Parts for Ge GEH80DFEJSRB: Unit Parts

This SCR 8-18 silicon-controlled rectifier replaces the control semiconductor that switches and regulates power to heating or motor circuits in compatible appliances, restoring proper power delivery and control. It's a direct-fit electrical replacement part. What it does

• Acts as a switching device on control boards to allow or block current flow when signaled.
• Regulates power delivered to heating elements or motor circuits to enable proper operation.
• Commonly linked to symptoms like no heat or intermittent heating, motors that won't start, or erratic control-board behavior.
• Helps restore reliable on/off control when a failed SCR is causing open or shorted conditions.

• One SCR 8-18 silicon-controlled rectifier (WD02X10160).

• Always disconnect power before servicing the appliance to avoid shock.
• Handle the part carefully; avoid touching leads and use anti-static precautions if available.
• Inspect surrounding connectors and wiring for damage; replace any corroded terminals.

A flat metal washer used to secure fasteners and distribute load on a washer's assemblies. Replaces worn or missing washers to help maintain proper alignment and reduce metal-on-metal wear. What it does:

• Sits under a nut or bolt head to spread clamping force and protect mating surfaces
• Helps keep fasteners tight and resists loosening from vibration
• Prevents wear and damage to softer components where hardware clamps
• Common symptom: loose or missing washer causing rattling, vibration, or misaligned parts

• One flat metal washer

• Disconnect power and water supply to the appliance before beginning any repair
• Use appropriate hand tools; avoid excessive torque that can deform the washer
• Inspect adjacent fasteners and replace any damaged hardware

This compressor overload protector helps shut off a refrigerator compressor when electrical overload or heat risks occur, protecting the compressor from damage and keeping the cooling system more reliable. What it does:

• Interrupts compressor current during overheating or electrical overload to prevent motor damage.
• Works with the compressor start device/relay to allow proper motor start and run behavior.
• Common symptom linkage: refrigerator not cooling and compressor runs hot, hums, or cycles rapidly.
• Common symptom linkage: compressor will not start but attempts to run or clicks.

• One compressor overload protector.

• Disconnect power to the appliance before inspecting or replacing the overload; follow all safety precautions.
• Handle terminals gently and install in the same orientation; ensure secure electrical connections and proper seating on the compressor.
• If the compressor or start relay shows other damage, inspect the entire start device assembly and wiring; replace any damaged components before restoring power.

This mastic thermal sensor detects oven temperature and helps the control board monitor and regulate heat for safe, consistent cooking. It's a direct-replacement temperature sensing element used where a mastic-mounted sensor is required. What it does:

• Senses appliance temperature and sends a signal to the control module for temperature regulation
• Helps prevent overheating by allowing the control to reduce heat when temperatures exceed set points
• Commonly replaced when an oven runs too hot, won't reach set temperature, or shows temperature-related errors
• Designed for mastic- or adhesive-style mounting to maintain stable thermal contact

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Handle the sensor and lead wires carefully; avoid kinking or stressing the sensing element
• Install in the same orientation and mounting location as the original to ensure proper temperature readings

This is a grommet and it is intended for use on refrigerators and freezers. This is a genuine replacement part made by General Electric. A new grommet might be needed if the current one is visibly worn out or damaged in any way. If there are noises from vibration coming from the lower back area of the fridge there might be need for a new grommet. This is an OEM part sourced directly from the manufacturer, and it is sold individually. It is compatible with refrigerators and freezers, or units with a compressor and is made by General Electric.
