Parts for Ge AZ38H15DABM2: 04 - Unit Parts

This condenser assembly replaces the refrigerator's condenser coil to help dissipate heat from the cooling system and maintain proper cooling performance. It's a direct-fit service part used during condenser or cooling repairs. What it does:

• Condenses refrigerant from gas to liquid so the refrigerator can reject heat
• Helps maintain correct operating temperature by allowing efficient heat transfer
• Commonly replaced when condenser damage, corrosion, or restricted airflow impairs cooling
• Can reduce compressor run time and improve cooling consistency when functioning properly

• One condenser assembly

• Ensure power is disconnected before service
• Handle coils carefully to avoid bending fins or causing punctures to refrigerant lines
• May require removal of rear access panels and reconnection of mounting brackets; follow OEM service instructions

A rubber compressor cushion that isolates the compressor from the refrigerator chassis to reduce vibration and prevent metal-on-metal contact. Replaces worn or missing cushions to help minimize noise and vibration transfer. What it does:

• Cushions the compressor to dampen vibration and reduce rattling or buzzing noises.
• Keeps the compressor from directly contacting the cabinet, preventing wear and chafing.
• Helps maintain proper compressor positioning and reduces stress on mounting components.
• Common symptom: increased compressor noise or vibration, or visible worn/deteriorated cushion.

• One compressor cushion (rubber mount).

• Disconnect power to the appliance before starting any repair.
• Support the compressor or secure the unit when removing/replacing mounts to avoid strain.
• Remove the old cushion and press the new cushion into place; no refrigerant handling required.
• Use basic hand tools and wear gloves.

The Compressor Cushion is an OEM replacement part for GE refrigerators and air conditioners. It is designed to absorb vibrations and reduce noise generated by the compressor during operation. This cushion helps stabilize the compressor, ensuring smooth and quiet performance while protecting adjacent components from excessive wear.

Over time, compressor cushions can deteriorate due to heat, vibration, or regular wear and tear. A damaged or missing cushion may lead to increased noise, vibrations, and potential strain on the compressor and surrounding parts.

Symptoms of a bad or missing compressor cushion include:

• Excessive noise or vibrations during operation
• The compressor appearing loose or unstable
• Increased wear or damage to nearby components
• Reduced efficiency or uneven performance of the appliance

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This compressor cover is a molded protective housing that fits over the refrigerator compressor to shield components and help manage airflow. It restores a finished appearance and helps keep debris and pests away from the compressor area. What it does:

• Protects the compressor and electrical connections from dust, dirt and accidental contact
• Helps direct airflow around the compressor for proper ventilation
• Reduces exposure that can allow pests or debris to interfere with components
• Addresses symptoms like an exposed/cracked cover, rattling from loose or damaged housing, or visible compressor components

• One compressor cover (1 pc) as shown

• Disconnect power to the appliance before accessing the rear lower compartment
• Move the refrigerator away from the wall to access the compressor area; two people may be needed for safe handling
• Remove any mounting clips or screws before lifting the old cover off; align and secure the replacement until clips engage
• Wear gloves and eye protection; avoid bending or forcing the cover to prevent breakage
