Parts for Bosch DHD9605UC/01: Vent System Parts

This replacement rack rail guides the dishwasher upper rack so it slides smoothly and stays aligned during loading and unloading. Replaces a worn or broken rail to restore proper rack movement and prevent binding or derailment. What it does:

• Provides a stable track for the upper rack to roll in and out smoothly
• Prevents the rack from falling off or catching on the cabinet opening
• Restores proper alignment when the original rail is bent, cracked, or broken
• Helps rollers and bearings engage correctly for quiet operation

• One rack rail (upper, right) as shown

• Inspect rollers and mounting clips; replace any damaged components for best results
• Secure part to the rack frame and cabinet slide per the appliance's service instructions
• Disconnect power and water supply to the appliance before beginning repairs

The Transformer is an OEM part for Bosch downdraft ranges. This part is responsible for converting the electrical voltage to the appropriate levels required by the range hood, enabling efficient operation of the lighting and fan systems.

Causes for the need to replace the transformer may include electrical surges that damage the internal components, natural wear over time affecting the transformer's efficiency, or overheating due to blockages or excessive buildup in the vent hood that strains the electrical system.

Symptoms of a failing Transformer include:

• The range hood lights or fan not working correctly or not turning on at all, suggesting electrical issues.
• Unusual noises or humming sounds from the transformer area, indicating potential electrical faults.
• Intermittent operation of the range hood, which can be frustrating and reduce the effectiveness of your kitchen ventilation.

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This flexible sealing strip replaces a worn or damaged door seal to restore a tight closure and help prevent leaks and energy loss. It fits into the door channel to maintain proper sealing and appliance performance. What it does

• Creates a continuous seal along the door edge to reduce water leaks and air infiltration
• Helps maintain consistent internal temperature and energy efficiency
• Reduces vibration and rattling from a loose or damaged seal
• Common symptom fix: visible gaps around the door, water pooling, or fluctuating temperatures

• Disconnect power and turn off water before starting any repair
• Remove the old sealing strip fully and clean the mounting channel of debris and adhesive residue
• Press the new strip into the channel evenly; trim excess if necessary for a proper fit
• Some installations may require adhesive or retaining clips;

This is a replacement mounting bracket that secures appliance panels and components to restore proper alignment and stability. It helps prevent loose panels, rattling, and misaligned doors or trim when the original bracket is damaged or missing. What it does

• Secures panels, trim, or internal components to the appliance frame
• Restores proper alignment to doors or access panels
• Reduces vibration and rattling caused by a loose or broken bracket
• Provides a sturdy anchor point for screws or fasteners

• Turn off power and water (if applicable) to the appliance before starting any work.
• Use appropriate hand tools; avoid overtightening fasteners to prevent damage.
• Support panels or components while removing the old bracket to prevent pinching or dropping parts.

This cover is a molded trim piece that restores the appliance's finished appearance and protects underlying components from dirt and damage. It replaces broken or missing covers to improve safety and maintain proper operation. What it does:

• Conceals and protects internal components behind the appliance cabinet or control area
• Prevents debris buildup and accidental contact with exposed parts
• Restores the original cosmetic appearance where the cover was damaged or missing
• Common symptom: cracked, broken or missing cover leaving components exposed

• One replacement cover as shown

• Disconnect power (unplug or switch off breaker) before beginning any work
• Installation typically requires removing adjacent trim or a few screws; keep hardware for reassembly
• Handle carefully to avoid scratching the finish and ensure clips/tabs fully engage

This replacement sheet is a thin internal protective panel used in select Bosch appliances to cover or shield components and surfaces, helping restore original fit and finish. What it does:

• Replaces a torn, missing, or damaged internal protective sheet
• Protects wiring, hoses, and components from abrasion and contact
• Helps maintain proper spacing and panel alignment to reduce rattles or vibration
• Restores the appliance's internal appearance where the original sheet was installed

