Parts for Weedeater SV22: Weed Eater Parts

This authentic OEM replacement on/off switch is a safety measure that manufacturers install to prevent the chainsaw or trimmer from starting before the operator is ready. It also allows the operator to stop their appliance at a moment's notice if they lose control of it. The on/off switch is located in or near the handle of the appliance and must be in the on position for the appliance to start. If hit to the off position, the appliance will immediately stop running. Switches can slowly wear out over time due to repeated use. When it wears out, the switch will no longer give the same amount of resistance and may be tripped more easily. This can be frustrating as it means that the operator would have to continually restart their appliance. To replace the switch, use a screwdriver to access the handle interior and detach the wiring from the old switch. Install the new part and reassemble. This switch is a high-quality replacement part for Craftsman chainsaws and trimmers, and as such, it comes sourced directly from the original manufacturer. This part ships individually.

This is a genuine fuel cap with retainer that is designed as a replacement for select outdoor lawn and garden equipment engines. The fuel cap is responsible for sealing the fuel tank, providing an airtight fit and securing the fluid inside the tank to prevent fuel spills during use. The plastic retainer holds the cap in place when it is open. Both parts could become damaged over time and the retainer could detach entirely. If this occurs, it is best to replace the entire unit.This OEM fuel cap with retainer is manufactured by MTD and designed for use in machines from the brand, as well as those from Yard Man, Husky, Bolens, and Yard Machines. It screws on and requires no tools for installation. The retainer simply fits into the fuel tank to secure the cap when it is open. This cap is sold as an individual part and does not include any additional hardware or a new fuel tank. If the fuel tank itself is damaged and needs replaced, that will require an additional purchase. This fuel cap with retainer will ensure that fuel stays secured and that the unit can run properly at all times.

The Fuel Pick Up Assembly is an OEM part for Husqvarna outdoor power equipment, including chainsaws, trimmers, and blowers. This assembly is responsible for drawing fuel from the tank to the carburetor, ensuring the engine receives a steady supply of fuel for optimal performance.

Over time, the fuel pick up assembly can become clogged or damaged due to debris in the fuel, exposure to ethanol-blended gasoline, or regular wear and tear. If the fuel pick up assembly is compromised, it can lead to poor engine performance or difficulty starting the equipment.

Symptoms of a bad fuel pick up assembly include:

• Engine not starting or hard to start
• Engine stalling or running inconsistently
• Reduced power or performance
•  Visible damage or clogging in the fuel line

This OEM Husqvarna part ensures proper fuel delivery and compatibility with your outdoor power equipment.

This wrist pin retainer is an essential component that is used to secure the piston pin in many types of handheld lawn and garden equipment. The pin is made of durable metal, but if it is missing or has become damaged, the part will need to be replaced. A wrench set, screwdriver, and pliers will be needed to make the replacement. To replace the wrist pin retainer, get access to the piston and then take off any keeper rings included. Use tools to tap on the wrist pin retainer to make it come loose and take it out of the equipment. The replacement can be inserted into the same place and the equipment will need to be reassembled.This is a genuine OEM replacement part that is sourced directly from the manufacturer. The wrist pin retainer is designed to be used in trash compactors, string trimmers, leaf blowers, edgers, hedge trimmers, chainsaws, pole pruners, and carpet cleaners manufactured by Turf King, Craftsman, Paramount, Husqvarna, Broan, Weed Eater, Poulan, and Poulan Pro. The part is sold individually.

This is a genuine carburetor screw that is designed to replace missing or broken screws in certain lawn and garden equipment engines. On select models of small engines, there are two carburetor screws that are used to secure the carburetor to the rest of the engine assembly. These screws are made of durable material, but also constantly exposed to high heat and constant vibrations. They may become worn, damaged, or even snap off entirely as a result. They sometimes also get lost in the process of other repairs and will need to be replaced. This genuine OEM part will offer the solution for compatible engines. This OEM carburetor screw is compatible with hedge trimmers, edger/trimmer models, and blowers that use the appropriate engine. There are over 150 models that take this carburetor screw, including those from Husqvarna, Paramount, Weed Eater, Jonsered, and Poulan. This durable screw is sold as a single unit and features a hex socket head, so be sure to have the proper tool for installation. Those who need to replace both screws will have to purchase two separately. Be sure to allow the engine to cool completely and wear gloves whenever replacing screws or performing other engine repairs.

