Whirlpool WPW10237493 Washer Door Bellow (Drum Light) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Gasket & Seal.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10237493 replaces AP6017513, W10237493, 4442862, PS11750812.

Description

This washer door bellow seals the opening between the outer tub and the front panel. The drum-light version restores a watertight seal on models equipped with an interior drum light, helping prevent leaks and odor issues from a torn or deteriorated boot.

• Creates a flexible, watertight barrier between the door opening and the outer tub
• Version designed for models with an interior drum light; aligns with the light opening
• Helps the washer contain water properly through fill, wash, and spin cycles
• Common symptoms: water leaking at the door/front, visible tears or cracks, persistent mildew or odor on the boot

What's included: 1 door bellow Install notes:

• Unplug the washer and turn off water supply before servicing
• Remove necessary front/top access; release inner and outer retaining clamps and remove the old bellow
• Align drain ports and the drum-light opening; seat the bellow fully on the tub and front panel, then reinstall clamps evenly
• Run a quick test and inspect for leaks
