Parts for Bosch HBL765AUC/01: Upper Body Parts

This genuine right rail support secures the dishwasher rack slide and keeps the lower rack aligned for smooth movement and stable loading. It replaces a missing or damaged support to restore proper rack tracking and reduce wobble. What it does:

• Supports the right side rack rail so the lower rack slides straight and evenly
• Prevents rack misalignment, catching, or wobbling during insertion and removal
• Replaces cracked, broken, or missing plastic support pieces that let the rack sag
• Works with the existing rail and rollers to restore normal rack motion

• One right rail support (black), as shown

• Disconnect power to the appliance before starting any repair
• Remove the lower rack to access the rail support; common hand tools may be required
• Inspect rails and rollers for damage and replace any worn components for best results
• Handle plastic parts carefully to avoid cracking during installation

This oven door hinge switch detects when your oven door is opened or closed, automatically controlling the interior light and sometimes stopping operation for safety. It ensures the light turns on when you open the door and may disable heating elements. Replace this part if the oven light doesn't work, stays on constantly, or if the oven won't operate with the door closed.

This support piece mounts inside the oven cavity and holds oven racks or shelves securely in place. It attaches to the interior side wall and provides a stable ledge for the rack to rest on. Replace this part if oven racks are tilting, sliding out of position, or if the original support has broken or bent.

M4.2 x 9.5mm mounting screw for wall ovens. Secures interior panels, brackets, and components. Replace if stripped, missing, or damaged during repairs.

Insulation pad for electric wall ovens. Installs between the oven cavity and outer panel for heat retention. Replace if worn, torn, or missing.

This is a frying pan designed for use inside a wall oven or range. It sits on the oven rack and is used for stovetop-style cooking tasks such as frying or searing within the oven cavity. Replace this pan if it is warped, the coating is damaged or peeling, or if it no longer sits flat on the rack.

This is the left hand hinge kit. This kit now includes the hinge, hinge housing, microswitch assembly, wire harness and instructions. For the right hand side order 00493360.

This is the left hand hinge kit. This kit now includes the hinge, hinge housing, microswitch assembly, wire harness and instructions. For the right hand side order 00493360.

This is the right hand hinge kit. For the left hand side order 00493358.

This is an insulating component designed to fit around the hinge area of a range or oven door. It prevents heat transfer through the hinge mechanism and protects nearby switches or electrical components from excessive temperatures. Replace this part if the insulation is worn, cracked, or missing, which can lead to overheating of adjacent components or inconsistent door operation.

This outer cover protects and secures the catalyzer element, keeping it in position and shielding it from debris and contact damage. It helps maintain safe operation by preventing movement and minimizing noise from a loose element. What it does

• Protects the catalyzer element from physical damage and foreign debris
• Holds the catalyzer element securely in its mounting location
• Reduces vibration and rattling that can occur with a loose or damaged cover
• Helps maintain correct airflow/clearance around the catalyzer element

• Disconnect power (and gas supply where applicable) before beginning work
• Handle the part carefully to avoid bending or cracking the cover
• Reuse original fasteners only if undamaged; otherwise replace with OEM-specified hardware