This is a wave washer, also called a wave spring washer, that is used in many types of lawn and garden equipment. The wave washer is a small metal disc with a hole in the middle. Rather than being flat like most washers, the wave washer has waves that offer three, four, or six points of contact to better carry a load and create a large range of deflection.As the equipment containing the wave washer is used, it can experience damage or wear and tear. When this happens, the wave washer will not operate as expected by holding the load and assisting other components in the equipment. The equipment will need to be disassembled to reach the wave washer. Remove any parts in the way and remove the old component before replacing it with a new part.This is an authentic OEM replacement part that has been sourced directly from the manufacturer. The wave washer is sold as an individual part. The washer is made to be compatible with string trimmers, leaf blowers, chainsaws, carpet cleaners, and trash compactors manufactured by Turf King, Paramount, Broan, Poulan, Poulan Pro, Weed Eater, Husqvarna, and Craftsman.

This part is a carburetor assembly kit that is used on blowers, trimmers, and chainsaws. The carburetor is designed to supply a mixture of air and fuel to the engine. The carburetor is manufactured out of metal on the body and plastic on the lever. We recommend replacing the gaskets at the same time, although they will need to be ordered separately. A new carburetor assembly kit may be needed if the outdoor power equipment will not stay running or if it won't start at all. Remember to wear gloves when operating or performing care and maintenance on any outdoor power equipment.This carburetor assembly kit is a genuine Husqvarna part. It is sold individually. This particular carburetor assembly kit is compatible with blowers, trimmers, and chainsaws that are manufactured by Husqvarna, Weed Eater, Poulan, Jonsered, and Paramount.

This carburetor gasket is a genuine Husqvarna part, sold individually. This carburetor gasket can be used as a replacement part in a leaf blower or a string trimmer. This component creates a seal in the carburetor, ensuring it is not contaminated by outside debris.The carburetor gasket in a leaf blower or a string trimmer might have to be replaced if it is blown or broken. This could occur if the carburetor gasket is punctured, dented, cracked, warped, eroded, or otherwise damaged.This is a genuine OEM replacement part sourced directly from the manufacturer. It is sold individually. This carburetor gasket is compatible with the following outdoor appliance brands: Husqvarna, Craftsman, Weed Eater, Poulan, Poulan Pro, and Paramount.

This replacement part is a foam seal. This part is compatible with weed eaters and is responsible for sealing components off to ensure there are no leaks in the machinery.It is not unusual for foam seals to be damaged within the standard lifespan of the equipment. Damage to a foam seal can include being torn, shredded, or ripped in half. Be sure the equipment is powered down and cooled off before replacing or repairing this part. This is a genuine OEM replacement part manufactured by Husqvarna. This part is sold individually.

This is a genuine tapping screw replacement uses in certain models of outdoor lawn and garden equipment engines. This replacement screw is standard hardware on several units, and it has a variety of applications. Owners will need to consult their parts diagram for exact location and use. The screw is made of durable metal, but it is also exposed to constant heat and vibrations when the machine is in use, which can cause wear, damage, or even breakage over time. In some cases, the screw may become loose or get lost in the course of other repairs. In this case, a replacement will also be necessary. It's best to choose a genuine OEM screw like this model from Poulan. This screw is compatible with several blowers, saws, trimmers, and hedge trimmers from Poulan, as well as select units from Weed Eater, Jonsered, Paramount, and Husqvarna. A hex screwdriver or allen key will be required to replace this screw. Be sure to wear gloves and allow equipment to cool before working. This general use screw might be good to purchase in multiples to keep extras on hand in case of emergency. Each screw is sold as an individual part.

