to replace a worn or broken glide and reduce scraping, binding, or uneven travel. What it does:

• Guides and supports the drawer so it tracks straight and slides smoothly.
• Replaces worn or damaged glides that cause drawers to stick, bind, or scrape.
• Helps prevent the drawer from coming off the track or shifting out of alignment.
• Reduces noise and uneven movement during opening and closing.

• Disconnect power (unplug the appliance) before servicing to avoid electrical hazards.
• Remove the drawer and any obstructing shelves per the OEM instructions to access the glide.
• Keep or replace original mounting screws; ensure the glide is oriented and seated correctly before tightening.
• Replace those parts to ensure a secure fit.

The Coil Burner Element is an OEM replacement part for Frigidaire cooktops and ranges. The 6-inch coil burner element typically consists of a spiral-shaped metal resistance wire or rod that glows red-hot when electricity passes through it. This heat is then transferred to the cooktop surface, allowing it to reach the desired temperature for various cooking tasks, such as boiling, simmering, or sautéing.

Symptoms of a bad coil burner element:

• Burner not heating up properly or failing to reach the desired temperature
• Uneven heating or hot spots on the cooktop surface
• Visible damage or breaks in the coil wire
• Unusual smells or burning odors emanating from the burner area

Causes of a bad coil burner element can include mechanical failure, electrical malfunctions, or simply reaching the end of its lifespan due to repeated heating and cooling cycles.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore cooktops and ranges.

The Coil Surface Element is an OEM part for Frigidaire ranges and cooktops. It is a key component for cooking, providing the heat source directly under pots and pans. This 8 inch element is designed to heat quickly and maintain consistent temperature, which is essential for effective cooking and energy efficiency.

Symptoms of a bad Coil Surface Element include:

• The element not heating up when turned on
• Uneven heating or hot spots that can cause inconsistent cooking results
• The element not turning off or fluctuating in temperature

Causes of a bad coil surface element can include a breakdown of the coil itself due to general wear and tear, electrical connections becoming loose or corroded, or damage from spills or impacts during cooking.

This OEM part is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

Main top replaces the cooktop surface on select ranges, restoring a flat, secure surface for burners and controls. It improves appearance and supports proper burner alignment for safer, more reliable cooking. What it does:

• Provides the primary cooktop surface and mounting for surface burners and elements.
• Restores a flat, undamaged surface when the original top is dented, warped, cracked, or cosmetically damaged.
• Secures burner assemblies and helps prevent burner wobble or misalignment.
• Improves cleanability and overall appearance of the cooktop area.

• Disconnect power (and gas supply for gas ranges) before beginning service.
• Remove burner grates, surface elements, and any trim; retain original hardware for reassembly.
• Large parts may require two people to position; use basic hand tools and follow model-specific service instructions.
• Verify burner alignment and function before completing reassembly.

Main top support rod.

A replacement hinge bracket that secures and aligns the refrigerator door, restoring proper pivot and fit for smooth opening and closing. Install this bracket to correct sagging or misaligned doors and improve door seal performance. What it does

• Secures the door hinge to the cabinet and supports door weight — use when the door droops or hangs unevenly.
• Maintains pivot alignment so the door opens and closes smoothly without binding.
• Helps keep the door gasket aligned for a tighter seal; can reduce uneven gaps and cold-air loss.
• Replaces bent, cracked, or worn hinge-mounting points that cause noise or instability.

• One hinge bracket.

• Disconnect power to the appliance before starting work and remove or support the door to prevent injury.
• Support the door while removing and installing the bracket; a second person may be needed for large doors.
• Reuse existing hinge hardware if undamaged; replace fasteners if stripped or missing.
• After installation, check door alignment and adjust hinge position as needed for a proper seal.

This Small Drip Pan is an OEM replacement part for Frigidaire ranges. The Frigidaire Small Drip Pan boasts a durable construction, made of high-quality materials to ensure long-lasting performance.

