Whirlpool WP2198574 Ice Auger (Ice Bucket/Dispenser) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Auger, Helix, Crusher.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP2198574 replaces AP6006171, 2198574, 2211590, 920447, PS11739237.

Description

Located inside the freezer's ice bucket, this ice auger is the helical shaft that rotates to move cubes toward the chute for cubed or crushed ice. Replacing a worn or bent auger restores dispensing and helps prevent jams and grinding.

• Rotates with the dispenser motor to move ice through the bucket and into the chute
• Works with the crusher assembly to provide cubed or crushed ice
• Damage or wear can cause jamming, slow/weak dispensing, or loud grinding during dispense
• Often replaced when the dispenser motor runs but little or no ice is dispensed

What's included: 1 ice auger Installation notes:

• Disconnect power to the refrigerator; remove the ice bucket from the freezer
• Disassemble the bucket/crusher housing; transfer blades, spacers, and hardware to the new auger in the same order and orientation
• Handle sharp metal parts with care; wear cut-resistant gloves
• Reinstall the bucket fully seated; restore power and test both cubed and crushed functions