This is a reed valve found in many types of lawn and garden equipment. The reed valve is a single-direction valve that is located near the inlet port. This component lets a mixture of fuel and air into the crankcase while preventing it from coming back out of the same part. A reed valve moves from open to closed and back again based on the level of pressure within lawn equipment. Over time, the reed valve can experience issues like chipping, breaking, loosening, or bending. When these things happen, the valve reed will need to be replaced.To access the reed valve, remove the rear cover of the machine. The carburetor must also be removed to get access to the reed assembly. Take the reed valve out of the mounting assembly and install a new replacement part.This is an authentic OEM replacement component that is sourced directly from the manufacturer. It is sold as an individual component. The reed valve is used with string trimmers, pole pruners, and leaf blowers manufactured by Craftsman, Husqvarna, Paramount, Poulan, Poulan Pro, and Weed Eater.

This replacement part is a screw and is intended for use in a variety of lawn equipment. This is a genuine replacement part made by Husqvarna. Screws are an important part of many different types of machinery as they hold other parts in place and secure. A new screw might be needed if the current ones are loose or missing. It is common that screws might become stripped overtime and will need to be replaced. Be sure to double check the size of the screw as many places on lawn equipment will require different size screws. Be sure the appliance is completely powered down and cooled off before attempting to repair an appliance. For more detailed instructions on how to install this specific part, see the owner's manual. This is an OEM part sourced directly from the manufacturer. It is sold individually. This replacement part is compatible with different types of lawn equipment made by Husqvarna.

This replacement part is a crankshaft assembly. This is a genuine replacement part made by Husqvarna. This specific part is an extremely important part of the engine in many machines. The crankshaft assembly is responsible for converting linear motion to a rotational motion.A new crankshaft assembly might be needed if the engine is running, but the proper operations are not being performed. This can be due to the fact that the crankshaft is no longer converting energy properly and should be replaced as soon as possible. Be sure the engine is completely shut down before attempting to replace this part. Work gloves are also recommended during this repair. This crankshaft assembly is a genuine OEM replacement part to ensure proper fit. This part is sold individually and is sourced directly from the manufacturer.

Known as a starter rope, this part is used to start the engine of the tool and wraps around the recoil pulley. The pulley and return spring spin to begin the firing of the spark plug for the engine to run. The rope can malfunction and create problems or even prevent the engine from starting. The most common cause for replacement is when the rope splits or starts to fray and doesn’t operate as usual. A tangled kit rope can also make the rope hard to pull to start up the engine before doing yard work. Users who experience excess rope or a knot on their kit rope when starting the engine may need to look into replacement. This Husqvarna Kit Rope is a component that attaches to chainsaws, hedge trimmers, string trimmers, and leaf blowers. This is a genuine OEM product directly from the manufacturers and is sold individually. It can be used with many models from Husqvarna, RedMax, Craftsman, McCulloch, Poulan, Weed Eater, Paramount, and Homelite. Installation requires only a pair of pliers, a screwdriver, and a Torx screwdriver. Other products that may be needed include a pulley and starter spring.

This is a carburetor rebuilt kit made for use with gas powered chainsaws. It comes with many parts, including gaskets and diaphragms, that can get a chainsaw running properly again if there are issues with the carburetor. The carburetor is an important component of the chainsaw that ensures the right amount of gas and air reach the cylinder to ignite. The main symptom of carburetor issues is an engine that won't start even when the tank is full of fuel.There's a simple test to determine if the carburetor has an issue inside the chainsaw. The air filter will need to be removed from the equipment before a small amount of fuel is added directly to the carburetor. If the carburetor has problems, the engine will start for a short time before shutting off. Replacing or repairing the carburetor will be required.This carburetor rebuild kit is a genuine OEM replacement part that is directly sourced from the manufacturer. It is sold as an individual kit with several components. The kit is made for use with chainsaws manufactured by Zama and Stihl.

