Parts for Ge ZTD90DPSN1SS: Upper Door Parts

This door insulation retainer is a small plastic clip that secures insulation inside a refrigerator/freezer door to help maintain proper temperature and reduce noise. It replaces worn or missing retainers to keep the door liner insulation in place. What it does:

• Secures the door insulation to the inner door liner so insulation stays positioned
• Helps prevent insulation from shifting or sagging that can affect door seal performance
• Commonly used when insulation falls out or the liner shows gaps around the insulation
• Works as a direct-fit replacement for the original retainer designed for the door assembly

• One door insulation retainer clip

• Installation generally requires removing the door panel or liner; keep track of fasteners and trim
• Handle the door liner and insulation carefully to avoid damage or tearing the insulation
• Use proper tools and disconnect power if working near electrical components or lights
• Replace all affected clips for an even, secure fit

This door liner plug snaps into the inner door liner to cover fastener or access holes. It restores a clean, finished look and helps keep grease and debris from entering the door assembly.

• Covers exposed holes in the inner door liner
• Replaces a missing, loose, or damaged plug/cap
• Helps protect the door cavity from splashes and debris
• Restores a neat, factory-finished appearance

• Disconnect power before servicing; for gas ranges, also shut off gas. Allow the appliance to cool completely.
• Open the door and gently pry out the old plug with a plastic trim tool or flat-blade screwdriver.
• Align and press the new plug into the liner until it seats flush.
• Support glass and follow the manufacturer's instructions.

A replacement liner support that secures the refrigerator cabinet liner and keeps interior trim and panels aligned for a proper seal and appearance. Restores stability to cracked or broken support points. What it does:

• Holds the cabinet liner and interior trim in position to prevent gaps and movement
• Helps maintain door seal alignment by keeping liner edges stable
• Reduces rattling or shifting caused by a damaged support
• Commonly replaced when liner pieces are cracked, broken, or loose

• One liner support

• Disconnect power to the appliance before beginning any repair
• Remove food, shelves, and trim pieces as needed to access the damaged support
• This part typically secures with clips or fasteners; inspect existing hardware and replace if necessary

This mounting stud secures appliance panels and components in place, restoring proper alignment and stability. It's a simple replacement that helps stop rattling and keeps parts seated correctly for safe operation. What it does:

• Secures panels, brackets, or assemblies to the appliance frame
• Restores proper alignment when a stud is bent, stripped, or missing
• Reduces rattling or vibration caused by loose or damaged fasteners
• Helps maintain safe, stable mounting for controls and internal parts

• Disconnect power to the appliance before servicing.
• Use appropriate hand tools; avoid cross-threading the stud.
• Do not overtighten—tighten until snug to prevent damage.
• If threads are damaged, replace the mating nut or insert as needed.

The Window Pack Assembly is an OEM part for GE ovens. This component includes the oven door window and its associated parts, providing visibility into the oven cavity during cooking. It helps retain heat within the oven while allowing users to monitor the cooking process without opening the door.

Causes of a bad window pack assembly can include thermal stress from repeated heating and cooling, accidental impact, or general wear and tear. A damaged window can compromise the oven's efficiency and safety by allowing heat to escape.

Symptoms of a bad window pack assembly include:

• Cracks or damage to the window glass
• Heat escaping from the oven door
• Condensation or discoloration between the window panes
• Difficulty seeing through the window during cooking

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This set screw secures refrigerator components—most commonly door handles—to their mounting studs. Replacing a missing or stripped screw restores a solid, secure feel and helps prevent loose or wobbly handles.

• Locks the handle to its mounting stud to keep it tight and secure
• Helps resolve a loose, wobbly, sliding, or rattling handle
• Replaces a missing, rounded, or damaged set screw
• Helps maintain proper handle alignment and consistent door operation

• Unplug the appliance or switch off power before servicing
• Ensure the handle is fully seated on the studs before tightening
• Start the screw by hand to avoid cross-threading; then tighten until snug
• Do not overtighten to prevent stripping the screw or handle threads

This left-hand handle support secures the refrigerator door handle to the cabinet, restoring a solid grip and proper door alignment. It replaces a worn or broken support so the handle stays mounted and functional. What it does:

• Anchors the left side of the refrigerator door handle to the cabinet or door.
• Restores handle stability when original support is cracked, loose, or missing.
• Helps maintain proper door alignment and user grip.
• Fits where the OEM support left handle is specified.

• One left-hand handle support.

• Designed for direct replacement; match part number before ordering.
• Use basic hand tools; keep screws and clips removed during disassembly.
• Disconnect power or follow appliance-specific safety steps if required by your model.
• Order replacements separately.

This right-side support handle secures and stabilizes the appliance door or panel, restoring proper alignment and making opening and closing easier and safer. It replaces a cracked, loose, or missing right support handle. What it does:

• Provides structural support for the right side of the door/panel to maintain alignment
• Restores a solid grip for opening and closing when the original handle is damaged
• Prevents further wear or stress on adjacent door parts caused by a loose handle
• Commonly used when customers observe a cracked, bent, or loose handle on the right side

• One right support handle

• Disconnect power or unplug the appliance before starting any repair
• Remove trim or access panels as required; hardware may be reused if undamaged
• Hand-tighten fasteners, then snug—avoid over-tightening which can crack plastic parts

This 1/4-20 hex nut secures threaded studs and bolts on appliances, providing a simple, reliable fastening point to keep panels, brackets, and components in place. Ideal for repairs where a worn or missing nut causes looseness or rattling. What it does:

• Fastens to 1/4-20 threads to lock panels, brackets, or assemblies together
• Restores secure mounting where a stripped, corroded, or missing nut causes movement
• Helps stop vibration-related noise by holding parts tightly
• Small hardware solution used in many appliance fastening applications

• One 1/4-20 hex nut

• Use the matching 1/4-20 bolt or stud; thread fit before tightening
• Hand-start the nut to avoid cross-threading, then tighten with the appropriate wrench
• Do not overtighten to prevent stripping threads or damaging components
• Disconnect power and follow appliance-specific safety instructions before working

This stop door is a replacement component used in the oven dehydrate function to help control airflow and temperature during low-heat drying cycles. Replacing a worn or broken stop door restores proper drying performance and cycle control. What it does

• Serves as the oven's dehydrate stop door, helping direct airflow for low-temperature drying
• Helps maintain stable conditions during dehydrate cycles so food dries evenly
• Common symptom: dehydrate cycles fail to dry food properly or produce uneven results
• Common symptom: cracked, warped, or missing stop door that interferes with airflow or closing

• One stop door

• Disconnect power to the appliance before attempting any repair
• Handle the part carefully to avoid bending or damaging mounting tabs
• Basic hand tools may be required; follow the oven's service manual for disassembly/reassembly steps