• One replacement sheet as shown

• Disconnect power and water to the appliance before beginning any repair
• Remove only the panels needed to access the sheet; keep track of fasteners
• Handle sheet carefully to avoid bending or creating sharp edges; wear gloves as needed

This metal mesh coarse filter is a direct-replacement sump filter that captures food particles and debris to help protect the dishwasher pump and keep wash water flowing freely. It restores proper filtering so the dishwasher can drain and rinse effectively. What it does

• Traps large food particles and debris in the sump to prevent them from recirculating during cycles
• Protects the wash pump and drain system from clogging and damage
• Helps reduce leftover food on dishes and improves overall cleaning performance
• Common symptom indicators: persistent food/particles on dishes, poor draining, or unusual pump noise

• One (1) metal mesh coarse dishwasher filter

• Always disconnect power and turn off water supply before servicing the appliance
• Remove the lower rack and access the sump area to remove the old filter (twist/pull style or lift out, depending on model)
• Clean the sump area and seating surface before installing the replacement; ensure the filter locks/seats securely
• Run a short rinse cycle to verify proper fit and operation after installation

This metal mesh coarse filter is a direct-replacement sump filter that captures food particles and debris to help protect the dishwasher pump and keep wash water flowing freely. It restores proper filtering so the dishwasher can drain and rinse effectively. What it does

• Traps large food particles and debris in the sump to prevent them from recirculating during cycles
• Protects the wash pump and drain system from clogging and damage
• Helps reduce leftover food on dishes and improves overall cleaning performance
• Common symptom indicators: persistent food/particles on dishes, poor draining, or unusual pump noise

• One (1) metal mesh coarse dishwasher filter

• Always disconnect power and turn off water supply before servicing the appliance
• Remove the lower rack and access the sump area to remove the old filter (twist/pull style or lift out, depending on model)
• Clean the sump area and seating surface before installing the replacement; ensure the filter locks/seats securely
• Run a short rinse cycle to verify proper fit and operation after installation

The Spring Guide is an OEM part for Bosch range hoods. This spring guide attaches directly to the cushion spring bracket, serving to securely hold the cushion spring in the proper position. It plays an integral role in dampening vibrations and absorbing shocks generated by the range hood fan and motor.

Causes of a bad spring guide can include fatigue of the material over many years of operation, breakage or cracks developing due to repeated use and mechanical stresses, or damage during cleaning or servicing of the range hood components.

Symptoms of a bad or failing spring guide include:

• Increased vibration transferring to kitchen cabinets during high fan speeds
• Louder operating noise levels from the range hood
• Possible interference with normal spring and bracket operation
• Reduced vibration damping performance of the cushion spring assembly

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This door/interlock switch completes the electrical circuit when the appliance door is closed, allowing the unit to start and run. Replacing a faulty switch restores reliable door detection and normal operation. What it does:

• Detects door closure and enables the appliance to power on
• Prevents operation when the door is open for user safety
• Stops intermittent starts or control lockouts caused by a bad switch
• Helps eliminate symptoms like no-start, no power to controls, or cycle interruptions

• One replacement door/interlock switch

• Disconnect power (unplug appliance or shut off breaker) before installing
• Access typically requires removing the control panel or door inner panel; follow your model's service sheet
• Verify connectors and actuator alignment before reassembly

This electronic control module manages the appliance's timed cycles and user interface, restoring reliable control over functions like starting, stopping and cycle sequencing. Replaces a failed or unresponsive main control board to bring back normal operation. What it does

• Receives input from buttons/knobs and runs the selected cycle program
• Controls power to motors, pumps, valves and heaters based on cycle logic
• Monitors sensors and timings to advance or pause cycles
• Common symptom: appliance won't start, stops mid-cycle, or shows unresponsive controls

• One control module

• Disconnect power before beginning service to avoid shock or damage
• Handle the board by edges and avoid static discharge; wear an ESD strap if available
• May require removing exterior panels or console to access the module