This part is a screw. This is a genuine Husqvarna replacement screw and has been sourced directly from the manufacturer. This replacement part is intended to replace missing or broken screws in a number of different small outdoor power equipment models.With regular usage, screws can easily become stripped, rusted, or lost. This can lead to improper functionality of outdoor power equipment. It's important to use genuine manufacturer replacement screws to ensure the highest-quality materials and a proper fit that will keep equipment in good working order. When installing screws, always follow proper guidelines and abide by appropriate safety measures. Husqvarna screws are manufactured from high-quality, durable material. This replacement part is a high-quality piece of standard hardware with many different applications. For proper installation and usage guidance, it is recommended to refer to the equipment manufacturer diagram.This replacement screw is designed to fit various models of Husqvarna, Craftsman, Poulan, and Weed Eater trimmers and hedge trimmers, blowers, and chainsaws. Please note this screw is a genuine OEM part and is sold individually.

This retainer is a genuine Husqvarna part, sold individually. This retainer can be used as a replacement part in a string trimmer or a leaf blower. The purpose of the retainer in a string trimmer or a leaf blower is to secure the recoil starter pulley while the appliance is in use. The retainer in a string trimmer or a leaf blower might have to be replaced if it can no longer secure the recoil starter pulley. If damaged, it should be removed and replaced by this genuine OEM replacement part.This component is a genuine OEM replacement part, sourced directly from the manufacturer. It is sold individually. This retainer is compatible with the following outdoor appliance brands: Husqvarna, Craftsman, Poulan, Weed Eater, Paramount, and Turf King.

This recoil starter pulley is a genuine Husqvarna part, sold individually. This recoil starter pulley can be used as a replacement part for a string trimmer or a leaf blower. The purpose of a recoil starter pulley is to function within the pull-start mechanism of the string trimmer or leaf blower so when the pull-start system is engaged by the operator, the pulley is activated, and the engine is powered on.If the pull-start mechanism can no longer function, the recoil starter pulley should be removed and replaced by this genuine OEM replacement part. Remember to always wear gloves when handling, repairing, and operating outdoor equipment. Always unplug the appliance before performing any kind of repair or replacement.This is an OEM part sourced directly from the manufacturer. It is sold individually. This recoil starter pulley is compatible with the following outdoor appliance brands: Husqvarna, Craftsman, Weed Eater, and Poulan.

This starter spring will put tension on the starter pulley, which will then retract the starter assembly on a range of lawn and garden equipment. It engages the drive cup on the flywheel to start the engine when it is pulled. The starter spring is made from durable metal, but it may need to be replaced if it fails. It could become damaged or corroded, or it may have simply worn down over time and a lot of usage. A problematic starter spring will mean that the starter cord does not recoil properly after being pulled. It can make starting the engine difficult at best, and impossible at worst. In these cases, a replacement becomes necessary. The authentic OEM replacement starter spring is sold individually. It can be used with string trimmers, leaf blowers, and hedge trimmers. It is compatible with Craftsman, Husqvarna, Poulan, Poulan Pro, and Weed Eater brands. Buyers must always make sure they are choosing the correct option for their make and model.

The Fuel Line is an OEM replacement part for Husqvarna outdoor power equipment, such as chainsaws, trimmers, and blowers. This component is essential for transporting fuel from the tank to the carburetor, ensuring that the engine receives a steady supply of fuel for optimal performance.

Causes of a bad fuel line can include regular wear and tear, exposure to fuel and environmental elements, or physical damage from mishandling or improper storage. Over time, the fuel line can become brittle, crack, or clog, hindering fuel flow.

Symptoms of a bad Fuel Line include:

• The engine failing to start or running inconsistently
• Visible cracks or leaks in the fuel line
• Fuel odor or visible fuel leaks around the equipment
• Reduced engine performance or stalling during operation

This OEM Husqvarna part ensures reliable operation and is compatible with various models of Husqvarna equipment.