Over time, exposure to high heat, spills, and frequent cleaning can cause the drip pan to discolor, warp, or rust. A faulty drip pan can result in decreased efficiency and difficulty in maintaining a clean cooking area.

Symptoms of a bad Small Drip Pan include:

• Discoloration or rust
• Warping or misshaping
• Difficulty fitting properly beneath the burner
• Residual spills or drips reaching the burner area

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

The Large Chrome Drip Pan is an OEM replacement part for Frigidaire cooktops, designed to fit beneath the burner elements. It is responsible for providing a clean surface and maintain cleanliness. The drip pan catches spills and drips that occur during cooking, preventing them from reaching the interior of the stove where they can become burnt-on and difficult to clean. This large chrome drip pan measures approximately 8 inches in diameter.

Causes of a bad drip pan can include frequent exposure to high heat, spills, and regular cleaning, which can lead to discoloration, warping, or rust over time. When the drip pan becomes damaged or worn out, it may no longer effectively catch spills or reflect heat, affecting both cleanliness and cooking performance.

Symptoms of a bad part include:

• Visible signs of damage, wear, rust, or corrosion on the drip pan
• Uneven stove element
• Difficulty cleaning spills and grease accumulating on the pan
• Unsightly appearance of the stove
• Difficulty cleaning the stove surface

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Replacement wiring harness that connects control electronics to internal components, restoring proper electrical connections and reliable operation. Use when factory wiring is damaged, loose, or causing intermittent component failures. What it does:

• Routes power and signal between the appliance control board and internal components.
• Restores continuity when broken, frayed, or corroded wires cause intermittent or no operation.
• Can resolve symptoms such as non-responsive controls, lights or fans not running, or intermittent component operation.
• Keeps wiring neat and secured along original routing to prevent rubbing and stress.

• Always disconnect power (unplug or shut off breaker) before starting any repair.
• Match connector shapes and pin counts; route harness along original clips and pathways to avoid pinch points.
• Inspect mating connectors and terminals for damage or corrosion before reconnecting.

The Handle is an OEM replacement part for Frigidaire ranges and ovens. Designed for safety and ease of use, this handle allows intuitive opening and closing of the oven door. It provides a sturdy grip to safely access food inside the heating chamber.

Causes of a bad handle can include wear from frequent use over the years, damage from accidental impacts or mishandling, or issues with the mounting fasteners.

Symptoms of a bad handle include:

• Loose, wobbly or difficult operation of the handle
• The handle detaching from the oven door
• Inability to fully open or properly close the door
• Discomfort or safety issues when accessing the hot oven interior

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and select Kenmore range models.

This is a replacement mounting screw used to secure the dual safety valve assembly on compatible gas ranges and ovens. It restores proper fastening so the valve stays firmly in place during operation. What it does

• Secures the safety/dual gas valve to the appliance chassis or manifold
• Prevents valve movement that can interfere with burner operation or alignment
• Commonly replaced when original screw is missing, stripped, or damaged
• Matches OEM thread size and length for correct fit and retention

• One (1) screw, size 10-16 x 0.486

• Disconnect power and shut off gas supply before starting work; follow all safety procedures
• Thread carefully to avoid cross-threading; do not overtighten — snug to OEM torque specification
• Inspect surrounding mounting holes and hardware; replace any stripped or damaged parts for a secure fit

This is a replacement mounting screw used to secure panels and components in compatible Frigidaire appliances. It restores proper fit and helps prevent rattles, loose panels, and parts that shift during operation. What it does:

• Fastens trim, panels, brackets, or controls to the appliance frame
• Restores secure attachment to reduce vibration, noise, and movement
• Replaces stripped, missing, or corroded screws that prevent proper assembly
• Works wherever the OEM screw with this part number is specified

• Disconnect power to the appliance before beginning any repair
• Use the correct screwdriver or bit to avoid stripping the head
• Tighten until snug—do not overtighten to avoid stripping threads or damaging parts
• Keep removed hardware organized and compare parts to the old screw for correct fit

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
